Overall Dimensions; Specifications - Allmand TLB Series Operator's Manual

OVERALL DIMENSIONS

Weight
Length
Height
Width
Wheelbase
Ground Clearance
TRACTOR
Engines
Transmission
Drive motor
Power steering
Differential
Brakes
Parking brake
Speed range
Auxiliary hydraulic pump
Auxiliary hydraulic output (Loader)
Auxiliary hydraulic output (Backhoe)
Fuel tank
Hydraulic oil reservoir
Tire size (Front)
Tire size (Rear)
Tire Pressure (Front)
Tire Pressure (Rear)
LOADER
Maximum lift height (Bucket Pivot)
Clearance with bucket dumped
Reach @ maximum height
Reach @ grade
Bucket rollback angle
Bucket dump angle
Digging depth
Lift capacity
Breakout force
Bucket width
Bucket capacity
Specifications are subject to change without notice

SPECIFICATIONS

3100 lbs. (1395 kg)
4620 lbs. (2100 kg) ESL
16' (4.80 m)
82.5" (2.09 m)
56" (1.42 m)
65" (1.65 m)
9" (22.8 cm)
111" (27.9 cm) ESL
Robin EH64
Kohler Command 20
Kubota D905 or D1105
Isuzu 3LD1
Hydrostatic
Ross ME Series
Series 5 Load Sensing
Dana 44 Limited Slip
Hydrostatic
Band type
0 to 5.5 MPH (9.2 km/h)
Gear pump
6 gpm @ 2500 psi
6 gpm @ 2150 psi
12 gallons (54 L)
10 gallons (45.4 L)
23 x 8.5 - 12
31 x 15.5 - 15
Inflate to manufacturer's
Recommendations
25 p.s.i. min. Max. as
specified by manufacturer
90" (2.29 m)
76" (1.93 m)
30" (76.2 cm)
54" (1.37 m)
40 degrees
25 degrees
4" (10.2 cm)
1700 lbs. (765 kg)
2600 lbs. (1179 kg)
56" (1.28 m)
1/3 yd (.25 cu. m)
19
