KCOMBO-7
OPERATOR'S MANUAL
GPS  CHART  PLOTTER  WITH  FISHFINDER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KCOMBO-7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Onwa KCOMBO-7

Summary of Contents for Onwa KCOMBO-7

  • Page 1 All manuals and user guides at all-guides.com KCOMBO-7 OPERATOR'S MANUAL GPS  CHART  PLOTTER  WITH  FISHFINDER...
  • Page 2 Continued use of the equipment can cause fire or electrical shock.Contact Connection of an incorrect power supply can cause fire or equipment ONWA agent for service. damage. Use the proper fuse. Use the proper fuse. Use of a wrong fuse can damage the equipment or cause fire.

  • Page 3: Table Of Contents

    All manuals and user guides at all-guides.com CONTENTS FOREWORD  MAIN  PERFORMANCE  AND  SPECIFICATIONS CONFIGERATION  1   OPERATION  OVERVIEW Keypad instruction 1.2 Turning ON and OFF Power 1.3 Adjusting Brilliance and DIM Display Modes 2   PLOTTER  DISPLAY  OVERVIEW Choosing the Display Range Moving the Cursor 2.3 Panning the PLOTTER Display 2.4 Centering Own Ship's Position...
  • Page 4 All manuals and user guides at all-guides.com 4   WAYPOINT/MOB 4.1 Entering Waypoints 4.2 Entering the MOB Mark 4.3 Displaying Waypoint Name 4.4 Operation on the Waypoint Editing 4.5 Erasing Waypoints 5  ROUTES 5.1 Creating Routes 5.2 Editing Routes 5.3 Erasing Routes 6  ...
  • Page 5 All manuals and user guides at all-guides.com 8.4 Editing Drawing Marks 8.5 Editing Drawing Lines 8.6 Editing Drawing Place Name 8.7 Erasing Drawing Marks 8.8 Erasing Drawing Lines 8.9 Erasing Drawing Place Name 9   OTHER  SETTING 9.1 Map Scale 9.2 Unit of Measurement 9.3 Bearing Reference 9.4 Magnetic Variation 9.5 Deviation...
  • Page 6 All manuals and user guides at all-guides.com 11   ECHO  SOUNDER  OVERVIEW 11.1 Sonar mode 11.2 Gain 11.3 Range 11.4 TVG 11.5 Pic. Advance 11.6 Split ratio 11.7 Sonar Menu 11.8 Alarm 11.9 System Menu 11.10 Data Field 12  INSTALLATION 13   INTERCONNECTION  DIAGRAW 14  ...

  • Page 7: Foreword

    All manuals and user guides at all-guides.com FOREWORD The KCOMBO ONWA GPS PLOTTER aid are specially designed for the vessel traffic management, ONWA is a professional brand of the domestic and foreign navigation products. The products are designed to be all-sealed and waterproof, can be rapid position-fixing and resistant to poor environment.

  • Page 8: Main Performance And Specifications

    Degree of minutes and UTM Position format Basemap Built-in Onwa K-Chart External Map SD Cards slot for C-Map MAX and ONWA K-Chart User data storage Internal backup of user settings, or external SD-card Plot Interval 5s to 60min 0.01nm to 10nm Automatic way Plotting scales 0.001nm to 1000nm...
  • Page 9 All manuals and user guides at all-guides.com Power  Supply 10.5 to 35VDC, current drain<1.0A at 12V Physical Size: 243mm(H)X155mm(W)X82mm(D) Weight: 0.6kg Display: 7-inches ColorTFT day-view LCD 800 600 pixels Input & Output Port: one opto-isolated input Port one RS232 Output Port Waterproofing: Display unit: IPX5 Temperature range:...
  • Page 10 - 600W Bronze NMM40-50/200 - 600W Plastic NBM40-50/200 - 600W Airmar Bronze Transducer w/Temp seosor B45 Dual Frequency Transom Mount Transducer - 600W Onwa Transducer w/Temp seosor KTD-520_TM - 600W Airmar transducer w/Temp seosor P58 3) Temperature seosor Onwa Thru-Hull temperature seosor KTS-10K_TH...
  • Page 11 All manuals and user guides at all-guides.com HD  Fishfinder  Characteristics Echo Color 16 colors (including background color) according to echo intensity. The background color is selectable from blue, light blue, white and black. Basic Range Meters 5/10/20/40/80/150/200/300/600/1000 Feet 15/30/60/120/200/400/600/1000/2000/3000 Fathoms 3/5/10/20/40/80/100/150/300/600 Range Shift 80 meters, 200 feet, 100fathoms Zoom Range...

