Removable screw terminal blocks 28 – 16 AWG wire
CONTROL OUTPUTS:
4 relay outputs, SPDT Form 'C' relays 6 AMP
1 Year Warranty
MODBUS
Network allows multiple units to be connected together for distributed applications,
remote monitoring SCADA applications (optional).
FEATURES
Microprocessor Based
16 LED Indicators
2 User Push Buttons
4/20MA Input (Optional)
1 Analog Output (Optional)
8 Digital Inputs, standard
4 Form 'C' Relay Outputs
Fully User Programmable
1 ea. RS485 Ports, MODBUS
PROGRAMMING
Two user push buttons and front viewable LED indicators.
Programming the PC101S/102S is limited to:--
A) Allowing loads to alternate at the end of each cycle or:
B) Selecting a fixed cycle where the lead/lag/second lag order is fixed.
See next page for programming instructions.
(Option)
4
