PB 8154, PB 8155,
R R
PB 8156, PB 8278
PB 8156 & PB 8278
PB 8155
PB 8154
ASSEMBLY INSTRUCTIONS
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
© Playcore Inc. 2012
Printed in USA
LA 6747

Advertisement

loading
Need help?

Need help?

Do you have a question about the Swing-N-Slide PB 8154 and is the answer not in the manual?

Questions and answers

Related Manuals for Playcore Swing-N-Slide PB 8154

Summary of Contents for Playcore Swing-N-Slide PB 8154

  • Page 1 PB 8156 & PB 8278 PB 8155 PB 8154 ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 © Playcore Inc. 2012 Printed in USA LA 6747...
  • Page 2 Safety Checklist for Swing-N-Slide Playsets & Accessories Save this instruction sheet in the event the manufacturer needs to be contacted. Observing the following statements and warnings reduces the likelihood of serious or fatal injury. Installation Safety – Have You: • Consulted the assembly instructions supplied with your particular model? • Consulted the assembly instructions of your particular model for minimum use zones? • Used a water sealant on your play set to protect the wood and prevent cracking and warping? • Placed the equipment on level ground, not less than six feet (1.8 meters) from any structure or obstruction such as a fence, garage,...
  • Page 3 This product is intended for single family home/residential use only and not intended for use in any public setting. Placement in any public setting constitutes a misuse of this product. IMPORTANT! Additional required safety installation instructions According to ASTM requirements, all kits must be anchored to the ground and if the unit has a climbing rope, the rope must be anchored to the ground. If soil conditions permit stakes to be pulled out easily, cementing into the ground is necessary.
  • Page 4 DIMENSIONS MINIMUM USE ZONE FOR PLAY EQUIPMENT SHALL EXTEND NO LESS THAN 72” FROM ALL SIDES OF THE PLAY STRUCTURE. SWING USE ZONE EXTENDS NO LESS THAN 168”. SWINGS MUST HAVE A MINIMUM CLEARANCE OF 8” ABOVE THE PROTECTIVE SURFACING. 90 Max Fall Height 8 Minimum 90 Max Fall Height...

  • Page 5: Tools Required

    TOOLS REQUIRED DRILL 1/2” SOCKET & HAMMER ADJUSTABLE TAPE MEASURE WRENCH WRENCH PHILLIPS BIT CARPENTER SAFETY GLASSES 1/8” DRILL BIT SQUARE INCLUDED HARDWARE 30mm Deck Screw (x166) 1-1/4” Lag Screw (x40) T-20 Bit (x1) 2” Deck Screw (x209) 2” Lag Screw (x30) 2-1/2”...

  • Page 6: Included Components

    INCLUDED HARDWARE 5/16”-18 x 7-1/2” Hex Bolt (x1) 5/16”-18 x 6” Hex Bolt (x1) 5/16”-18 x 5” Hex Bolt (x1) 5/16”-18 x 4-1/2” Hex Bolt (x1) 5/16”-18 x 3-1/2” Hex Bolt (x4) Note: Swing-N-Slide has included all hardware necessary to build any one of the three designs of this playset.
  • Page 7 Note: Slide Not Included. Playset is not complete until an ASTM approved slide is installed as illustrated above. ASSEMBLY INSTRUCTIONS Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545 Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232 © Playcore Inc. 2012 Printed in USA LA xxxx Play Handle (x1) ID Tag (x1)
  • Page 8 INCLUDED COMPONENTS CONT. L-Bracket (x 2) Cool Wave Slide (x1) Window (x1) PB 8154 INCLUDED COMPONENTS Bolt Caps (x4) 2 For Fun Handles (x2) 2 For Fun Seat (x1) RH/LH Brackets (x2 ea) 137-1/2’’ UnCoated Chain (x2) Loc Washer (x2) 5/16’’...
  • Page 9 PB 8154 INCLUDED COMPONENTS CONT. 5/16”-18 x 6-1/4” Hex Bolt (x2) 5/16”-18 x 2” Carriage Bolt (x8) PB 8155 INCLUDED COMPONENTS Wind Rider Seat (x1) Wind Rider Handle (x1) 51’’ UnCoated Chain (x4) 5/16’’ Flat Washer (x2) Loc-Nut (x1 ) Quick Link (x4) 5/16”-18 x 6-1/2”...

