Rear View - NetComm CloudMesh Satellite NS-02 User Manual

Rear view

1
N o . I n t e r f a c e
1 Ethernet ports
2 Power adapter port
3 WPS button
CloudMesh Satellite – User Guide
UG01350 v1.00 14 July 2021
Fi gure 2 – Rear view interfaces
D e s c r i p t i o n
Gigabit Ethernet LAN ports. Can be used to connect clients in bridge
mode.
Connect the included power adapter here.
Push this button within 2 minutes of pushing the 5GHz WPS button on
the CloudMesh Gateway to connect (pair) them.
During the pairing process, the LED indicator on the front side of the
CloudMesh Satellite will be flashing purple, see page 9.
Ta ble 2 - Rear view interfaces
6 of 22
3
1
2
