Summary of Contents for Tracmaster ARTIO BC65
- Page 1 BC65 Lawn Scarifier Attachment Operating Instructions IMPORTANT – PLEASE READ BEFORE USE Before commissioning the machine, read operating instructions and observe warning and safety instructions.
- Page 2 Manufacturer Details Tracmaster Ltd Sovereign Centre Victoria Road Burgess Hill West Sussex RH15 9LR UNITED KINGDOM Tel: +44 1444 247689 www.tracmaster.co.uk info@tracmaster.co.uk Machine Details Model: ARTIO BC65 Lawn Scarifier Serial Number: ..........Date of Purchase: ..........Supplier: ..........
-
Page 3: Table Of Contents
Tracmaster Ltd ARTIO BC65 Lawn Scarifier Table of Contents What the Machine is Designed For ......................2 Specifications ............................3 Major Components Diagram ........................3 Preparing for Use ............................4 Hazard Pictorial Explanations ........................5 Operating the Lawn Scarifier ........................6 Transporting ............................. -
Page 4: What The Machine Is Designed For
IMPORTANT – READ CAREFULLY The blades of the ARTIO BC65 Lawn Scarifier are designed to pass through the grass ONLY - they are NOT designed to make contact with solid ground at any point during operation. -
Page 5: Specifications
Tracmaster Ltd ARTIO BC65 Lawn Scarifier Specifications MACHINE Model BC65 Working Width 590mm Max gradient for operation on slope 15 degrees Weight 65kg Dimensions (l x w x h) 82 x 77 x 50 cm Major Components Diagram Original Instructions... -
Page 6: Preparing For Use
Tracmaster Ltd Preparing for Use The ARTIO BC65 Lawn Scarifier will be delivered already assembled, lubricated and ready for work. It will need to be attached to the power unit. This is achieved as follows. BCS 738, 740, 770HY, 615SL, 630 and 630WS To attach the Lawn Scarifier to the BCS 738, 740, 770HY, 615SL, 630 and 630WS power units, couple the implement to the machine PTO and make sure the nuts are tightened securely. -
Page 7: Hazard Pictorial Explanations
Tracmaster Ltd ARTIO BC65 Lawn Scarifier Hazard Pictorial Explanations WARNING! ROTATING BLADE HAZARD. DO NOT OPERATE WITH GUARD REMOVED. ALWAYS REMOVE THE SPARK PLUG BEFORE SERVICING. ❶ ❷ ❸ ❶ READ OPERATING INSTRUCTIONS BEFORE USE. ❷ REMOVE SPARK PLUG BEFORE SERVICING OR MAINTENANCE. -
Page 8: Operating The Lawn Scarifier
ARTIO BC65 Lawn Scarifier Tracmaster Ltd Operating the Lawn Scarifier IMPORTANT: Always read all separate instruction manuals supplied with power unit before use, to ensure you are familiar with the machine’s controls. 6.1 Transporting To transport the BC65 Lawn Scarifier, wind the height adjuster to its highest position where the blades are the furthest from the ground. -
Page 9: Adjusting The Working Height Of The Scarifier For Different Size Wheels
Tracmaster Ltd ARTIO BC65 Lawn Scarifier 6.4 Adjusting the working height of the Scarifier for different size wheels The working height of the BC65 Lawn Scarifier can be modified for power units with different size wheels. The initial set of the BC65 is in the position suitable for 5x10 agricultural wheels. -
Page 10: Maintenance
ARTIO BC65 Lawn Scarifier Tracmaster Ltd Maintenance 7.1 Regular Maintenance Checks Always clean the Lawn Scarifier after use. Remove any wire, string, plastic netting etc from the rotor shafts and bearings. 7.2 Belt Maintenance Check the condition of the belts after the first four hours of work. -
Page 11: Gearbox Maintenance
Tracmaster Ltd ARTIO BC65 Lawn Scarifier Once the belts are tensioned and the gearbox frame is square, lock the position of the belt tensioning bolts using the locking nut. Tighten the four bolts that were previously loosened at each end of the gearbox frame. -
Page 12: Changing The Blades
ARTIO BC65 Lawn Scarifier Tracmaster Ltd Fig 6 NB: IT IS IMPORTANT THAT ALL 3 RODS ARE ROTATED AT THE SAME TIME TO ENSURE THAT THE ROTOR REMAINS BALANCED DURING OPERATION. Ensure that the bolts holding each rod holder onto the mounting plates are tight. -
Page 13: Replacing The Rods
Tracmaster Ltd ARTIO BC65 Lawn Scarifier Each rod can be disassembled. The first step is to remove the split pin used to contain the elements of the rod. Once this has been removed it is possible to slide the components easily off one of the rod. -
Page 14: Warranty
Ltd has not been adhered to. No liability is accepted by Tracmaster Ltd in respect of machine or component failure when it can be determined that such failure was the result of using the equipment with one or more attachments not given prior applications approval by them. -
Page 15: Ec Declaration Of Conformity
Tracmaster Ltd ARTIO BC65 Lawn Scarifier EC Declaration of Conformity Tracmaster Ltd declares that the machinery stipulated below complies with all the relevant provisions of: Machinery Directive 2006/42/EC EMC Directive 2004/108/EC and the National Laws and Regulations adopting these directives and other relevant directive. - Page 16 © 2018 Tracmaster Ltd Sovereign Centre, Victoria Road, Burgess Hill RH15 9LR Tel: +44 (0) 1444 247689 www.tracmaster.co.uk...
