Service Manual 4. Refrigerant System Diagram 12/18/24K Cooling and heating model Outdoor unit Indoor unit Gas pipe side Valve 4-Way valve Di s charge Heat Suction Accumlator exchanger Compressor (evaporator) Heat exchanger Liquid pipe (condenser) side Valve Strainer Electric Strainer expand valve COOLING...
Service Manual 5.2 PCB Printed Diagram Indoor Unit ● Top view Name Interface of live wire Fuse Interface of neutral wire Interface of fan Auto button Up&down swing interface Interface of PG feedback Interface of dry contact Interface of wifi Needle stand for tube temperature sensor Display interface...
Page 29
Service Manual Outdoor Unit . Top view Name 1 Interface of compressor wire 2 Interface of reactor Terminal of chassis electric heater Terminal of compressor electric heater 5 Terminal of 4-way valve 6 Interface of outdoor fan 7 Interface of earthing wire 8 Communication interface 9 Interface of netural wire 10 Interface of live wire...
Page 30
Service Manual ● Top view Name Terminal of compressor overload protection Terminal of temperature sensor Terminal of electronic expansion valve 4 Terminal of outdoor fan 5 Terminal of 4-way valve Terminal of compressor electric heating Terminal of chassis electric heating Terminal of indoor unit and outdoor unit communication 9 Power supply live wire...
Page 31
Service Manual Top View Name Name Name Compressor three phase input interface Terminal of high pressure protection 11 Terminal of chassis electric heating Terminal of low ambient temperature Terminal of low pressure protection 12 Terminal of live wire cooling temperature sensor Terminal of electronic expansion valve Terminal of outdoor fan 13 Terminal of communication...
Service Manual 6. Function and Control 6.1 Remote Controller Introduction ON/OFF button MODE button FAN button TURBO button ▲/ button button button SLEEP button I FEEL button TIMER ON / TIMER OFF button CLOCK button QUIET button WiFi button LIGHT button button TEMP button Set fan speed...
Page 33
Service Manual Press this button to turn on the unit. Press this button again to turn off the unit. (This indicator is not available for some models). (This indicator is not available for some models). Operation indicator is ON. (This indicator is not available for some models).
Page 34
Service Manual ● The function is only available for some mode ● Press this button, can select Sleep 1 ( ), Sleep 2 ( ), Sleep 3 ( ) and cancel the Sleep, circulate between these, after electrified, Sleep Cancel is defaulted.Sleep 1 is Sleep mode 1, in Cool modes; sleep status after run for one hour, the main unit setting temperature will increase 1 , two hours, setting temperature increased 2 , then the unit will run at this setting temperature;...
Page 35
Service Manual ● The Quiet function can be set up in all modes; Under the Quiet mode,the fan speed is not available. ● The Quiet function is only available for some models. ● When quiet function is selected Under cooling mode: indoor fan operates at notch 4 speed. 10 minutes later or when indoor ambient temperature≤28℃, indoor fan will operate at notch 2 speed or quiet mode according to the comparison between indoor ambinet temperature and set temperature.
Page 38
Service Manual 6.2 GREE+ App Operation Manual Control Flow Chart Internet Gree Cloud Gree Home Wi-Fi Cellular/ intelligent home Other Wi-FI appliances Home wireless router Home Wi-Fi GREE+ APP Operating Systems 5HTXLUHPHQW IRU 8VHU
V VPDUW SKRQH iOS system Android system Support iOS7.0 and...
Page 39
Service Manual 6.3 Ewpe Smart App Operation Manual Control Flow Chart Internet Cloud intelligent Cellular/ Home Wi-Fi home Other Wi-FI appliances Home wireless router Home Wi-Fi Operating Systems 5HTXLUHPHQW IRU 8VHU
V VPDUW SKRQH iOS system Android system Support iOS7.0 and Support Android 4.4 and above version above version...
Service Manual Part : Installation and Maintenance 7. Notes for Installation and Maintenance Safety Precautions: 10. If the power cord or connection wire is not long enough, please get the specialized power cord or connection wire Important! from the manufacture or distributor. Prohibit prolong the wire by yourself.
