Impressa S9 One Touch Quick Reference Guide
This Guide does not replace the Operating Instructions.
For details and cautions you must read all instructions.
Traces of Coffee Grounds in New Machine?
This is normal! Grinder was tested during assembly with beans.
Despite cleaning, traces of ground coffee may be found.
COFFEE
SELECT
RE DY
PRODUCT
ON/OFF
Rinse
Four Coffee Buttons
RED TEXT
represents display text.
A) First Time Ever Preparation
1. Fill water in tank and beans in bean container.
2. DO NOT install the Clearyl Filter Cartridge now!
3. Push the main power switch in the back of the machine.
4. Push the ON/OFF button in the display. When the display
reads
FILL SYSTEM / PRESS STEAM
the frothXpress and push the Rinse button.
SYSTEM FILLING
5. Place a cup under the coffee spouts and press the RINSE
button.
MACHINE
6. Place a large cup underneath the coffee spouts and press
the 1-CUP coffee button.
starts grinding and brewing. Repeat once. Discard the first
two cups of coffee.
B) Daily Preparation
1. Fill fresh water in tank and check bean container.
2. Push ON/OFF button.
a cup under the coffee spouts and press the RINSE button.
MACHINE RINSING. COFFEE
Important: You can only brew coffee when display shows
COFFEE
READY.
C) Grinding and Brewing Coffee
Four pre-set coffee buttons:
1
COFFEE,
2
COFFEES. These buttons are pre-set for
strength (five settings), cup size (1 to 8 oz. per cup) and
temperature (HIGH, NORMAL). In programming you can
change all three functions.
To brew coffee:
place a cup under
then
HEATING
UP.
PRESS
RINSING.
COFFEE
READY.
1
COFFEE: The machine
HEATING UP. PRESS
READY.
1
ESPRESSO,
A LA Carte
Rotary Dial
with
Push-Button
RINSE.
RINSE. Place
2
ESPRESSI,
68206

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Impressa S9 One Touch and is the answer not in the manual?

Questions and answers

Summary of Contents for Jura Impressa S9 One Touch

  • Page 1 All manuals and user guides at all-guides.com Impressa S9 One Touch Quick Reference Guide This Guide does not replace the Operating Instructions. For details and cautions you must read all instructions. Traces of Coffee Grounds in New Machine? This is normal! Grinder was tested during assembly with beans.
  • Page 2 All manuals and user guides at all-guides.com Pre-warm cup, see "E) Using Hot Water" COFFEE READY. Place a cup under the Dual Coffee Spouts and push one of the four coffee buttons. Display shows e.g. 1 ESPRESSO and coffee flows into your cup and stops automatically.
  • Page 3 All manuals and user guides at all-guides.com 1. Fill the thermal milk container with milk and attach to the frothXpress system. Important: Make sure all parts are connected tightly, otherwise siphoning does not work. 2. Set the frothXpress dial to the 12 o’clock position for frothing for cappuccino or to the 6 o’clock position for steaming for latte.
  • Page 4 All manuals and user guides at all-guides.com 3. Push Cappuccino button. Display shows COFFEE 2.0 4. Push the Dial, COFFEE 2.0 OZ and turn until display shows COFFEE 4.0 5. Push Dial to confirm: CONFIRMED then COFFEE 4.0 6. Turn the Dial until display shows AROMA and the current strength setting of three beans.
  • Page 5 All manuals and user guides at all-guides.com K. Replacing the Clearyl Cartridge When display shows COFFEE READY /CHANGE FILTER and the Rinse button lights up: • Push Rinse button. DURATION 2 MIN. / START YES. • Remove water tank, remove old filter. Keep the extension rod.
  • Page 6 N) Supplies can be ordered through: Customer Service, Mail Order Form or www.capresso.com • Clearyl Water Filter Cartridge: #64553 • Cleaning Tablets: #62205 • Decalcifying Tablets: #66281 JURA-CAPRESSO CUSTOMER SERVICE: 1-800-220-5701 M-F 9AM - 9PM; Sat. 9AM - 5PM EST FAX: 201-767-9684 contact@capresso.com...
