- Page 1 BC65 Lawn Scarifier ORIGINAL INSTRUCTION MANUAL Manufactured by Tracmaster Ltd Before commissioning the machine, read operating instructions and observe warning and safety instructions.
- Page 2 ARTIO BC65 Lawn Scarifier Manufacturer Details Tracmaster Ltd Units 6-7 Winterpick Business Park Hurstpierpoint Road Wineham Henfield BN5 9BJ UNITED KINGDOM Tel: +44 (0)1444 247689 www.tracmaster.co.uk info@tracmaster.co.uk Machine Details ARTIO BC65 Lawn Scarifier Model: Serial No: A 5 1 -...
-
Page 3: Table Of Contents
Preparing for Use ........................6 Attaching to the Power Unit ....................6 Operating the Lawn Scarifier .....................7 Transporting...........................7 Working the BC65 Lawn Scarifier ..................7 Stopping the BC65 Lawn Scarifier ..................8 Adjusting the working height of the Scarifier for different size wheels .........8 Maintenance ..........................9 Regular Maintenance Checks ....................9... -
Page 4: Introduction
About This Manual It is crucial that you read this manual carefully and understand it. Reading and understanding this manual should prevent you from operating the BC65 incorrectly and so extend the life of the machine. This manual also contains important safety information about your machine. You must observe all safety instructions at all times. -
Page 5: What The Machine Is Designed For
The blades of the BC65 Scarifier are designed to pass through the grass ONLY - they are NOT designed to make contact with solid ground at any point during operation. -
Page 6: Specifications
ARTIO BC65 Lawn Scarifier 3.0 Specifications MACHINE Model BC65 Working Width 59cm Cartridge Types Free Swinging Fixed Spring Rake Number of Blades Direction of Rotor Rotor rotates in the same direction as travel Height Adjustment From 0mm above ground to 20mm... -
Page 7: Unpacking And Assembly
⑧ ⑦ ⑩ Unpacking Instructions The BC65 Lawn Scarifier is usually delivered on a pallet and covered with pallet wrap. Carefully remove any outer packaging. Locate and remove any cable ties or straps that secure the Scarifier to the pallet. -
Page 8: Preparing For Use
ARTIO BC65 Lawn Scarifier 5.0 Preparing for Use Attaching to the Power Unit The ARTIO BC65 Lawn Scarifier will be delivered already assembled, lubricated and ready for work. It will need to be attached to the power unit. This is achieved as follows. -
Page 9: Operating The Lawn Scarifier
Transporting To transport the BC65 Lawn Scarifier, wind the height adjuster to its highest position where the blades are the furthest from the ground. NB: ENSURE THE PTO LEVER IS NOT ENGAGED ON YOUR POWER UNIT. DO NOT ENGAGE THE PTO LEVER DURING TRANSPORTATION. -
Page 10: Stopping The Bc65 Lawn Scarifier
Adjusting the working height of the Scarifier for different size wheels The working height of the BC65 Lawn Scarifier can be modified for power units with different size wheels. -
Page 11: Maintenance
ARTIO BC65 Lawn Scarifier 7.0 Maintenance Regular Maintenance Checks Always clean the Lawn Scarifier after use. Remove any wire, string, plastic netting etc from the rotor shafts and bearings. Belt Maintenance Check the condition of the belts after the first four hours of work. -
Page 12: Gearbox Maintenance
Remove any material that could get pushed into the bearings causing damage. Rotating the Blades The BC65 features a system that allows you to remove a rod from the rotor assembly and to rotate and re insert it so that the unused side of the blades can be utilised. -
Page 13: Changing The Blades
Once the rod has been assembled and secured with a split pin, attach the rod holders of the rod assembly to the hexagonal mounting plate in the same position from which it was removed. 7.11 Storage Always store BC65 Lawn Scarifier in a clean, dry place. Page 11 BC65 Lawn Scarifier... -
Page 14: Handling
Gloves must be worn when lifting the BC65 Lawn Scarifier. When performing maintenance on the BC65 Lawn Scarifier, if it is situated on a work bench, ensure that the machine is firmly held in position at all times. Page 12... -
Page 15: Warranty
• For domestic or private use: 3 years • For commercial and hire use: 2 years Tracmaster Ltd will replace or repair, at their discretion, free of charge, any such defective material providing the machine is returned to their workshops or an Authorised Tracmaster Dealer (contact us or see www.tracmaster.co.uk). -
Page 16: Warranty Registration
If an issue develops with the machine, within the warranty period, the problem must be verfied by Tracmaster or an Authorised Tracmaster Dealer before any repair is undertaken. Any other express or implied warranty is cancelled and substituted by this Warranty, whose clauses can be modified in writing only. -
Page 17: Spare Parts
9.0 Spare Parts Parts Diagrams The spare parts diagrams and part numbers for the ARTIO BC65 Lawn Scarifier can be found on our website or by contacting our spare parts department. Spare parts can be ordered via the following methods:... -
Page 18: Service Record
ARTIO BC65 Lawn Scarifier 10.0 Service Record To ensure your machine is kept in peak condition we recommend that your ARTIO BC65 Lawn Scarifier is serviced at regular intervals. Contact Tracmaster on 01444 247689 to find out who your local Authorised Tracmaster Dealer is, or check our Dealer Locator online at www.tracmaster.co.uk. -
Page 19: Ec Declaration Of Conformity
ARTIO BC65 Lawn Scarifier 11.0 EC Declaration of Conformity Tracmaster Ltd declares that the machinery stipulated below complies with all the relevant provisions of: Machinery Directive 2006/42/EC EMC Directive 2004/108/EC and the National Laws and Regulations adopting these directives and other relevant directive. - Page 20 ARTIO BC65 Lawn Scarifier Original Instruction Manual © 2021 Tracmaster Ltd Tracmaster Ltd Units 6-7 Winterpick Business Park | Hurstpierpoint Road | Wineham | Henfield | BN5 9BJ | UK Tel: +44 (0)1444 247689 | www.tracmaster.co.uk | info@tracmaster.co.uk...
