PUD-P-YMF-C PFD-P-VM-A Close control CONTENTS 1. Specifications ······························································ ······························································ 1-1 Main Features ····· 1-2 List of Possible Combinations of Indoor and Outdoor Units 1-3 Unit Specifications ························································· 2. Capacity Curves ························································· ························································· 2-1 Cooling Capacity ························································· 2-2 Cooling Input ·························································... -
Page 2: Specifications
POWER RATING WEIGHT SERIAL No. 2.11kg MITSUBISHI ELECTRIC CORPORATION PAC-SC50KUA When using a PFD-P250VM-A as an indoor unit, connect an outdoor unit PUD-P250YMF-C to each indoor unit and operate with a built-in remote control for the indoor unit. ✻1: Bold line indicates refrigerant piping (gas/liquid). This system consists of one refrigerant circuit. -
Page 3: List Of Possible Combinations Of Indoor And Outdoor Units
1-2. List of Possible Combinations of Indoor and Outdoor Units Units Indoor Units Model Name Down-flow Type 380-415V(50Hz) 380-415V(50Hz) Power Source 400,415V(60Hz) 400,415V(60Hz) Unit Horse Power 10HP 20HP Series Name PFD-P250VM-A(-H) PFD-P500VM-A(-H) 28.0 56.0 10.9 21.8 PUD- 10HP /400 P250YMF-C 18.3/17.3/16.3 36.1/34.3/33.0 /415V... - Page 4 (2) Indoor Unit PFD-P250VM-A PFD-P500VM-A Power source 3N~380-415V 50Hz / 3N~400-415V 60Hz ✻ 1 Cooling capacity 28.0 56.0 Power consumption Current 5.5/5.3/5.1 9.5/9.0/8.7 External finish <5Y 7/1> Height 1895 Dimensions Width 1,800 1,200 Depth Net weight Heat exchanger Cross fin (Aluminum-plate fin and copper tube) Sirocco fan ✕...
-
Page 5: Capacity Curves
2. Capacity Curves 2-1. Cooling Capacity Indoor Temperature (˚CWB) 24˚CWB 21˚CWB 19˚CWB 17˚CWB 15˚CWB 12˚CWB Outdoor Temperature (˚CDB) 2-2. Cooling Input Indoor Temperature (˚CWB) 24˚CWB 21˚CWB 19˚CWB 17˚CWB 15˚CWB 12˚CWB Outdoor Temperature (˚CDB) ✻ The correction curves indicate the values measured at the point where the compressor was operated at its maximum capacity. -
Page 6: Shf Curves
2-3. SHF Curves Standard Capacity Ratio 130% 120% 110% 100% 90% Indoor Temperature 27˚CDB 0.93 RH (%) Standard Capacity Ratio 130% 120% 110% 100% Indoor Temperature 24˚CDB RH (%) Operation Temparature Range : Indoor : 12˚CWB~24˚CWB Outdoor : -5˚CDB~43˚CDB (RH : 30~80%) Standard Point "... -
Page 7: Correction By Refrigerant Piping Length
2-4. Correction by refrigerant piping length To obtain a decrease in cooling/heating capacity due to refrigerant piping extension, multiply by the capacity correction factor based on the refrigerant piping equivalent length in the table below. Piping equivalent length (m) • How to obtain piping equivalent length Equivalent length = (Actual piping length to the farthest indoor unit) + (0.50 ✕... -
Page 8: Sound Levels
3. Sound Levels 3-1. Noise Level (1) Outdoor Unit Measured point Noise Level Series (dB [Type A]) PUD-P250YMF-C (2) Indoor Unit Noise Level Series (dB [Type A]) Measured PFD-P250VM-A point PFD-P500VM-A... -
Page 9: Nc Curves
3-2. NC Curves PUD-P250YMF-C (External static pressure 0Pa) NC70 NC60 NC50 NC40 NC30 NC20 Approximate minimum audible limit on continuous noise 1000 2000 4000 8000 OCTAVE BAND CENTER FREQUENCIES (Hz) (External static (External static PFD-P250VM-A PFD-P500VM-A pressure 120Pa) pressure 120Pa) High speed High speed NC70... -
Page 10: External Dimensions
4. External Dimensions PUD-P250YMF-C Unit : mm... - Page 11 PFD-P250VM-A Unit : mm...
- Page 12 PFD-P500VM-A Unit : mm...
-
Page 13: Electrical Wiring Diagrams
5. Electrical Wiring Diagrams PUD-P250YMF-C Motor Inverter (Compressor) Controller Box White Black ACCT ACCT Terminal Noise Terminal Diode Block Filter Block stack TB1A TB1B ZNR4 Power source White White White 380/400/415V 50/60Hz Black Black Black Gate amp board (G/A board) Blue Blue Blue... - Page 14 PFD-P250VM-A...
