SAFETY INSTRUCTIONS
1. 120 Volts may cause serious injury from electric shock. Disconnect electrical power before starting installation or servicing.
Leave power disconnected until installation/service is completed.
2. Sharp edges may cause serious injury from cuts. Use care when cutting plenum openings and handling duct work.
3. Dropping may cause personal injury or equipment damage. Handle with care and follow installation instructions.
1. Read all instructions before beginning installation.
2. Improper installation may cause property damage or injury. Installation, service, and maintenance must be performed by a
qualified service technician.
3. Do not use in pool applications. Pool chemicals can damage the dehumidifier.
4. Do not use solvents or cleaners on or near the circuit board. Chemicals can damage circuit board components.
5. Wait 24 hours before running the unit if it was not shipped or stored in the upright position
6. Do not use dehumidification to prevent window condensation in the winter. To address window condensation, use ventilation
to lower indoor humidity in the winter.
7. This appliance is not intended for use by persons (including children) with reduced physical, sensory, or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning the use of this
appliance by a person responsible for their safety.
8. Children should be supervised to ensure that they do not play with the appliance.
9. If the supply cord is damaged, it must be replaced by a special cord or assembly available from the manufacturer or its
service agent.
Model E080CS & E100CS Dehumidifier
Installation and Operation Manual
WARNING
CAUTION
READ AND SAVE THESE INSTRUCTIONS
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the E080CS and is the answer not in the manual?

Questions and answers

Related Manuals for Aprilaire E080CS

Summary of Contents for Aprilaire E080CS

  • Page 1 Model E080CS & E100CS Dehumidifier Installation and Operation Manual SAFETY INSTRUCTIONS WARNING 1. 120 Volts may cause serious injury from electric shock. Disconnect electrical power before starting installation or servicing. Leave power disconnected until installation/service is completed. 2. Sharp edges may cause serious injury from cuts. Use care when cutting plenum openings and handling duct work.

  • Page 2: Table Of Contents

    Service Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12 SPECIFICATIONS Model E080CS Model E100CS Shipping Weight 81 lbs .

  • Page 3: Set Up Dehumidifier For Installation

    SET UP DEHUMIDIFIER FOR INSTALLATION IMPORTANT: Cut the strap securing the compressor shipping support bracket and remove the strap and shipping bracket . See Figure 1 . IMPORTANT: Remove the ALERT LIGHT and FLOAT Switch cables from around the duct collar . PACKAGING CONTENT 1.

  • Page 4: Duct Collars

    DUCT COLLARS Use the screws in the parts bag to attach the duct collars to the inlet and outlet of the dehumidifier . The outlet collar has a backflow FIGURE 3 – Install Duct Collars damper . See Figure 3 . OUTLET COVER OUTLET DUCT COLLAR W/BACK...

  • Page 5: Location Considerations

    LOCATION CONSIDERATIONS • Allow sufficient clearance for filter removal and FIGURE 6 – Filter Access Clearance to prevent airflow obstruction • Electrical service access will require the removal ELECTRICAL SERVICE 6" MINIMUM CLEARANCE of the side panel shown . Allow sufficient space ACCESS THIS SIDE FOR PROPER AIR FLOW for service on this side of the unit .

  • Page 6: Drain Tubing And Condensate Pump Installation

    DRAIN TUBING AND CONDENSATE PUMP INSTALLATION The drain outlet on the dehumidifier can be plumbed FIGURE 8 – Drain and Condensate Pump Installation directly to a condensate pump (see Figure 8) using the provided fitting and 1/2” clear PVC tubing . Always maintain a constant downward slope from the dehumidifier to the condensate pump .

  • Page 7: Float Switch Wiring

    FLOAT SWITCH WIRING If using a condensate pump, remove the factory installed jumper wire between the FLOAT SWITCH terminals on the control, and wire FIGURE 10 – Float Switch Wiring the float switch terminals to the normally closed contacts on the condensate pump or float switch .

  • Page 8: Model 76 - Crawl Space Control And Wiring

    MODEL 76 – CRAWL SPACE CONTROL AND WIRING NOTE: Use 18-22 AWG wire for control wiring . FIGURE 12 – Model 76 Crawl Space (Remote) Wiring CRAWL SPACE CONTROL Used as crawl space control (or remote control), the Model 76 is mounted in the living space while the dehumidifier is located in the crawl + –...

  • Page 9: System Check

    SYSTEM CHECK Press and hold the ON/OFF button After one minute of compressor and MODE buttons for 3 seconds . operation, all outputs will turn off The measured humidity, AIR and DONE will blink for 3 seconds SAMPLING and TEST will show and then return to the OFF screen .

  • Page 10: High Dew Point / High Humidity Alert

    HIGH DEW POINT / HIGH HUMIDITY ALERT If the dehumidifier measures the dew point of the air to be 4°F or more or 6%RH or more above the setting for 72 consecutive hours, the ALERT LIGHT will turn on and the display will show “HI” . The dehumidifier will continue to operate as normal when the ALERT LIGHT is on . If the dew point falls within 4°F of the setting or relative humidity falls within 6%RH of the setting, the ALERT LIGHT will turn off .
  • Page 11 0 .4”w .c . for Model • Verify that the outlet collar with backflow damper is installed on the outlet side of the dehumidifier . E080CS or 0 .6”w .c . for • Check if backflow damper is blocked or stuck and remove obstruction .

  • Page 12: Service Parts

    Fan, 100pt Deh, with 12MFD Capacitor 5886 Threaded Barbed Drain Fitting 5461 Wire Harness, Power, Deh 5884 Condensate Pump with Tubing 4856 AprilairePartners.com P.O. Box 1467 Madison, WI 53701-1467 800.334.6011 F: 608.257.4357 Printed in USA ©2021 Aprilaire – Division of Research Products Corporation 10015561 B2209244A 1.21...
