- Page 1 HD IP Fixed Mini Bullet Camera User’s Manual_Install Part Ver. 1.1 / 2018.07 Before installing and using the camera, please read this manual carefully. Be sure to keep it handy for future reference.
-
Page 2: Table Of Contents
Contents INTRODUCTION Important Safety Information Speci cation Product & Accessories Part Name INSTALLATION Disassemble the Camera Installation SPECIFICATION Dimension... - Page 3 Safety Information CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN. CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK) NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Warning Precaution This symbol indicates that dangerous voltage This exclamation point symbol is intended to alert the consisting a risk of electric shock is present within user to the presence of important operating and...
- Page 4 Important Safety Instructions Read these instructions. - All these safety and operating instructions should be read before the product is installed or operated. Keep these instructions. - The safety, operating and use instructions should be retained for future reference. Heed all warnings. - All warnings on the product and in the operating instructions should be adhered to. Follow all instructions.
- Page 5 Disposal of Old Appliances 1. When this crossed-out wheel bin symbol is attached to a product it means the product is covered by the European Directive 2002/96/EC. 2. All electrical and electronic products should be disposed of separately form the municipal waste stream stream in accordance to laws designated by the government or the local authorities.
-
Page 6: Speci Cation
Specification FEATURES Optimized Multiple Profile Streaming ROI(Region of Interest) Various web plug-in Smart AVC Advanced built in ISP SPECIFICATION CAMERA I/O & EVENT Image Sensor 1/2.9” 2.2M CMOS Audio In/Out Total Pixels 2001(H) X 1121(V) Alarm In/Out Focal Length 3.6mm, F2.0 Video Output (2nd Video Out) Angle... -
Page 7: Product & Accessories
Introduction - Product & Accessories Please check if all the camera and accessories are included in the package. Cables Camera Torx Wrench Screw & Plastic Anchor-4pcs Quick Manual Template Sheet Waterproof cap & Gasket Manual CD... -
Page 8: Part Name
Introduction - Part Name Pan/Tilt Stoper Screw Lens Bracket RJ-45 Connector DC Power Jack Waterproof cap Reset Button... -
Page 9: Installation
Installation - Installation Before installing your camera, you have to read the following cautions. 1. You have to check whether the location can bear five times of the weight of your camera. 2. Don’t let the cable to be caught in improper place or the electric line cover to be damaged. Otherwise it may cause a breakdown or fire. - Page 10 Installation - Cabling Two Options Use a PoE-enabled switch to connect data and power through a single cable and begin viewing and recording images instantly. A non-PoE switch will require an adaptor for power transmission. 1. Using a PoE-Enabled Switch 2.
-
Page 11: Dimension
Specifications - Dimension Unit: mm 67.5 67.5 70.6 161.7...