  • Page 12: Configeration

    All manuals and user guides at all-guides.com CONFIGERATION KA-07 (Optional) 10M or 15M Transducer (Optional) Display Unit...

  • Page 13: 1   Operation  Overview

    All manuals and user guides at all-guides.com 1. OPERATION OVERVIEW 1.1 Keypad instruction Plotter function: Moving the cursor upward or to change the setting. Sounder function: Moving the VRM upward. Plotter function: Moving the cursor to the right. Sounder function: Long Press - Activates feeding rate selection for picture advancement Short Press - Setting the depth range (setting upper range limit).

  • Page 14: Turning On And Off Power

    All manuals and user guides at all-guides.com 1.2  Turning  ON  and  OFF  Power Turning on the power ONWA Press the key. The unit beeps and displays the " " logo. After a few seconds, it starts up with the last used display mode.

  • Page 15: Display Modes

    All manuals and user guides at all-guides.com 1.4  Display  Modes Your unit has eleven display modes: PLOTTER SCREEN, NAVIGATOR SCREEN WIND SCREEN, POSITION SCREEN, SATELLITE SCREEN , HIGHWAY SCREEN, AIS SCREEN , SOUNDER SCREEN and PLOTTER + SOUNDER SCREEN. Press the [MODE] key to choose a display mode.

  • Page 16: Plotter Display Overview

    All manuals and user guides at all-guides.com 2. PLOTTER DISPLAY OVERVIEW 2.1  Choosing  the  Zoom  Display  Range You may press to Zoom In and to Zoom Out as desired on the PLOTTER display. 2.2  Moving  the  Cursor Press the cursor pad to move the cursor. The cursor moves in the direction of the pressed arrow.

  • Page 17: Panning The Plotter Display

    All manuals and user guides at all-guides.com 2.3  Panning  the  PLOTTER  Display Using the cursor, pan left, right, up or down on your desired area. Place the cursor at the edge of the screen to start panning. The display shifts in the direction opposite to cursor pad operation.

  • Page 18: Map

    All manuals and user guides at all-guides.com 2.6 Map 1. Press [ MENU ] key in PLOTTER screen. 2. Choose and then press [ ] key to select. 3. Choose the layer ON or OFF as desired and then press [ "...

  • Page 19: Heading Line

    All manuals and user guides at all-guides.com 4. Choose the layer "ON" as desired and then press [ ] key to finish. 5. Choose the layer "OFF" as desired and then press [ ] key to finish. 2.8  Heading  Line 1.

  • Page 20: Cursor

    All manuals and user guides at all-guides.com 4. Heading Line option: "COG Time Line" selection The length of heading line will vary according to the SOG to show the estimated point of destination after the set period. Example, if you set the COG Time Line to 10 minutes then the length of the heading line will point to the position that your boat will reach after 10 minutes.

  • Page 21: Ship Shape/Color

    All manuals and user guides at all-guides.com 2.10  Ship  shape/color 1. Press [MENU] key in PLOTTER screen. 2. Choose Ship shape/color and then press [ENT] key to select. Press [ ] key and then press [ENT] 2.11  Range  Circle 1. Press [MENU] key in PLOTTER...

  • Page 22: Drawing

    All manuals and user guides at all-guides.com 2.12  Drawing 1. Press [MENU] key in PLOTTER screen. 2. Choose Drawing and then press [ENT] key to select. 3. Choose "Mark" "Line" or "Place name" as desired and then press [ ] key to finish.