  • Page 10: Board List

    BOARD LIST (1) [PF 4110] 1’’ x 6’’ x 31-1/2’’ ARCH (1) [PF 4080] 3’’ x 5-1/2’’ x 89-1/2’’ SWING BEAM (1) [PF 4079] 3’’ x 3’’ x 62’’ SWING BEAM SUPPORT (2) [PF 4109] 1’’ x 4’’ x 64-3/4’’ (1) [PF 4081] 3’’...
  • Page 11 USE THE CORRECT FASTENER Use the guides below to help select the correct length, quantity & location of screws for the board installation. Avoid splitting your lumber by offsetting your screws at least 3/4” from edge. All hardware should be driven until flush with the surface or no deeper than 1/16”. 1x4 to 2x4 &...

  • Page 12: Bracket Installation

    BRACKET INSTALLATION Shelf-Loc bracket CORRECT INCORRECT Cup-Loc bracket CORRECT INCORRECT Bracket mounting NOTCH 1. Always use lag screws 2. Brackets interlock with each other. NEVER position them in a non-interlocking position. 3. Place lag screws in brackets only where instructed. Do NOT fill in every hole as this will lead to a hardware shortage.
  • Page 13 STEP 1 PF 4075 2’’x3’’x78’’ PF 4075 2’’x3’’x78’’ PF 4075 2’’x3’’x78’’ PF 4127 PF 4074 2’’x3’’x22’’ 2’’x3’’x48’’ PF 4074 2’’x3’’x48’’ PF 4126 2’’x3’’x9-1/2’’ Post A PF 4127 2’’x3’’x22’’ PF 4075 2’’x3’’x78’’ Post B PF 4127 2’’x3’’x22’’ Post C 2-1/2” Deck Screw (x76) 1.
  • Page 14 STEP 2 1-1/4” Lag Screw (x8) 2” Lag Screw (x2) NOTCH NOTCH NOTCH (2) 1-1/4” Lag Screws per bracket 84-5/8” 47-3/8” NOTCH 47-3/8” Post C Post B NOTCH Frame A Post A (2) 1-1/4” Lag Screws per bracket 1. Attach brackets as shown.
  • Page 15 STEP 3 PF 4106 1’’x4’’x39-1/2’’ 64-3/4” (3) 2” Deck 39-1/2” Screws PF 4106 1’’x4’’x39-1/2’’ Flush 77-3/4” Hold 22” (3) 2-1/2” Deck between Screws brackets per joint PF 4109 1’’x4’’x64-3/4’’ 50-3/4” Post A Post B Post C Check to make sure structure is square Frame A 2-1/2”...
  • Page 16 STEP 4 TIP: Flex bracket(s) to make installation of 2x4 easier 1-1/4” Lag Screw (x9) 2” Lag Screw (x6) 1-1/4” (2) 2” Lag PF 4132 2’’x4’’x64-3/4’’ (3) 1-1/4” Lag & (2) 2” Lag per 2x4 Shelf Loc bracket Frame A Check to make sure structure is square 1.
  • Page 17 STEP 5 NOTCH (2) 2” Lag Screws per bracket NOTCH (2) 1-1/4” Lag Screws per bracket 84-5/8” 47-3/8” NOTCH 47-3/8” Post C NOTCH 1-1/4” Lag Screw (x8) Post B Frame B (2) 1-1/4” Lag Screws Post A per bracket 2” Lag Screw (x2) 1.Attach brackets as shown.
  • Page 18 STEP 6 64-3/4” 39-1/2” (3) 2” Deck Screws PF 4107 1’’x4’’x39-1/2’’ Flush WINDOW CUTOUT (3) 2” Deck Screws PF 4109 84-7/16’’ 1’’x4’’x64-3/4’’ (3) 2-1/2” Deck Screws per joint Post C Post B Post A Frame B Check to make sure structure is square 2-1/2”...
  • Page 19 STEP 7 64-3/4” PF 4106 (3) 2” Deck (3) 2-1/2” Deck 1’’x4’’x39-1/2’’ Screws Screws per joint PF 4136 1’’x4’’x39-1/2’’ WINDOW CUTOUT ARCH (2) PF 4091 1’’x4’’x12-3/8’’ PF 4106 1’’x4’’x39-1/2’’ Flush PF 4119 1’’x5’’x39-1/2’’ PF 4100 ARCH 1’’x4’’x28-1/4’’ FENCE (2) 2” Deck Screws (2) 2-1/2”...
  • Page 20 STEP 8 TIP: Flex bracket(s) to make installation of 2x4 easier 1-1/4” Lag Screw (x9) 2” Lag Screw (x6) 1-1/4” (2) 2” Lag PF 4132 2’’x4’’x64-3/4’’ (3) 1-1/4” Lag & (2) 2” Lag per 2x4 Shelf Loc bracket Frame B Check to make sure structure is square 1.
  • Page 21 STEP 9 Flush PF 4056 1’’x4’’x31-1/2’’ ANGLE (2) 2” Deck PF 4110 Screws 1’’x6’’x31-1/2’’ Flush ARCH (2) 2” Deck Check to make sure Screws structure is square PF 4056 1’’x4’’x31-1/2’’ ANGLE (2) 2” Deck Screws Flush (3) PF 4055 1’’x4’’x31-1/2’’ (3) 2-1/2”...
  • Page 22 STEP 10 (2) 2-1/2” Deck Screws (2) 2” Deck Screws (3) 2-1/2” Deck Screws per joint (3) 2” Deck Screws Frame A Check to make sure structure is square (3) 2-1/2” Deck Screws per joint 2” Deck Screw (x10) 2-1/2” Deck Screw (x20) 1.
  • Page 23 STEP 11 TIP: Flex bracket(s) to make PF 4081 installation of 2x4 easier 3’’x3’’x31-1/2’’ TOWER BEAM SUPPORT 1-1/4” COUNTERBORE HOLES ON (2) 2” Lag BOTTOM (3) 1-1/4” Lag & (2) 2” Lag per 2x4 Shelf Loc bracket PF 4078 2’’x4’’x31-1/2’’ (4) 2”...
  • Page 24 STEP 12 (2) PF 4069 2’’x4’’x16’’ Angle Brace Flush Flush 2” Lag Screw 2” Lag Screw (x2) 2-1/2” Deck Screw (x6) 1. Attach boards as shown.
  • Page 25 STEP 13 (3) PF 4050 1’’x4x25’’-1/4’’ (4) 2’’ Deck Screws per board 1/4” gap typical 1/4” gap typical (9) PF 4054 1’’x4’’x31-1/2’’ (4) 2’’ Deck Screws per board (6) PF 4054 1’’x4’’x31-1/2’’ (4) 2’’ Deck Screws per board 2” Deck Screw (x72) 1.
  • Page 26 STEP 14 PF 4122 2’’x2’’x64-3/4’’ (2) 2” Deck Center Board on pre-drilled holes of Screw Per Deck Boards Board UNDERDECK VIEW 2” Deck Screw (x36) 1. Attach board as shown.
  • Page 27 STEP 15 PF 4050 1’’x4’’x25-1/4’’ 2-1/2” Deck Screw (x4) 1. Attach boards as shown.

