Bottom view

1
N o I n t e r f a c e
1 ON/OFF button
2 Reset button

Physical dimensions and weight

The table below lists the physical dimensions and weight of the CloudMesh Satellite.
CloudMesh Satellite – User Guide
UG01350 v1.00 14 July 2021
Fi gure 3 – Bottom view interfaces
D e s c r i p t i o n
Turns the CloudMesh Satellite on or off.
To reset the CloudMesh Satellite, insert a straightened paper clip or
similarly shaped object into the small hole marked with the reset icon
and hold for ten (10) seconds.
Ta ble 3 - Bottom view interface
D i m e n s i o n s
Width
Height
Depth
Weight
Ta ble 4 - Physical dimensions and weight
113 mm
145 mm
110 mm
320 grams
7 of 22
