Garbage Disposer
DSP-100H-AWS model
The warranty is on page 25 of this User's Manual.
Please check the entry for customer name, delivery
date, and other information.
Thank you very much for purchasing the Teral
●
Garbage Disposer. In order to use this product both
safely and correctly, please use only after you have
carefully read and fully understood the User's Manual.
Keep this manual in a safe place. It contains the
●
warranty.
TP-326-02E
User s Manual and Warranty
（
）
manual feed type
Table of contents
1.
Configuration of the garbage disposer
2.
3.
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
4.
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
5.
Cautions on what to drop
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
6.
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
7.
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
8.
Causes of trouble and troubleshooting
●
Part replacement guidelines
●
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
●
●
1
・ ・ ・ ・ ・ ・ ・
2
・ ・ ・ ・ ・ ・
3
6
7
9
14
21
・ ・ ・ ・ ・ ・
23
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
24
・ ・ ・ ・ ・ ・ ・ ・
25
26
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・
Advertisement
Related Manuals for Teral DSP-100H-AWS
Summary of Contents for Teral DSP-100H-AWS
-
Page 1: Table Of Contents
・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ Maintenance instructions ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ ・ Thank you very much for purchasing the Teral ● Garbage Disposer. In order to use this product both ... -
Page 2: Overview Of The Garbage Disposer System
1. Overview of the garbage disposer system 2. Configuration Name of each component Shower-hose branch tee Garbage disposer Plug switch Electromagnetic Grinds up and flushes away valve Water supply Control panel equipment food waste. Stop cock Drain pipe Sends crushed food waste and kitchen wastewater Reset button down to the wastewater treatment system. It is a single - use pipe only for kitchen wastewater. Earth cable Power plug Trap Plug switch Disposer opening... -
Page 3: Safety Precautions
3. Safety precautions ● Be sure to follow these precautions for safety. Warning This User's Manual contains important information for preventing safety hazards. It is to ensure that this product is used both properly and safely, protecting people and/or property from damage. Fully understand the following (notations and graphic symbols) ●... -
Page 4: Precautions For Use
4. Precautions for use 3.Safety precautions ● When using the garbage disposer Caution Make sure that the shower head of the Do not insert anything other than Do not force a large amount of combination faucet is set at entire faucet food waste. food waste into the opening. while the garbage disposer is being used. （See page 8.） ●... - Page 5 5. What to insert The following items, if inserted, will damage the garbage Items that may be inserted Items not to be inserted disposer or remain inside the disposer without being crushed. Type Example Resulting problems if inserted Vegetable scraps, fruit scraps, (cooked) rice, fish meat. bones of small Food scraps fish (sardines etc.） , chicken bones such as the upper portion of chicken Metals Spoons, forks, T h e y w i l l d a m a g e t h e wings, meat. noodles, bread, fried food, tea leaves, leftovers, etc.
-
Page 6: Operating Instructions
6. Operating instructions Garbage disposer operation flow Insert food waste into the garbage disposer. ❶ Drop food waste. ● ln this case, do not force a large amount of food waste in. See the d i s p o s a l a m o u n t g u i d e l i n e ❷... - Page 7 6.Operating instructions When the sound of grinding food waste Turn the plug switch to the right to turn ON. stops, turn the plug switch left to the OFF position. ● Turn the plug switch until its △ marking aligns ● Even if the plug switch is not turned with the ON position. The buzzer will sound a to the OFF position, the operation will beep and water supply from the combination automatically stop in approximately faucet will start automatically. After 5 ...
-
Page 8: Maintenance Instructions
7. Maintenance instructions 6.Operating instructions How to remove foreign objects If foreign objects (items not to be inserted as described in page 8) enter the grinding chamber of the garbage disposer, be sure to remove them while following the procedures below. If the garbage disposer is operated without removing these objects, jamming, clogged pipes, or other problems will result. Remove the power plug of the garbage disposer from the outlet. If the power plug cannot be removed due to the unreachable position of the outlet. push down the branch circuit breaker latch for the garbage disposer on the distribution switchboard to turn it OFF. Be sure to pull the power plug out when removing foreign Warning objects. Not doing so will result in injury. Remove the plug switch from the Approximately two to three times a week, flush the ... - Page 9 7.Maintenance instructions How to clear a jam Insert the enclosed lock release handle from the disposer opening If overloaded food waste or foreign objects such as spoons cause jamming during into the grinding chamber with the grinding, the overload protection device will be activated and the garbage disposer will handle's recess aligned with the stop. In this case. a buzzer will sound. Clear jamming with the following procedure: nut ...
- Page 10 7.Maintenance instructions Cleaning interior of the garbage disposer unit Inser t the power plug of the garbage disposer into the outlet. The garbage disposer is a machine that processes food waste. Crushed food waste particles left in If the breaker is turned OFF, push the grinding chamber will cause bad odors. Clean it periodically (two to three times a week) with the latch up to turn it ON. the following procedures: Ice cleaning Insert 5 or 6 ice cubes. Press the reset button of the overload protection device on the ※ It is more effective to pour a few garbage disposer control box. drops of mild kitchen detergent. ※The buzzer will sound a ...
- Page 11 7.Maintenance instructions If ice cleaning does not sufficiently eliminate odors or dirt, Inser t the power plug of the clean the interior with the following procedure: garbage disposer into the outlet. If the breaker is turned OFF, push the latch up to turn it ON. Remove the power plug of the garbage disposer from the outlet. If the power plug cannot be removed due to the unreachable position of the outlet, push down the branch circuit breaker latch for the garbage disposer on the distribution switchboard to turn it OFF.