  • Page 23: Palette

    All manuals and user guides at all-guides.com 5. User can change the size of Drawing Lines. 2.13 Palette 1. Press [ MENU ] key in PLOTTER screen. 2. Choose Palette and then press [ ] key to select. 3. Choose "Normal ", "Daylight , "Night"...

  • Page 24: Map Direction

    All manuals and user guides at all-guides.com 2.14  Map  Direction 1. Press [MENU] key in PLOTTER screen. 2. Choose Map Direction and then press [ENT] key to select. 3. Choose Normal , " " " North Up , " " WPT Up or "...

  • Page 25: Track

    All manuals and user guides at all-guides.com 3. TRACK 3.1  Changing  Track  Plotting  Interval,  Stop  Plotting When the track memory becomes full, the oldest track is erased to make room for the latest. 1. Press the [MENU] key twice to enter main menu. 2.

  • Page 26: Displaying The Track

    All manuals and user guides at all-guides.com 3.2  Displaying  the  Track 1. Press [MENU] key in PLOTTER screen. 2. Choose Track and then press key to select. 3. Choose the color and if you want to turn it ON or OFF . "...

  • Page 27: Erasing Track

    All manuals and user guides at all-guides.com 3.4  Erasing  Track 1. Press [MENU] key twice to enter main menu. 2. Choose Erase and then press key to select. 3. Choose Current track Saved track 4. If Saved track is chosen, press key to choose the color that you want to erase or choose if you want to erase all tracks and then press...

  • Page 28: 4   Waypoint/Mob

    All manuals and user guides at all-guides.com 4. WAYPOINT/MOB 4.1  Entering  Waypoints Waypoints can be entered on the PLOTTER display in three ways: by cursor position, at own ship's position, and from the waypoint edit. Entering a waypoint with the cursor 1.
  • Page 29 All manuals and user guides at all-guides.com Entering a waypoint from the waypoint list 1. Press the [MENU] key twice to enter main menu. 2. Choose Edit and then press key to select. 3. Choose Waypoint and then press [ ] key.

  • Page 30: Entering The Mob Mark

    All manuals and user guides at all-guides.com 4.2  Entering  the  MOB  Mark Only one MOB mark may be entered. Each time the MOB mark is entered, the previous MOB mark and its position data are over-written. 1. Long press the [MOB] key on any display mode.

  • Page 31: Operation On The Waypoint Editing

    All manuals and user guides at all-guides.com 4. User can change the size of Waypoint Marks 4.4  Operation  on  the  Waypoint  Editing Waypoint position, waypoint name, mark shape, mark color and comment can be edited from the Waypoint Edit. 1. Press the [ MENU ] key twice to enter main menu.

  • Page 32: Erasing Waypoints

    All manuals and user guides at all-guides.com 4.5  Erasing  Waypoints 1. Press the [MENU] key twice to main menu. 2. Choose Edit and then press key to select. 3. Choose Waypoint and then press the [ENT] key. The following window will appear.

  • Page 33: 5  Routes

    All manuals and user guides at all-guides.com 5. ROUTES 5.1  Creating  Routes 1. Press [MENU] key twice to enter main menu. 2. Choose Edit and then press key to select. 3. Choose Route and then press [ENT] key. The following window will appear. 4.
  • Page 34 All manuals and user guides at all-guides.com 5. Use [ ] or [ ] to enter the route name and then press [ ] key to finish. The following will appear. 6. Choose the location (e.g. 01) and then press [ ] key.

  • Page 35: Editing Routes

    All manuals and user guides at all-guides.com 5.2  Editing  Routes Replacing waypoints in a route 1. Press the [MENU] key twice to enter main menu. 2. Choose Edit and then press key to select. 3. Choose Route and then press [ENT] key to select.

  • Page 36: Erasing Routes

    All manuals and user guides at all-guides.com Permanently deleting a waypoint from a route 1. Press the [MENU] key twice to enter main menu. 2. Choose Edit and then press the key to select. 3. Choose Route and then press [ENT] key to select.
  • Page 37 All manuals and user guides at all-guides.com 4. Select a route then press [ENT] key. 5. The confirm window will appear. Choose "ERASE " and then press [ENT] key. 6. Choose " " and then press [ ] key to finish. Erase All Routes 1.

