Installation Guide
for EHE0200155 Room Thermostat
1. Find a suitable location for mounting
3. Mount the backplate to wall
a. Wall box mounting
4. Wiring options
a. Wall box wiring
1.5
M
Fixing holes spaced
to suit BS4662
Screws supplied
2. Remove the cover from the backplate
b. Surface mounting
b. Surface wiring
CAUTION: Disconnect
system power supply
before removing cover.
Use wall box fixing holes
or alternatives shown
Screws supplied