- Page 15 PFD-P500VM-A...
-
Page 16: Options
6. Options Description Model Applicable capacity PAC-TS75DFB P250 Square duct flange (Standard filter)✻1 PAC-TS76DFB P500 PAC-TS70TB P250 Square duct flange (High-efficiency filter) PAC-TS72TB P500 PAC-TS60AF P250 High-efficiency filter 65% ✻2 PAC-TS62AF P500 PAC-TS65AF P250 High-efficiency filter 90% ✻2 PAC-TS67AF P500 ✻1 Used to connect Intake Duct . -
Page 17: Refrigerant Circuit Diagram And Thermal Sensor
7. Refrigerant Circuit Diagram And Thermal Sensor PUD-P250YMF-C... -
Page 18: System Design
8. System Design 8-1.Piping Outdoor Unit Sample Unit Connection Indoor Maximum Pipe Length (L) Net length: under 120m, Total Length: under 150m Under 50m Maximum Height (Under 40m if the outdoor unit is installed below the indoor unit. Difference Between Indoor and outdoor units (H) Under 15m if the outdoor temperature is under 10˚C.) ø... -
Page 19: Control Wiring
8-2.Control Wiring (1) Specifications of control wiring and maximum length of wiring Transmission line is a type of control line. When the source of noise is located adjacent to the unit, the use of shield cable as well as moving the unit as far away from the noise source are recommended. 1 Transmission line (M-NET transmission line) System component For multiple-refrigerant system... - Page 20 (1) Address setting This system requires address setting. The range of address varies depending on the type of unit. Refer to “7-4 Wiring and Address Setting” for details. Address Factory Unit Symbol Setting method setting range setting Assign a number to all indoor units, starting with 1 and using Main/sub 01~50 sequential numbers.
-
Page 21: Wiring And Address Setting (System Using Ma Remote Controller)
8-4.Wiring and Address Setting (1) System Using MA Remote Controller 1 System with one indoor unit (10HP system) Control Wiring Diagram Use CN41 as is. ✻There is one indoor controller board inside indoor unit. TB5-1 A B S A B S TB15 A1 B2 Remarks... - Page 22 Wiring and Address Setting <a. Indoor/Outdoor Transmission Lines > Connect A, B terminals of indoor/outdoor transmission line terminal board (TB3) on the outdoor unit and A, B terminals of the Indoor/outdoor transmission terminal board (TB5). (Non-polar 2 wire) ✻ Only use shield line. [Grounding the shield line] Connect the earth terminal of the OC and S terminal of the IC terminal board (TB5).
- Page 23 (1) System Using MA Remote Controller 2 Unit with One Indoor Unit (20HP Systems) Control Wiring Diagram Replace CN41 with CN40. ✻There are 2 indoor controller boards inside indoor unit. TB5-1 A B S A B S Conect TB15 A1 B2 Use CN41 as is.
- Page 24 Wiring and Address Setting <a. Indoor/Outdoor Transmission Lines > Connect A, B terminals of indoor/outdoor transmission line terminal board (TB3) on the outdoor unit and A, B terminals of the Indoor/outdoor transmission terminal board (TB5). (Non-polar 2 wire) ✻Only use shield line. [Grounding the shield line] Connect the earth terminal of the OC and S terminal of the IC terminal board (TB5).
- Page 25 (1) System Using MA Remote Controller 3 When connecting 2 MA remote controller to one indoor unit (20HP Systems) Control Wiring Diagram Replace CN41 with CN40 ✻There are 2 indoor controller boards inside indoor unit. TB5-1 A B S A B S Connect TB15 A1 B2...
- Page 26 Wiring and Address Setting <a. Indoor/Outdoor Transmission Line > Same as (2). <b. Transmission Line for Centralized Control > Same as (2). <c. MA Remote Controller Wiring > [When using 2 remote controllers] When using two remote controllers, connect terminals 1 and 2 of TB15 on the indoor unit to terminal board of MA controller(option).
- Page 27 (1) System Using MA Remote Controller 4 When grouping 2 indoor units (20HP systems) with MA remote controller Control Wiring Diagram ✻There are two indoor controller board inside each indoor unit. Replace CN41 with CN40. Replace CN41 with CN40. TB5-1 TB5-1 A B S A B S...
- Page 28 Wiring and Address Setting <a. Indoor/Outdoor transmission line > Same as (2). <b. Transmission Line for Centralized Control > Same as (2). <c. MA remote controller line > ✻ When grouping units that use different refrigerants, set MA remote controller of one of the indoor units as sub controller.
- Page 29 (1) System Using MA Remote Controller 5 When grouping multiple indoor units (combination of 10HP, 20HP systems) Control Wiring Diagram ✻There is one indoor controller ✻There are two indoor controller board inside indoor unit. boards inside indoor unit. Use CN41 as is Replace CN41 with CN40.