Page 52
Service Manual Safety Precautions for Installing and Relocating the Unit: To ensure safety, please be mindful of the following precautions. Warnings 1. When installing or relocating the unit, be sure to keep the refrigerant circuit free from air or substances other than the VSHFL¿HG UHIULJHUDQW $Q\ SUHVHQFH RI DLU RU RWKHU IRUHLJQ VXEVWDQFH LQ WKH UHIULJHUDQW FLUFXLW ZLOO FDXVH V\VWHP SUHVVXUH ULVH RU FRPSUHVVRU UXSWXUH UHVXOWLQJ LQ LQMXU\...
Service Manual 8. Installation 8.1 Installation Dimension Diagram Space to the wall At least 15cm At least 15cm Space to the wall Drainage pipe Installation and Maintenance...
Page 56
Service Manual Start installation Preparation before installation Read the requirements select installation Prepare tools for electric connection location Select indoor unit Select outdoor unit installation location installation location Install the support of outdoor unit Install wall-mounting frame, drill wall holes (select it according to the actual situation) Connect pipes of indoor Fix outdoor unit...
Page 68
Service Manual If malfunction occurs,corresponding code will display and the unit will resume normal until protection or malfunction disappears. Installation and Maintenance...
Page 69
Service Manual Analysis or processing of some of the malfunction display: 1. Compressor discharge protection 3RVVLEOH FDXVHV VKRUWDJH RI UHIULJHUDQW EORFNDJH RI DLU ILOWHU SRRU YHQWLODWLRQ RU DLU IORZ VKRUW SDVV IRU FRQGHQVHU WKH V\VWHP KDV QRQFRQGHQVLQJ JDV VXFK DV DLU ZDWHU HWF EORFNDJH RI FDSLOODU\ DVV\ LQFOXGLQJ ¿OWHU OHDNDJH LQVLGH IRXUZD\ YDOYH FDXVHV LQFRUUHFW RSHUDWLRQ PDOIXQFWLRQ RI FRPSUHVVRU PDOIXQFWLRQ RI SURWHFWLRQ UHOD\ PDOIXQFWLRQ RI GLVFKDUJH VHQVRU RXWGRRU WHPSHUDWXUH WRR KLJK 3URFHVVLQJ PHWKRG UHIHU WR WKH PDOIXQFWLRQ DQDO\VLV LQ WKH DERYH VHFWLRQ...
Service Manual 9.2 Procedure of Troubleshooting Indoor unit (1) Malfunction of Temperature Sensor F1, F2 0DLQ GHWHFWLRQ SRLQWV ,V WKH ZLULQJ WHUPLQDO EHWZHHQ WKH WHPSHUDWXUH VHQVRU DQG WKH FRQWUROOHU ORRVHQHG RU SRRUO\ FRQWDFWHG" ,V WKHUH VKRUW FLUFXLW GXH WR WULSRYHU RI WKH SDUWV" ,V WKH WHPSHUDWXUH VHQVRU EURNHQ"...
Page 71
Service Manual (2) Malfunction of Blocked Protection of IDU Fan Motor H6 0DLQ GHWHFWLRQ SRLQWV 6PRRWKO\,V WKH FRQWURO WHUPLQDO RI 3* PRWRU FRQQHFWHG WLJKWO\" 6PRRWKO\,V WKH IHHGEDFN LQWHUIDFH RI 3* PRWRU FRQQHFWHG WLJKWO\" 7KH IDQ PRWRU FDQW RSHUDWH" 7KH PRWRU LV EURNHQ" 'HWHFWLRQFLUFXLW RI WKH PDLQERDUG LV GH¿QHG DEQRUPDO"...
Page 72
Service Manual (3) Malfunction of Protection of Jumper Cap C5 0DLQ GHWHFWLRQ SRLQWV ,V WKHUH MXPSHU FDS RQ WKH PDLQERDUG" ,V WKH MXPSHU FDS LQVHUWHG FRUUHFWO\ DQG WLJKWO\" 7KH MXPSHU LV EURNHQ" 7KH PRWRU LV EURNHQ" 'HWHFWLRQ FLUFXLW RI WKH PDLQERDUG LV GH¿QHG DEQRUPDO" 0DOIXQFWLRQ GLDJQRVLV SURFHVV 6WDUW $SSHDUDQFH RI WKH...
