PARTS DESCRIPTION:
5
2
4
1
1
Control button
3
Support foot
5
Indicator lamp
7
Temperature sensor
9
Rocker main switch
OPERATION
Note!
Since the appliance and its heating elements are slightly greased when
!
delivered, there might be a slight development of odor the first time it is used.
This is harmless and stops after a short a while. Be sure to provide for sufficient
ventilation during such time.
Warning! Ensure that there is sufficient distance from the wall, fixtures or other appli-
ances. The distance must be at least 1 m to exclude the risk of fire.
6
7
8
3
2
Front metal guard
4
Tip over switch
6
Handle
8
Filter cover
CONTROL PANEL
9
ON/OFF
Turn on/ off button.
Press once to turn on the appliance, press once again to turn off.
MODE
Press this button to select the working mode "High, Low or Eco"
OPERATION INTRODUCTION:
POWER ON/OFF AND STANDBY BUTTON INTRODUCTION:
1) Once turn on the main switch (on the back of unit), the power indicator lights up and
the product enter the standby mode.
2) Under standby mode: press the ON/OFF button once to turn on and enter the heating
mode, by the default state is low-power
low-power mode indicator lights up.
Under working mode, press the ON/OFF button once to shut down directly; (heating
element stops working immediately, and the fan stops working after 60 seconds).
Noted: under working in High and Low mode, when the ambient temperature more than
35°C, the machine will be shut down automatically.
MODE BUTTON INTRODUCTION:
1) In working condition, press the MODE button to enter the high-power mode
again to enter the ECO mode
2) Under ECO mode:
a) The appliance will work at the high heating power
temperature is lower than 18°C.
b) The device will work at low heating power
between 18°C to 25°C
heating mode and fan automatically, the
, then press once to enter the low-power mode
ECO
, when the ambient
, when the ambient temperature is
42 | 43
GB
, press
.