  • Page 28: Outside View

    STEP 16 (10) 2-1/2” Deck Screws (5) PF 4105 1’’x4’’x36’’ FENCE 30mm Deck Screws per board 1-7/16” gap typical 30mm Deck Screw (x20) 2-1/2” Deck Screw (x10) OUTSIDE VIEW 1. Attach fence board(s) as shown.
  • Page 29 STEP 17 (6) PF 4099 1’’x4’’x28’’ FENCE 30mm Deck Screws per board Install Screws from Inside of Barrier 1-7/8” gap 30mm Deck Screw (x24) OUTSIDE VIEW 1. Attach boards as shown.
  • Page 30 STEP 18 7-1/4’’ PF 4094 1’’x4’’x19’’ (5) 30 mm Deck Screws PF 4090 1’’x4’’x9-3/8’’ 2-1/2’’ Deck Screws PF 4104 1’’x4’’x34-5/8’’ 2-1/2’’ Deck (3) 2” Screws Deck Screws 2-1/2” Deck Screw (x7) 30mm Deck Screw (x5) 2” Deck Screw (x3) 1. Attach boards as shown.
  • Page 31 STEP 19 (2) PF 4099 1’’x4’’x28’’ FENCE Install Screws from Inside of Barrier 3’’ gap OUTSIDE VIEW 30mm Deck Screw (x8) 1. Attach boards as shown.