  • Page 38: Destination

    All manuals and user guides at all-guides.com 6. DESTINATION 6.1  Setting  Destination  by  Cursor 1. Press key to display the FUNCTION window. 2. Choose Goto cursor and then press [ENT] key to select. 3. The cursor appears with ? . "...

  • Page 39: Setting Destination By Waypoint (Wpt)

    All manuals and user guides at all-guides.com 6.2  Setting  Destination  by  Waypoint  (WPT) 1. Press the key to display the FUNCTION window. 2. Choose Goto WPT and then press [ ] key to select. WAYPOINT 3. The list appears. 4. Choose a waypoint and then press [ ] key to finish.
  • Page 40 All manuals and user guides at all-guides.com 3. The ROUTE list appears. 4. Choose a route and then press [ ] key. The following window appears. 5. Choose Forward or Reverse in order to traverse the waypoints in the route, and "...

  • Page 41: Setting Track Data As Destination

    All manuals and user guides at all-guides.com 6.4  Setting  Track  Data  as  Destination Track Data can be used for navigation. 1. Press the key to display the FUNCTION window. 2. Choose Goto track and then press the [ENT] key to select. 3.

  • Page 42: Canceling Destination

    All manuals and user guides at all-guides.com Once a Goto track has been activated, the track will divide it into segments. Up to 200 temporary waypoints are created (named T1,T2, T3, etc. and END) to mark the most significant features of the track, duplicating your exact path as closely as possible.

  • Page 43: Distance

    All manuals and user guides at all-guides.com 6.6  Distance Measure the distance of several points and save it as a route. PLOTTER FUNCTION 1. Press key in screen to display window. 2. Select " Distance " and press [ENT] key to activate the distance measurement function.
  • Page 44 All manuals and user guides at all-guides.com 6. Move the cursor to the next point (C). Now the BRG and LEG displays the Bearing and Distance from point B to point C. DIST displays the total distance from point A to point B. 7.

  • Page 45: Alarm

    All manuals and user guides at all-guides.com 7. ALARM There are six alarm conditions which generates both audio and visual alarms: Arrival alarm Anchor drag alarm XTE (Cross-Track Error) alarm Speed alarm Voltage alarm Timer alarm When the alarm setting is violated, the buzzer sounds and the name of the offending alarm and the alarm icon appears on the display.

  • Page 46: Arrival Alarm

    All manuals and user guides at all-guides.com 3. Choose Anchor and then press [ ] key. The alarm options appear. 4. Press [ ] key to select the alarm value and then press [ ] key to setup the value. 5.

  • Page 47: Xte (Cross-Track Error) Alarm

    All manuals and user guides at all-guides.com 7.3  XTE  (Cross-Track  Error)  Alarm XTE (Cross-Track Error) Alarm warns you when own ship is off its intended course. 1. Press [MENU] key twice to enter main menu. 2. Choose Alarm and then press key to display ALARM menu.

  • Page 48: Voltage Alarm

    All manuals and user guides at all-guides.com 7.5  Voltage  Alarm Voltage Alarm warns you when the input voltage in the unit is higher than the set value. 1. Press [ MENU ] key to enter main menu. 2. Choose Alarm and then press [ ] key to display ALARM menu.

  • Page 49: Buzzer Type Selection

    All manuals and user guides at all-guides.com 7.7  Buzzer  Type  Selection The buzzer sounds whenever an alarm setting is violated. 1. Press the [MENU] key twice to enter main menu. 2. Choose Alarm and then press key to select. 3. Choose Buzzer and then press key to select.

  • Page 50: Drawing

    All manuals and user guides at all-guides.com 8. DRAWING 8.1  Drawing  Marks 1. Press [ ] key to display the FUNCTION window. 2. Choose Drawing and then press [ ] key to select. 3. Choose Mark and then press [ ] key.

  • Page 51: Drawing Lines

    All manuals and user guides at all-guides.com 8.2 Drawing Lines 1. Press [ ] key to display the FUNCTION window. 2. Choose Drawing and then press [ ] key to select. 3. Choose Line and then press [ ] key. The cursor appears with "+?" on the PLOTTER screen.