- Page 30 Control Wiring Diagram ✻There is one indoor controller ✻There are two indoor controller board inside indoor unit. board inside indoor unit. Use CN41 as is Replace CN41 with CN40. TB5-1 TB5-1 A B S A B S A B S A B S Connect TB15...
- Page 31 (2) System with MA remote controller and G-50A 1 System with multiple indoor units (10HP, 20HP) Control Wiring Diagram ✻There is one indoor controller ✻There are two indoor controller board inside indoor unit. boards inside indoor unit. Use CN41 as is. Use CN41 as is.
- Page 32 Control Wiring Diagram ✻There is one indoor controller ✻There are two indoor controller board inside indoor unit. boards inside indoor unit. Use CN41 as is. Use CN41 as is. TB5-1 TB5-1 A B S A B S A B S A B S TB15 TB15...
-
Page 33: External Input/Output Specifications
8-5.External input/output specifications (1) Input/output specifications Input Output Usage Signals Usage Signal Function Function Obtaining signals indicating Start/stop Turning Pulse No.1 Relay a-contact ON/OFF (a-contact with voltage/without operation status of indoor units Operation output voltage) ✻1 in each refrigerant circuit. the indoor Status DC 30V or... - Page 34 (3) Wiring Method 1 Check the indoor unit setting (Refer to 7-5.(2) Wiring ) 2 When using the external output function, connect each signal line to External output Terminal (TB22) on the unit, depending on the usage. 3 When using external input function, peal the outer layer of the signal line off, and connect it to external input terminal (TB21 or TB23) on the unit, depending on the usage.
-
Page 35: Air Conditioning The Computer Room
9. Air Conditioning the Computer Room 9-1 Main Features of the Floor-Duct Air Conditioners This system is installed by building a floor over an existing floor and using the space between these two floors as an air-conditioning duct. This system has the following characteristics: 1 The temperature and humidity can efficiently and reliably be controlled, since the air-conditioned air is sent directly to the machine. -
Page 36: Step-By-Step Plan For The Implementation Of The Air-Conditioning
9-3 Step-by-Step Plan for the Implementation of the Air-Conditioning Purpose Making decisions on the computer system Basic Accommodates possible future expansion (ensuring the acquisition route) Conditions Operation schedule Back-up system (in case of breakdowns, power outage, water-supply cut offs etc.) Air conditioning methods (continuous, floor-duct type etc.) Securing Computer room, CVCF room, MT Disk Storage room... -
Page 37: Conditions For The Installation Of Computer-Room Air Conditioners
9-4 Conditions for the Installation of Computer-Room Air Conditioners (1) Outdoor Temperature and Humidity Generally the values set for general air conditioners are used, although the value higher than the maxi- mum outdoor temperature and humidity may be set for devices like computer-room air conditioners that must keep the air temperature and humidity under predetermined levels. -
Page 38: Setting The Air Conditioners
9-5 Setting the Air conditioners (1) Air-Conditioning Load 1 Once the floor plan is made and the conditions for the air-conditioning system are set, air conditioning capacity has to be determined by calculating the load. 2 Unlike the outdoor air, computer load remains constant throughout the year. However, it is possible that there are considerable fluctuations within a day. - Page 39 (2-3) Calculating the Load and Selecting a Model Calculate the temperature difference by setting the outdoor temperature; then, calculate hourly loads. The chart shows the result of a calculation, supposing that the system reaches its highest load at 12 o'clock. Outdoor temperatures in this example Summer : 32˚CDB relative humidity 60% Winter : -2˚CDB relative humidity 42%...
-
Page 40: Automatic Control Of The Computer Room
9-6 Automatic Control of the Computer Room Example PFD-P560VM-A automatically controls the cooling temperature with a built-in controller. (suction temperature or discharge temperature control) This unit is designed for high sensible-heat specifications, and it does not include a humidifier or a dehumidi- fier. -
Page 41: Maintenance/Inspection
10. Maintenance/Inspection 10-1. Maintenance/Inspection Schedule Having the units inspected by a specialist on a regular basis, in addition to regular maintenance such as changing the filters, will allow the users to use them safely and in good condition for an extended period of time. - Page 42 Details of Maintenance/Inspection Inspection Unit Parts Check points Assessment What to do Cycle Fan motor · Check for unusual noise · Free of unusual noise Replace when insulation · Measure the insulation · Insulation resistance over 1MΩ resistance is under 1MΩ resistance Bearing ·...
- Page 43 HEAD OFFICE: MITSUBISHI DENKI BLDG., 2-2-3, MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN Issued in June 2004 MEE03K204-A New publication, effective June 2004 Printed in Japan Specifications subject to change without notice...
