FLUID LEVEL CHECK USING PUSHBUTTON OR LEVER
SHIFT SELECTOR
1
MODE
2
3
4
5
D
N
R
SIX-SPEED,
LEFT-HAND
LEVER
SELECTOR
*
NOTE: Number displayed is highest forward range available in selected position.
Visually check to confirm range selected. If display is flashing, shift is inhibited.
Figure 9. WTEC III Controls Shift Selectors and Pushbutton Selectors
The transmission must be equipped with the oil level sensor to be able to read
fluid level information.
NOTE: WTEC III Controls pushbutton and lever selectors display fluid
level diagnostic information one character at a time. Allison 4
Generation Controls pushbutton and lever selectors display fluid level
diagnostic information two characters at a time.
1. Park the vehicle on a level surface, shift to N (Neutral), and apply the
parking brake.
2. Pushbutton shift selector—If equipped with an oil level sensor,
simultaneously press the ↑ (Up) and ↓ (Down) arrow buttons.
HOLD OVERRIDE BUTTON
MODE INDICATOR
(LED)
MODE BUTTON
MODE ID
DIGITAL DISPLAY
DISPLAY MODE/
DIAGNOSTIC BUTTON
WITH REVERSE TO FRONT
DIGITAL DISPLAY
MODE ID
MODE
INDICATOR (LED)
R
MODE
N
Push simultaneously
to enter diagnostic
D
mode and fluid
level check
PUSHBUTTON SELECTORS
R
MODE
N
D
5
4
3
*
2
1
SIX-SPEED,
RIGHT-HAND
LEVER SELECTOR
*
43
HOLD OVERRIDE
BUTTON
MODE INDICATOR
(LED)
MODE BUTTON
MODE ID
*
DIGITAL DISPLAY
DISPLAY MODE/
DIAGNOSTIC BUTTON
R
MODE
N
D
R
MODE
N
D
5
4
3
2
1
CONTOURED
VERSION
V07343.01.02