  • Page 52: Editing Drawing Marks

    All manuals and user guides at all-guides.com 8.4  Editing  Drawing  Marks [MENU] 1. Press key twice to enter main menu. 2. Choose Edit and then press key to select. 3. Choose Drawing marks and then press [ENT] key. The following window appears. 4.

  • Page 53: Editing Drawing Lines

    All manuals and user guides at all-guides.com 8.5 Editing Drawing Lines 1. Press [ MENU ] key twice to enter main menu. 2. Choose Edit and then press [ ] key to select. 3. Choose Drawing lines and then press [ ] key. The following window appears.

  • Page 54: Editing Drawing Place Name

    All manuals and user guides at all-guides.com 8.6  Editing  Drawing  Place  Name 1. Press [ MENU ] key twice to enter main menu. 2. Choose Edit and then press [ ] key to select. 3. Choose Drawing placename and then press [ ] key.

  • Page 55: Erasing Drawing Marks

    All manuals and user guides at all-guides.com 8.7 Erasing Drawing Marks 1. Press [MENU] key twice to enter main menu. Edit 2. Choose and then press key to select. 3. Choose Drawing marks and the press [ENT] Key. 4. Choose the mark that you want to clear, and then press [ENT] key.

  • Page 56: Erasing Drawing Lines

    All manuals and user guides at all-guides.com 8.8  Erasing  Drawing  Lines 1. Press [MENU] key twice to enter main menu. 2. Choose Edit and then press key to select. 3. Choose Drawing lines and the press [ENT] key to select. 4.

  • Page 57: Erasing Drawing Place Name

    All manuals and user guides at all-guides.com 8.9 Erasing Drawing Place Name 1. Press [MENU] key twice to enter main menu. Edit 2. Choose and then press key to select. 3. Choose Drawing placename and then press [ENT] key to select. 4. Choose the place name that you want to erase, and then press [ENT] key.

  • Page 58: 9   Other  Setting

    All manuals and user guides at all-guides.com 9. OTHER SETTING 9.1  Map  Scale You can change the map scale display format. 1. Press [MENU] key twice to enter main menu. Setup 2. Choose and then press key to select. 3. Choose Map scale and then press [ ] key to select.

  • Page 59: Bearing Reference

    All manuals and user guides at all-guides.com Depth Unit 1. Press [MENU] key twice to enter main menu. 2. Choose Setup and then press key to select. Depth unit [ENT] 3. Choose and then press key to select. 4. Choose "f eet , "...

  • Page 60: Magnetic Variation

    All manuals and user guides at all-guides.com 9.4  Magnetic  Variation The location of the magnetic North Pole is different from the geographical North Pole. This causes a difference between the true and magnetic north direction. This difference is called magnetic variation, and varies with respect to the observation point on earth.

  • Page 61: Deviation

    All manuals and user guides at all-guides.com 9.5  Deviation You can input the deviation of the ship or map manually to correct the position error from GPS error or map error. 1. Press [ MENU ] key twice to enter main menu. 2.

  • Page 62: Ttg/Eta Speed

    All manuals and user guides at all-guides.com 9.7  TTG/ETA  speed To calculate time-to-go and estimated time of arrival, enter your speed as below. 1. Press the [MENU] key twice to enter main menu. 2. Choose Setup and then press key to select. 3.

  • Page 63: Gps Setting

    All manuals and user guides at all-guides.com 4. Choose and then press [ ] key to finish. The following message appears 9.10  GPS setting 9.10.1  Choosing  GPS  output  data The unit s default is using an internal GPS module for position fixing. On the other hand, you can use external GPS data for position fixing.
  • Page 64 All manuals and user guides at all-guides.com 9.10.2  Datum  setting You can choose 6 types of data output at the same time. 1. Press [MENU] on the SATELLITE screen. 2. Choose Datum and press [ENT] key to select. 3. Choose your desired datum and press [ ] key to confirm.