  • Page 32: Inside View

    STEP 20 2” gap typical (4) PF 4096 1’’x4’’x23’’ FENCE Install Screws from Inside of Barrier 1’’ INSIDE VIEW 30mm Deck Screw (x16) 1. Attach boards as shown.
  • Page 33 STEP 21 1-7/16” gap typical (5) PF 4096 1’’x4’’x23’’ FENCE Install Screws from Inside of Barrier 1’’ INSIDE VIEW 30mm Deck Screw (x20) 1. Attach boards as shown.
  • Page 34 STEP 22 (4) PF 4047 1’’x4’’x18’’ Sandbox Bench (4) 2’’ Deck Screws per Board 2” Deck Screw (x16) 1. Attach board(s) as shown.
  • Page 35 STEP 23 (4) PF 4063 5/4’’x4’’x10-1/2’’ Picnic Table Support (4) 2-1/2” Deck Screws 22-1/2” 12-3/8” (2) PF 4062 1’’x6’’x31-1/2’’ Picnic Table 2” Deck Screw (x8) (4) 2” Deck Screws 2-1/2” Deck Screw (x16) 1. Attach board(s) as shown.
  • Page 36 STEP 24 PF 4093 1’’x4’’x17-1/4’’ Note: (4) 2” Deck Screw through side Screws boards into steps PF 4068 5/4’’x4’’x54-3/8’’ 2” Ladder RH PF 4067 5/4’’x4’’x54-3/8’’ Ladder LH (4) PF 4114 5/4’’x4’’x16’’ 1-1/2” (3) #12 x 3/4’’ Pan Screws per side 2”...
  • Page 37 STEP 25 Window INSIDE VIEW 3/4” Flat Head Screw (x10) 1. Attach Window as shown.
  • Page 38 STEP 26 3” Deck Screw PF 4088 PF 4066 1’’x4’’x5-3/8’’ 5/4x4x27-1/4 Sunburst (2) 30mm Deck Screws 14-1/2” 9-1/8” PF 4065 9/16” 5/4x4x23-7/8 PF 4042 1x2x23-5/8 (4) 30mm Deck Screws PF 4041 (2) PF 4040 1’’x2’’x10’’ PF 4043 1’’x2’’x6’’ (3) 30mm 1’’x4’’x5-3/8’’...
  • Page 39 STEP 27 3/16” Washer #12 x 3/4” Pan Screw (2) 2-1/2” Deck Screws per joint #12 x 3/4” Pan Screw (x6) 2-1/2” Deck Screw (x8) 1. Attach Tarp to roof as shown. 2. Attach Roof as shown.
  • Page 40 STEP 28 3” Deck Screw PF 4066 5/4x4x27-1/4 14-1/4” PF 4065 PF 4042 5/4x4x23-7/8 1x2x23-5/8 (4) 30mm Deck Screws PF 4041 PF 4043 (2) PF 4040 1’’x2’’x10’’ 1’’x4’’x5-3/8’’ 1’’x2’’x6’’ (3) 30mm Sunburst (2) 30mm Deck Screws (2) 30mm Deck Screws Deck Screws 9-1/8”...
  • Page 41 STEP 29 PF 4120 2’’x2’’x25-1/4’’ (2) 2-1/2” Deck Screws (2) PF 4112 5/4’’x4’’x7’’ ANGLE 4-7/8’’ (2) 2” Deck Screws Flush (2) PF 4098 1’’x4’’x26-1/4’’ (4) 2” Deck Screws 3/16” Washer #12 x 3/4” Pan Screw 2-1/2” Deck Screw (x2) 2” Deck Screw (x12) #12 x 3/4”...
  • Page 42 STEP 30 COUNTERBORE HOLES ON TOP PF 4080 3’’x5-1/2’’x89-1/2’’ Swing Beam 5-1/4’’ Swing 5/16’’ T-Nut Hanger Beam Clamp (4) 30mm Deck Screws Correct Orientation 30mm Deck Screw (x24) 1. Attach Swing Hanger(s) to swing beam as shown.
  • Page 43 STEP 31 PF 4079 3x3x62 5/16”-18 x 6” A-Frame SB Hex Head Bolt Support 5/16” Washer 5/16” Washer 5/16” Loc Nut (2) PF 4071 2’’x4’’x83’’ A-Frame 5/16”-18 x 3-1/4” Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Washer 5/16”-18 x 4-1/2” 5/16”...
  • Page 44 STEP 32 (2) Swing Beam Bracket 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16”-18 x 3-1/2” Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam Bracket to A-Frame & Swing Beam as shown.
  • Page 45 STEP 33 5/16”-18 x 3” Beam Brace Hex Head Bolt 5/16” Washer 5/16” Loc Nut 5/16” Washer 5/16”-18 x 7-1/2” Hex Head Bolt 5/16”-18 x 5” Hex Head Bolt 5/16” Washer 5/16” Washer 5/16” Loc Nut 1. Attach Swing Beam to tower as shown.
  • Page 46 STEP 34 1/4” Washer 1/4’’ x 1-3/4” Pan Screw 11” 1-3/4” Pan Screw (x2) 1. Attach Play Handle as shown...
  • Page 47 STEP 35 1” Truss Screws 2” Grade (2) 30mm PF 4076 Deck Screws 2’’x4’’x17-1/4’’ Slide Stake 30mm Deck Screw (x2) 1” Truss Screw (x3) 1. Attach slide as shown.