Page 73
Service Manual (4) Malfunction of Zero-crossing Inspection Circuit Malfunction of the IDU Fan Motor U8 0DLQ GHWHFWLRQ SRLQWV ,QVWDQW HQHUJL]DWLRQ DIWH GHHQHUJL]DWLRQ ZKLOH WKH FDSDFLWRUGLVFKDUJHV VORZO\" 7KH ]HURFURVV GHWHFWLRQFLUFXLW RI WKH PDLQERDUG LV GH¿QHG DEQRUPDO" 0DOIXQFWLRQ GLDJQRVLV SURFHVV 6WDUW 7XUQ SRZHU RII IRU PLQXWHWKH WXUQ EDFN RQ 7KH XQLW UHWXUQV WR QRUPDO...
Page 74
Service Manual (5) Malfunction of detecting plate(WIFI) JF Start check if the connection wire are correctly connected Replace the detecting plate with the same model Is malfunction eliminated Replace the mainboard with the same model The end Installation and Maintenance...
Page 75
Service Manual Outdoor unit: (1) Capacitor charge fault (Fault with outdoor unit) (AP1 below refers to the outdoor control panel) 0DLQ &KHFN 3RLQWV 8VH $& YROWPHWHU WR FKHFN LI WKH YROWDJH EHWZHHQ WHUPLQDO / DQG 1 RQ WKH ZLULQJ ERDUG LV ZLWKLQ 9$&a9$& ,V WKH UHDFWRU / FRUUHFWO\ FRQQHFWHG"...
Page 76
Service Manual 2. IPM protection, phase current overcurrent (the control board as below indicates the control board of outdoor unit) H5/P5 Mainly detect: (1) Compressor COMP terminal (2) voltage of power supply (3) compressor (4) Refrigerant-charging volume (5) air outlet and air inlet of outdoor/indoor unit Troubleshooting: Turn on the unit after energization...
Page 77
Service Manual (3) High temperature and overload protection diagnosis (AP1 hereinafter refers to the control board of the outdoor unit) 0DLQO\ GHWHFW ,V RXWGRRU DPELHQW WHPSHUDWXUH LQ QRUPDO UDQJH" $UH WKH RXWGRRU DQG LQGRRU IDQV RSHUDWLQJ QRUPDOO\" ,V WKH KHDW GLVVLSDWLRQ HQYLURQPHQW LQVLGH DQG RXWVLGH WKH XQLW JRRG" )DXOW GLDJQRVLV SURFHVV Overheat and high temperature protection...
Page 78
Service Manual (4) Start-up failure (following AP1 for outdoor unit control board) 0DLQO\ GHWHFW :KHWKHU WKH FRPSUHVVRU ZLULQJ LV FRQQHFWHG FRUUHFW" ,V FRPSUHVVRU EURNHQ" ,V WLPH IRU FRPSUHVVRU VWRSSLQJ HQRXJK" )DXOW GLDJQRVLV SURFHVV Power on the unit Restart it up after Is stop time of the compressor 3 minutes longer than 3 minutes?
Page 79
Service Manual (5) Out of step diagnosis for the compressor (AP1 hereinafter refers to the control board of the outdoor unit) 0DLQO\ GHWHFW ,V WKH V\VWHP SUHVVXUH WRR KLJK" ,V WKH LQSXW YROWDJH WRR ORZ" )DXOW GLDJQRVLV SURFHVV Out of step occurs in Out of step occurs once the operation unit is powered on.
Page 80
Service Manual (6) Overload and air exhaust malfunction diagnosis (following AP1 for outdoor unit control board) 0DLQO\ GHWHFW ,V WKH 309 FRQQHFWHG ZHOO RU QRW" ,V 309 GDPDJHG" ,V UHIULJHUDQW OHDNHG" )DXOW GLDJQRVLV SURFHVV 20 minutes after the complete unit is powered off Is the terminal FA for the Connect the...
Page 81
Service Manual (7) Communication malfunction: (following AP1 for outdoor unit control board) 0DLQO\ GHWHFW ,V WKHUH DQ\ GDPDJH IRU WKH LQGRRU XQLW PDLQERDUG FRPPXQLFDWLRQ FLUFXLW" ,V FRPPXQLFDWLRQ FLUFXLW GDPDJHG" 'HWHFW WKH LQGRRU DQG RXWGRRU XQLWV FRQQHFWLRQ ZLUH DQG LQGRRU DQG RXWGRRU XQLWV LQVLGH ZLULQJ LV FRQQHFW ZHOO RU QRW LI LV WKHUH DQ\ GDPDJH"...