  • Page 65: Nmea Data Display

    All manuals and user guides at all-guides.com 9.11  NMEA  data  display 1. Press [ MENU ] key twice to enter main menu. 2. Choose Setup and then press [ ] key to select. 3. Choose NMEA data display and then press [ ] key.

  • Page 66: 10  The  Ais Funtion

    All manuals and user guides at all-guides.com 10. THE AIS FUNCTION 10.1   Vessels  list 1. Press [MENU] on the screen. 2. Choose AIS detail list and then press [ ] key. The AIS SHIP LIST window will appear. 10.2   The  collision  alarm 1.

  • Page 67: Own Ship's Information

    All manuals and user guides at all-guides.com 10.3  Own  ship's  information There are two ways to display Own Ship Info " " 1. Enter the "Vessels list" , and press the [MENU] key, and then select the " Ship Info "...

  • Page 68: View Ais Vessels' Information On Chart Screen

    All manuals and user guides at all-guides.com 10.5   View  AIS  vessels'  information  on  chart  screen There are two ways to view AIS vessels' information: one is to move the cursor to select AIS vessel on the charts screen, and press the [ ] key.

  • Page 69: Emergency Alarm

    All manuals and user guides at all-guides.com 10.7  Emergency  alarm The information of the emergency alarm received is displayed on the bottom right corner. The emergency alarm is always available and can not be deleted, if the emergency alarm information is not read, after exiting the alarm menu, the "emergency alarm"...

  • Page 70: Ais Vessel

    All manuals and user guides at all-guides.com 10.9  AIS  Vessel 1. User can define the AIS vessel display as either " Fill " " Line " Fill Line...

  • Page 71: 11   Echo  Sounder  Overview

    All manuals and user guides at all-guides.com 11. HD FISHFINDER OVERVIEW 11.1  Sonar  mode 1. Press [MENU] key in SOUNDER screen. 2. Choose Sonar mode and then press [ENT] key or press and hold [MODE] key in the SOUNDER screen. The following window will appear. MODE Function Provides the high frequency (200KHz)normal picture on the full screen.
  • Page 72 All manuals and user guides at all-guides.com 200KHz, 50KHz (high frequency, low frequency) mode The sounder uses ultrasonic pulses to detect bottom conditions. The lower the frequency of the pulse the wider the detection area. Therefore, the 50KHz frequency is useful for general detection and judging bottom conditions, while the 200KHz frequency is useful for detailed observation of fish schools.

  • Page 73: Gain

    All manuals and user guides at all-guides.com 11.2  Gain [MENU] SOUNDER 1. Press key in screen. 2. Choose Gain and then press [ENT] key, or press [ENT] key in the SOUNDER screen to adjust gain manually. The following window will appear. 3.

  • Page 74: Tvg

    All manuals and user guides at all-guides.com 11.4  TVG 1. Press [MENU] key in SOUNDER screen. 2. Choose and then press [ENT] key. The following window will appear. 3. Choose " " " Manual " as desired then press [ENT] key.

  • Page 75: Pic. Advance

    All manuals and user guides at all-guides.com 11.5  Picture  advance The picture advance speed determines how quickly the vertical scan lines run across the screen. 1. Press [MENU] key in SOUNDER screen. 2. Choose Pic. advance and then press [ENT] key or press and hold key in SOUNDER...

  • Page 76: Sonar Menu

    All manuals and user guides at all-guides.com 11.7  Sonar  Menu 1. Press [MENU] key in SOUNDER screen. 2. Choose Sonar menu and then press [ENT] key. The following window will appear. 11.7.1 A-Scope 1. Press [MENU] key in SOUNDER screen. 2. Choose Sonar menu and then press [ENT]...
  • Page 77 All manuals and user guides at all-guides.com 11.7.2 Zoom modes 1. Press [MENU] key in SOUNDER screen. 2. Choose Sonar menu and then press [ENT] key to select. Zoom mode [ENT] 3. Choose and then press key. The following window will appear. "Marker Zoom"...
  • Page 78 All manuals and user guides at all-guides.com BOTTOM LOCK This display provides a compressed normal picture on the top 2/3 of the screen and a 5 or 10 meter (10 or 20 feet) wide layer in contact with the bottom is expanded onto the bottom 1/3 of the screen.
  • Page 79 All manuals and user guides at all-guides.com 11.7.3 Noise limiter Light-blue dots may appear over most of the screen. This is mainly due to unclean water or noise. This noise can be suppressed by adjusting Clutter on the menu. 1. Press [MENU] key in SOUNDER screen.
  • Page 80 All manuals and user guides at all-guides.com 11.7.5 Signal level 1. Press [MENU] key in SOUNDER screen. 2. Choose Sonar menu and then press [ENT] key to select. 3. Choose Signal level and then press [ENT] key. The following window will appear. 4.

