- Page 1 TDS 10 M / TDS 20 M ORIGINAL INSTRUCTIONS CERAMIC HEATER...
-
Page 2: Table Of Contents
Information marked with this symbol indicates that the Children aged from 3 years and less than 8 years shall instructions must be observed. not plug in, regulate and clean the appliance or perform user maintenance. ceramic heater TDS 10 M / TDS 20 M... - Page 3 If the power cable is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. Defective power cables pose a serious health risk! ceramic heater TDS 10 M / TDS 20 M...
- Page 4 In that case the device switches off completely. If so, please contact the customer service to have the overheating protection replaced. ceramic heater TDS 10 M / TDS 20 M...
-
Page 5: Information About The Device
• Place no further devices or objects on top of the device to prevent it from being damaged. Designation Transport handle Air outlet Heating level I switch Heating level II switch Operating light Air inlet ceramic heater TDS 10 M / TDS 20 M... -
Page 6: Assembly And Start-Up
The procedure is identical for the devices TDS 10 M / TDS 20 To do so, please proceed as follows: 1. Loosen the two screws and the two washers from the top of the housing. ceramic heater TDS 10 M / TDS 20 M... -
Page 7: Operation
• Insert the mains plug into a properly fused mains socket. • Make sure that the power cable is guided along the back of the device. Never guide the power cable along the front of the device! ceramic heater TDS 10 M / TDS 20 M... -
Page 8: Errors And Faults
• Check whether the device is set up in a stable and upright position. Note Wait for at least 3 minutes after maintenance and repair work. Only then switch the device back on. ceramic heater TDS 10 M / TDS 20 M... -
Page 9: Maintenance
12. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... 13. Date: ......... 14. Date: ........15. Date: ........16. Date: ........Signature: ........ Signature: ......... Signature: ......... Signature: ......... ceramic heater TDS 10 M / TDS 20 M... -
Page 10: Technical Annex
(A): 50 cm 50 cm rear (B): 50 cm 100 cm sides (C): 50 cm 50 cm front (D): 50 cm 150 cm Weight 1.5 kg 2.5 kg ceramic heater TDS 10 M / TDS 20 M... - Page 11 Circuit diagram ceramic heater TDS 10 M / TDS 20 M...
- Page 12 H05VV-F 3G1.0mm Self-Resetting Thermostat 65 °C Cable Fastener 6N-4 220-240V 2000W Bottom Base SPCC Air Flue PA66+30%GF Dual Switch RK1-23 Motor YJ58-16A 220-240V 25W 1 Rubber Feet Rubber Indicator-Lamp Cover PC Handle ceramic heater TDS 10 M / TDS 20 M...
- Page 13 75 °C Power Cord H05VV-F 3G1.5mm 220-240V 3000W Bottom Base SPCC Air Flue PA66+30%GF Dual Switch RK1-23 Indicator-Lamp Cover PC Motor YJ58-20 220-240V 25W 1 Air Flue Support SECC Motor Supper SECC ceramic heater TDS 10 M / TDS 20 M...
-
Page 14: Disposal
• 2011/65/EU: 01/07/ 2011 • 2012/19/EU: 24/07/2012 • 2014/30/EU: 29/03/2014 • 2015/863/EU: 31/03/2015 Applied harmonised standards: • EN 55014-1:2017 • EN 60335-1:2012 • EN 60335-1:2012/A11:2014 • EN 60335-1:2012/A13:2017 • EN 60335-1:2012/AC:2014 • EN 61000-3-3:2013 ceramic heater TDS 10 M / TDS 20 M... - Page 15 Trotec GmbH Grebbener Str. 7 D-52525 Heinsberg +49 2452 962-400 +49 2452 962-200 info@trotec.com www.trotec.com...
