Figure 12 Location for cage nut near top of allocated 4U space
5. Repeat the entire procedure for the left outer rail assembly.
Attach the inner rails to the storage enclosure
You must correctly attach the inner rails to the storage enclosure to bear the weight of its contents.
Required equipment
Inner rails, properly oriented
T10 Torx screwdriver, 6-in length
M3 low profile screws, 5x2.75-in length
#2 Phillips-head screwdriver, 6-in length
Panhead screw, M4x4mm length
CMA A bracket
P/N 83-00007769-10-01 Rev. A, March 2021 • 11
Qty Identification
2
1
10
1
2
1
N/A
N/A
N/A