Service Manual 10. Exploded View and Parts List 10.1 Indoor Unit . 7KH FRPSRQHQW SLFWXUH LV RQO\ IRU UHIHUHQFH SOHDVH UHIHU WR WKH DFWXDO SURGXFW Installation and Maintenance...
Page 117
Service Manual Steps Procedure 1.Remove big handle Before disassamble. Remove the screws fixing handle、valve big handle cover and then remove them. valve cover 2. Remove top cover top cover Remove the screws fixing top panel and then remove the top panel. Installation and Maintenance...
Page 118
Service Manual Step Procedure 3.Remove grille 、protective grille and front panel Remove connection screws between the front grille and the front panel. Then remove the front grille. Remove connection screws connecting the front protective panel with the chassis and the motor support, and grille then remove the front panel.
Page 119
Service Manual Step Procedure 6.Remove motor and motor support Remove the screws fixing motor and then remove the motor. Remove the screws fixing motor support and then remove the motor support. motor support motor 7.Remove electric box assy Remove the screws fixing electric box assy; cut off electric box assy the tieline;...
Page 120
Service Manual Step Procedure electronic expansion 9.Remove 4-way valve assy and valve assy Unsolder the welding joints connecting the 4-way electronic expansion assy valve assy with compressor and condenser; remove the 4-way valve. 4-way valve assy Note: Before unsoldering the welding joint, wrap the 4-way valve with a wet cloth completely to avoid damage to the valve caused by high temperature.
Page 121
Service Manual 18/24K 127(7DNH *:+4(.'1$(2 IRU H[DPSOH Steps Procedure 1. Remove top panel Twist off the screws used for fixing the handle and v alve cover , pull the handle and v alve cover up ward to remove it. handle valve top panel Remove...
Page 122
Service Manual Remove the 5 screw s connecting the pa nel wi th the chassis and the motor support, and then remove the pa nel. panel 3. Remove left side plate and right side plate Remove the scre ws connecting the right side plate with the chassis, the valve support and the electric box, and then remove the right side plate assy .
Page 123
Service Manual 4. Remove fan motor axial flow blade Remove the nuts fixing the blade and then remove the axial flow blade. fan motor fixing frame Remove the 4 tappin g screw s fixing the motor; disconnect the leading wire insert of the motor and then remove the moto r.
Page 124
Service Manual 6.Remove Fireproof electric box and soundproof sponge Fireproof electric box Tw ist of f the screws on fireproof electric box and then r emove the fireproof electric box . Since the piping ports on the soundproof sponge are torn easily , remove the soundproof sponge carefully .
Page 125
Service Manual 8. Remov e 4-w ay valv e assy Discharge the refrigerant completely;unsolder 4-way valve assy the pipelines connecting the compressor and the condenser assy,and then remove the 4-way valve assy. 9. Remov e c ompressor compressor Remove the 3 foot nuts fixing the compressor and then remove the compressor.
Page 126
Service Manual condenser sub-assy Dissemble the chassis sub-assy and condenser sub-assy. chassis sub-assy Installation and Maintenance...
Service Manual Appendix 3: Pipe Expanding Method Pipe Note: Pipe cutter Improper pipe expanding is the main cause of refrigerant leakage.Please expand the pipe according to the following steps: Leaning Uneven Burr $&XW WKH SLS &RQ¿UP WKH SLSH OHQJWK DFFRUGLQJ WR WKH GLVWDQFH RI LQGRRU XQLW DQG RXWGRRU XQLW &XW WKH UHTXLUHG SLSH ZLWK SLSH FXWWHU %5HPRYH WKH EXUUV Pipe...
Service Manual Appendix 4: List of Resistance for Temperature Sensor Resistance Table of Ambient Temperature Sensor for Indoor and Outdoor (15K) 7HPS & 5HVLVWDQFHN 7HPS & 5HVLVWDQFHN 7HPS & 5HVLVWDQFHN 7HPS & 5HVLVWDQFHN 138.1 18.75 3.848 1.071 128.6 17.93...
Page 130
Service Manual Resistance Table of Tube Temperature Sensors for Indoor and Outdoor (20K) 7HPS & 5HVLVWDQFHN 7HPS & 5HVLVWDQFHN 7HPS & 5HVLVWDQFHN 7HPS & 5HVLVWDQFHN 181.4 25.01 5.13 1.427 171.4 23.9 4.948 1.386 162.1 22.85 4.773 1.346 153.3 21.85...
Page 132
