Communication
Port COM3
Baud Rates
(COM1, COM2)
Baud Rate
(COM3)
Parity
Word Length
Stop Bits
Transient
Protection
Isolation
Cable Length
Protocol
Protocol Modes
14.4

Visual Indicators

COM1
COM2
COM3
Status
Digital Inputs / Outputs
Counters
Push-button
14.5

Power Supply

DC power Input
SCADAPack LP Hardware Manual
May 26, 2006
RS-232 compatible serial port (CMOS)
Data Terminal Equipment (DTE)
8 pin modular jack
Half duplex
Implemented Td, Rd, and 5V power under program control.
Intended for use with SCADAPack Vision operator
interface.
300, 600, 1200, 2400, 4800, 9600, 19200, 38400
1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
none, even, or odd
7 or 8 bits
1 or 2 bits
COM1, COM2: 2.5kV surge withstand capability as per
ANSI/IEEE C37.90.1-1989
Common ground return connected to Chassis Ground.
RS-232 –maximum 10 ft (3 m)
RS-485 –maximum 4000 ft (1200 m)
TeleBUS (compatible with Modbus RTU and Modbus
ASCII)
Slave, master, master/slave, store and forward
received data
transmitted data
received data
transmitted data
clear to send
data carrier detect
received data
transmitted data
Power Mode LED
Run LED
Status LED (shows functional status)
Forced I/O LED
8 LEDs
3 LEDs
LED power toggle
30V maximum
10.0 to 11.5V turn on
9.5V typical turn off
(Rx) LED
(Tx) LED
(Rx) LED
(Tx) LED
(CTS) LED
(DCD) LED
(Rx) LED
(Tx) LED
42