  • Page 81: Alarm

    All manuals and user guides at all-guides.com 11.8  Alarm 1. Press [MENU] key in SOUNDER screen. 2. Choose ALARM and then press [ENT] key. The following window will appear. 3. Press [] or [] key to select an alarm. 4. Press [ ] key to select "OFF", "ON", "IN"...

  • Page 82: System Menu

    All manuals and user guides at all-guides.com 11.9  System  Menu 1. Press [MENU] key in SOUNDER screen. 2. Choose System menu and then press [ENT] key. The following window will appear. RANGE 1- 10: Activates or deactivates specific range scales. Default ranges are 5, 10, 20, 40, 80, 150, 200, 300, 600, and 1000 (meters).

  • Page 83: Data Field

    All manuals and user guides at all-guides.com 11.10  Data  field 1. Press [MENU] key in SOUNDER screen. 2. Choose Data field and then press [ENT] key. The following window will appear. 3. Data field setup The Data Field will appear on the right-side of the screen. The black area is the data area of which may be changed.

  • Page 84: 12  Installation

    All manuals and user guides at all-guides.com 12. INSTALLATION Control/Display Unit Mounting Bracket Notice: The unit should be mounted on a flat, solid surface for maximum stability. Be sure to fix the mounting bracket with screws. Otherwise, the display unit may fall down by the boat s pitching and rolling to the lead to the fire or the injury.

  • Page 85: 13   Interconnection  Diagraw

    All manuals and user guides at all-guides.com 13. INTERCONNECTION DIAGRAM DATA INPUT/OUTPUT NMEA0183 IN+ (Orange) GPS ANTENNA NMEA0183 IN (Yellow) Power +(Red) ONWA Ignition_On (Brown) NMEA0183 OUT+ <RS-232> (White) Engineer Port (Blue) Built-in GPS antenna DC5V OUT (Green) Power (Black)/Shield...

  • Page 86: 14   Display  Size

    All manuals and user guides at all-guides.com 14. DISPLAY SIZE...

  • Page 87: 15   Shortcuts

    All manuals and user guides at all-guides.com 15. SHORTCUTS Shortcuts  in  Plotter  screen 1) Press and hold [ MODE ] to change the track color. 2) Press and hold [ ] to turn track record on and off. 3) Press and hold [ ] to activate the User Mark drawing function.

  • Page 88: 16   Data  In/Out   Description

    All manuals and user guides at all-guides.com 16. DATA IN/OUT DESCRIPTION NMEA0183 IN+ NMEA Input & AIS input from external equipment NMEA0183 IN Power + Ignition_On (Brown) Ignition Ignition Switch POWER-/GND 10.5~35VDC NMEA0183 OUT+(RS-232) NMEA 0183 output to external equipment Engineer Port DC5V OUT DC 5V OUT...

