B-K lighting ArtiStar Integral Standard Installation page 4

DRIVER HOUSING MUST BE INSTALLED ABOVE GRADE. POWER PIPE™ IS LABELED AT GRADE LEVEL.
Power Pipe Mounting Option
Optional
Finished grade
Stability Flange
Concrete
Finished grade
Finished grade
1. Excavate trench according to designed
lighting plan. Dig hole a minimum of 18" deep
and 10" wide to accommodate Power Pipe at
desired fixture location(s).
Finished grade
Remote
12V
Transformer
(by others)
4. Back fill with pea gravel or sand prior to pour.
FIXTURE
COM
HOT
DRIVER
Stability Flange
NEUTRAL
GROUND GROUND IN HOUSING
WIRING DIAGRAM
All line voltage connections must be made
in compliance with the National Electrical
Code. Failure to do so will void warranty.
READ, FOLLOW, AND SAVE ALL SAFETY AND INSTALLATION INSTRUCTIONS
Above Ground
B-K LIGHTING
Installation
Standard Installation
DRIVER HOUSING INSTALLED BELOW GRADE WILL VOID WARRANTY
Pea gravel or sand
Stability Flange
2. Slide optional Stability Flange onto Power
Pipe. Use optional Stability Flange to aid in
installation of Power Pipe.
Finished grade
Pea gravel or sand
5. Pour concrete (not included).
Finished grade
(+)
FIXTURE
Pea gravel Pea gravel
(-)
or sand or sand
7.
IMPORTANT SAFETY INFORMATION LISTED ON REVERSE
Concrete
Finished grade
Concrete
Pea gravel or sand
Label on Power Pipe™ indicates installation
depth with finished grade.
Above Ground
Installation
Pea gravel or sand
Insert wires, connectors and driver into fixture
base and attach to Power Pipe™.
fixture, use 3/16" Allen wrench to slightly
loosen ¼"-28 stainless steel black oxide
socket head screw at the knuckle for vertical
aiming purposes. Rotate fixture to aim to
desired horizontal location.
40429 Brickyard Drive • Madera, CA 93636 • USA
559.438.5800 • FAX 559.438.5900
www.bklighting.com • info@bklighting.com
ArtiStar Integral
Solid State LED
Pea gravel or sand
3. Pull branch circuit wires necessary for
installation (not included) through Power Pipe.
Allow for additional cable to make connections
to fixture lead and future service. Place Power
Pipe in hole. Do not cut PVC.
6. Use waterproof wire connectors (not included)
to connect driver primary leads to branch
circuit wires. Connect incoming ground to
ground wire provided in fixture body. See
wiring diagram.
Concrete
Pea gravel Pea gravel
or sand or sand
8. Tighten three (3) #8-32 stainless steel round
To aim head Phillips screws at base and 1/4"-28
stainless steel black oxide socket head screw
at the knuckle to secure all aiming positions.
Below Ground
Installation
RELEASE DATE
11/03/2021
Concrete
REFERENCE NUMBER
INS-2120-00
Bel
Inst
