Summary of Contents for InWin N127
- Page 1 User Manual...
- Page 2 Product Video Information 127 / N127 Product Video...
-
Page 3: Table Of Contents
content Product Stor y .........04 Specifications .........05 Package Contents ........06 Case Structure ........08 Cable Information ........10 Installation Guide ........11 Notices and Warranty ......19... -
Page 4: Product Story
Product Story The N127 features a Nebula front panel that is filled with crystal, shimmering stars, creating a dazzling display, while the 127 has a subtle ARGB logo, greeting users with a modest pop of color. The steel mesh front panel... -
Page 5: Specifications
2 x 2.5" Air Cooling Fans: Front: 2 x 120 mm Rear: 1 x 120 mm Bottom: 3 x 120 mm (N127 has one pre-installed Luna AL120 Fan) Thermal Solution Compatibility Water Cooling Radiator: Front: 1 x 240 mm Rear: 1 x 120 mm... - Page 6 Connector (Fan to Fan) Non-Modular Cables Connector to M/B 4-Pin (PWM, 12V), 3-Pin (ARGB, 5V) Noise Level 25 dB(A) (Normal) Bearing Type Long Lifespan Sleeve Bearing * InWin’s products comply with RoHS regulations. * Specifications may vary based on different regions.
-
Page 7: Package Contents
Package Contents 127 Chassis N127 Chassis QR Code Card Accessories Bag Motherboard Motherboard Hexagon Head Screws Stand-Offs Stand-off Socket x 18 2.5"HDD Screws Washer Cable Ties x 12 x 10 Graphics Card ARGB One-Click Anti-Sag Support Controller... -
Page 8: Case Structure
Case Structure Power Button USB 3.2 Gen 1 Audio Ports (Earphone and Microphone) USB 3.2 Gen 2x2 Type-C 3.5" / 2.5" Drive Bays Rear Fan / Radiator Mounting Area Bottom Fan / Radiator Mounting Area Front Fan / Radiator Mounting Area Motherboard Mounting Area PCI-E Expansion Slots Extra PCI-E Supporting Mounting Hole... - Page 9 Case Structure Fan Dust Filter 2.5" Drive Bays Power Supply Mounting Area...
-
Page 10: Cable Information
Cable Information Power Switch HD Audio USB 3.2 Gen 1 USB 3.2 Gen 2x2 Type-C ARGB Cable... -
Page 11: Installation Guide
Installation Guide * Please follow the related chapters to assemble. * Please use original provided accessories to avoid damage to the product. Opening the tempered glass side panel Press the Quick-Release Button to remove the tempered glass side panel. Caution: Be aware of possible sudden releases of the glass panel when opening it. - Page 12 Installation Guide Removing the Dust Filter and Graphics Card Holder It is recommended to remove the Graphics Card Holder when installing/removing your motherboard or graphics card. Motherboard Installation Parts Required: Motherboard Stand-Offs, Motherboard Stand-Off Socket, Hexagon Head Screws...
- Page 13 Installation Guide Expansion Card Installation Parts required: Hexagon Head Screws, GPU Anti-Sag Support *There are multiple ways to install the GPU Anti-Sag Support. *Please consider that the installation of the bracket may affect the placement of the bottom fans/radiator and other components of your build. *Use the adjustable GPU Anti-Sag Rubber Pad to eliminate friction between your Expansion Card and the bracket.
- Page 14 Installation Guide I/O Wires Installation HD Audio Header PORT2_L BLUE PURPLE PORT2_R YELLOW WHITE PORT1_R PORT1_L BLACK USB 3.2 Gen 1 USB 3.2 Gen 2x2 Type-C...
- Page 15 Installation Guide Front Panel ARGB Cable If your motherboard does not support ARGB effects, please use the included ARGB One-Click Controller. ARGB Cable Header ARGB One-Click Controller PSU's SATA Cable 2.5"/ 3.5" Drive Bays Installation...
- Page 16 Installation Guide 2.5" Drive Bays Installation Parts required: 2.5" HDD Screws...
- Page 17 Installation Guide Removing the Front Fans Mounting Bracket Remove the screws. Gently lift the bracket and slide it out. Attach the fans/radiator to the mounting bracket and secure the bracket back in the chassis.
- Page 18 Installation Guide Fan / Liquid Cooling Radiator Installation Parts required: Water-cooling System Washers...
-
Page 19: Notices And Warranty
Warranty 1. For more detailed warranty information, please visit the InWin retail website at www.in-win.com. 2. The actual product is subject to change without prior notice. - Page 20 Copyright © 2022 In Win Development Inc. All Rights Reserved.