  • Page 48: Design Options

    DESIGN OPTIONS For Design 1: Follow steps labeled “ ”, PB 8156 & PB 8278 “Anchor-Its”, “Swing Hangers” and “ID Tag”. PB 8156 & PB 8278 For Design 2: Follow steps labeled “ ”, “Anchor-Its”, PB 8155 “Swing Hangers” and “ID Tag”. PB 8155 For Design 3: Follow steps labeled “...
  • Page 49 PB 8156 & PB 8278 Tighten Quick Link(s) Ring Trap (2) 33” Coated chain Quick Link Quick Link “Open” “Closed” Note: For correct installation, the thread must be at the bottom 1. Assemble 33” Chain(s) to Ring Trap and attach to swing hangers as shown.
  • Page 50 PB 8156 & PB 8278 Swing Seat (2) 22” Uncoated 58” Coated chain chain Crimp “V” Hanger Crimp 1. Assemble Swing Seat(s) and attach to swing hangers as shown.
  • Page 51 PB 8155 51” Un-Coated chain Loc-Nut 5/16’’ Flat Washer QuickLink 5/16’’ Flat Washer 5/16”-18 x 6-1/2” Hex Bolt QuickLink Wind-Rider QuickLink Wind-Rider 1. Insert Seat into Handle as shown in (Step1). Secure in place with hardware shown. Note: Make certain no more than two bolt threads protrude from the Loc-Nut once fully tightened. 2.
  • Page 52 PB 8155 Swing Seat (2) 22” Uncoated 58” Coated chain chain Crimp “V” Hanger Crimp 1. Assemble Swing Seat(s) and attach to swing hangers as shown.
  • Page 53 PB 8154 (2) PF 4141 2’’x4’’x20’’ GLIDER SUPPORTS THREAD CHAIN THROUGH LOWEST TUBE Loc-Nut 5/16’’ Flat Washer (4) 30mm Deck Screws Loc-Nut 5/16’’ Flat Washer 5/16’’ Flat Washer 5/16’’ x 6-1/4’’ Hex Head Bolt 5/16’’ LocWasher 5/16’’ Flat Washer Loc-Nut (6) 2-1/2”...
  • Page 54 PB 8154 5/16’’ Loc Nut 5/16’’ Flat Washer 2’’ Hex Head Bolt 1. Center Glider Support Boards across the swing beam, mark and drill (8) 5/16” bolt holes. Secure the Glider Support Boards using two carriage bolts, washers and loc nuts per bracket as shown. 2.
  • Page 55 PB 8154 Tighten Quick Link(s) Ring Trap (2) 33” Coated chain Quick Link Quick Link “Open” “Closed” Note: For correct installation, the thread must be at the bottom 1. Assemble 33” Chain(s) to Ring Trap and attach to swing hangers as shown.
  • Page 56 PB 8154 Swing Seat (2) 22” Uncoated 58” Coated chain chain Crimp “V” Hanger Crimp 1. Assemble Swing Seat(s) and attach to swing hangers as shown.
  • Page 57 ANCHOR-ITS 5/16” Fold up Washer Anchor-It 1-1/2” Lag Strap Screw Anchor-It 5/16 x 1-1/2” Lag Screw (x4) 1. Place swing set in final location and mount Anchor-It(s) at locations circled above. 2. Twist the Anchor-It into the ground until only the loop is exposed. 3.
  • Page 58 SWING HANGERS NOTE: Make certain all Swing Hangers are properly seated in Beam Clamp slots. 1. Crimp all swing hangers closed after Swing Accessories have been attached.
  • Page 59 ID TAG Design 1 Design 2 Design 3 1/2” Pan Screw (x2) 1. Attach ID Tag as shown.
  • Page 60 Weekend support available April through Labor Day Also available on Memorial Day, Fourth of July & Labor Day Technical Support from experienced Swing-N-Slide Customer Service Representatives who have actually built a swing set themselves. © Playcore Inc. 2012 Printed in USA...
