Installation and Service Manual
ATW-Series
Reversing Central Air to Water Heat Pump
Two-Stage R410a
Model Sizes 25-75
Maritime Geothermal Ltd.
info@nordicghp.com
P.O. Box 2555, 170 Plantation Road
www.nordicghp.com
Petitcodiac, NB E4Z 6H4
001970MAN-04
(506) 756-8135
ISSUE 02: 7-Dec-2021
Page 1
001970MAN-04
ISSUE 02: 7-Dec-2021