  • Page 89: 17   Menu  Tree

    All manuals and user guides at all-guides.com 17. MENU TREE MAIN TRACK TIME: 5S/ TRACK RECORD MODE ( TIME/DISTANCE/AUTO/OFF) MENU RECORD 10S 30S/1min/ 5min/10min/ SAVED TRACK(... 30min/60min SAVE CURRENT TRACK(SAVE/EXIT) DISTANCE: SET UP MAP SCALE (MILES/RATIO) SPEED UNIT(NM,KT /KM,KMH/SM,KPH) DEPTH UNIT(FEET /FATHOM/METER) BRG REF.( TRUE/MAGNETIC) MAG REF.
  • Page 90 All manuals and user guides at all-guides.com MAIN ALARM ANCHOR MODE: (ON/OFF) MENU CONTINUE DISTANCE: 0.50 ARRIVAL MODE: (ON/OFF) DISTANCE: 0.50 MODE: (ON/OFF) DISTANCE: 0.50 SPEED MODE: (HI/LO/OFF) SPEED: 20.0 MODE: (ON/OFF ) VOLTAGE VOLT: 8.50 TIMER MODE: (ON/OFF ) TIME : 050 BUZZER MODE: (SHORT/LONG/CONST)
  • Page 91 All manuals and user guides at all-guides.com FUNCTION GOTO CURSOR( G OTO CURSOR FUNCTION ) GOTO WPT(GOTO WPT FUNCTION ) GOTO ROUTE(GOTO ROUTE FUNCTION ) GOTO TRACK(GOTO TRACK FUNCTION ) STOP GOTO(TURN OFF GOTO) DRAWING(MARK,NAME,LINE ) TIDE TABLE (TIDE TABLE FUNTION) SEARCH(SEARCH FUNCTION ) CALENDAR PLOTTER...
  • Page 92 All manuals and user guides at all-guides.com MENU TRACK COLOR 1 (ON/OFF) COORDIMATE (N/E/UTM) PLOTTER COLOR 2 (ON/OFF) PLACE NAME ( ON/OFF) COLOR 3 (ON/OFF) NAME TAGS ( ON/OFF) COLOR 4 (ON/OFF) NAV AIDS/LIGHTS (ON/OFF) COLOR 5 (ON/OFF) ATTENTION AREA (ON /OFF) COLOR 6 (ON/OFF) TIDES/CURRENTS ( O N/OFF) COLOR 7 (ON/OFF)
  • Page 93 All manuals and user guides at all-guides.com POSITION MENU -POS DATA FIELD HDOP BEARING RANGE TIME VOLTAGE DESTI N ATION DATE LUNAR DATE NORTH UP / WPT UP/BOW UP MENU-NAV POSITION HDOP SETUP DATA FIELD BEARING RANGE TIME VOLTAGE DESTINATION DATE LUNAR DATE...
  • Page 94 All manuals and user guides at all-guides.com MENU -AIS ACTIVATION RING (05.00NM) CPA LIMIT (05.00NM ) TCPA LIMIT (10MIN) CPA/ TCPA ALARM (ON/OFF ) STATUS AIS SHIP LIST MENU -SAT INPUT(INTER NAL/EXTERNAL) OUTPUT( OFF/NO GGA,GLL,RMC BUAD RATE(4800/9600/19200/38400) DATUM(WGS84 /LISTING) GPS SBAS(OFF/ON) POS SMOOTH ( 0 10) SOG SMOOTH( 0 60)

  • Page 95: 18   Abbreviations

    All manuals and user guides at all-guides.com 18. ABBREVIATIONS Abbreviations Word Escape Enter Satellite-based augmentation system SBAS Position Speed Over Ground Course Over Ground Apparent Wind Speed Apparent Wind Angle True Wind Speed True Wind Angle True Wind Direction Velocity Made Good Information INFO Latitude...

  • Page 96: 19   Glossary

    All manuals and user guides at all-guides.com 19. GLOSSARY (AIS) Regional Assignment Channel Assignment Message Acknowledgement (AIS) Channel management information source messages AFSK Auto frequency-shift keying (AIS) Alarm Message A to N Aid to Navigation Automatic Identification System BIIT Built In Integrity Testing Bayonet fitting type Therefore connector Course over Ground Carriage Return...
  • Page 97 All manuals and user guides at all-guides.com MMSI Maritime Mobile Service ldentity Maximum Permissible Exposure NMEA National Marine Electronics Association Personal Computer Presentation Interface Radio Frequency RTCM Radio Technical Commission for Maritime Services Commission Receive or Receiver Radio Frequency Interference Specific Absorption Rate SELV Separated Extra Low Voltage...
  • Page 98 All manuals and user guides at all-guides.com...