- Page 12 u s e , a n d deformed due to jamming to be replaced. Contact out even after turning on off from the control panel for contact the Teral call center caused by rigid foreign the Call Center. the switch. the disposer. The strainer of for service instructions.
-
Page 13: After-Sales Services
● Repair costs Inquiry or repair request by telephone is available for 24 hours a day, 365 days a year. Repair date and time will be determined at the time such request is made. Please note ※ Contact Teral Call Center for repair, parts replacement, or inspection. that we may not always be able to respond immediately. For repair, parts replacement, and inspection, it will cost 0120-201-844 Teral Call Center... -
Page 14: Warranty
Year Month date Motor type Capacitor-start single-phase induction motor ● Free-of-charge warranty provision Number of poles/rated output 4 poles/ 1OOW If a product delivered by Teral lnc. fails or is damaged during the warranty period for reasons attributable to the defective design or workmanship of the product, despite normal use according to the User's Manual, we will repair or replace the affected area free of charge Rated power consumption 330W/320W (50Hz/60Hz) during the specified period. The warranty in the preceding clause will cover the mechanical problem of the affected area and will not cover various expanses or other Rated current 4.2A/3.7A (50Hz/60Hz) damage arising from the problem. - Page 15 1. Overview of the garbage disposer system 2. Configuration Name of each component Shower-hose branch tee Garbage disposer Plug switch Electromagnetic Grinds up and flushes away valve Water supply Control panel equipment food waste. Stop cock Drain pipe Sends crushed food waste and kitchen wastewater Reset button down to the wastewater treatment system. It is a single - use pipe only for kitchen wastewater. Earth cable Power plug Trap Plug switch Disposer opening...
- Page 16 3. Safety precautions ● Be sure to follow these precautions for safety. Warning This User's Manual contains important information for preventing safety hazards. It is to ensure that this product is used both properly and safely, protecting people and/or property from damage. Fully understand the following (notations and graphic symbols) ●...
- Page 17 4. Precautions for use 3.Safety precautions ● When using the garbage disposer Caution Make sure that the shower head of the Do not insert anything other than Do not force a large amount of combination faucet is set at entire faucet food waste. food waste into the opening. while the garbage disposer is being used. （See page 8.） ●...
- Page 18 5. What to insert The following items, if inserted, will damage the garbage Items that may be inserted Items not to be inserted disposer or remain inside the disposer without being crushed. Type Example Resulting problems if inserted Vegetable scraps, fruit scraps, (cooked) rice, fish meat. bones of small Food scraps fish (sardines etc.） , chicken bones such as the upper portion of chicken Metals Spoons, forks, T h e y w i l l d a m a g e t h e wings, meat. noodles, bread, fried food, tea leaves, leftovers, etc.
- Page 19 6. Operating instructions Garbage disposer operation flow Insert food waste into the garbage disposer. ❶ Drop food waste. ● ln this case, do not force a large amount of food waste in. See the d i s p o s a l a m o u n t g u i d e l i n e ❷...
- Page 20 6.Operating instructions When the sound of grinding food waste Turn the plug switch to the right to turn ON. stops, turn the plug switch left to the OFF position. ● Turn the plug switch until its △ marking aligns ● Even if the plug switch is not turned with the ON position. The buzzer will sound a to the OFF position, the operation will beep and water supply from the combination automatically stop in approximately faucet will start automatically. After 5 ...
- Page 21 7. Maintenance instructions 6.Operating instructions How to remove foreign objects If foreign objects (items not to be inserted as described in page 8) enter the grinding chamber of the garbage disposer, be sure to remove them while following the procedures below. If the garbage disposer is operated without removing these objects, jamming, clogged pipes, or other problems will result. Remove the power plug of the garbage disposer from the outlet. If the power plug cannot be removed due to the unreachable position of the outlet. push down the branch circuit breaker latch for the garbage disposer on the distribution switchboard to turn it OFF. Be sure to pull the power plug out when removing foreign Warning objects. Not doing so will result in injury. Remove the plug switch from the Approximately two to three times a week, flush the ...
- Page 22 7.Maintenance instructions How to clear a jam Insert the enclosed lock release handle from the disposer opening If overloaded food waste or foreign objects such as spoons cause jamming during into the grinding chamber with the grinding, the overload protection device will be activated and the garbage disposer will handle's recess aligned with the stop. In this case. a buzzer will sound. Clear jamming with the following procedure: nut ...
- Page 23 7.Maintenance instructions Cleaning interior of the garbage disposer unit Inser t the power plug of the garbage disposer into the outlet. The garbage disposer is a machine that processes food waste. Crushed food waste particles left in If the breaker is turned OFF, push the grinding chamber will cause bad odors. Clean it periodically (two to three times a week) with the latch up to turn it ON. the following procedures: Ice cleaning Insert 5 or 6 ice cubes. Press the reset button of the overload protection device on the ※ It is more effective to pour a few garbage disposer control box. drops of mild kitchen detergent. ※The buzzer will sound a ...
- Page 24 7.Maintenance instructions If ice cleaning does not sufficiently eliminate odors or dirt, Inser t the power plug of the clean the interior with the following procedure: garbage disposer into the outlet. If the breaker is turned OFF, push the latch up to turn it ON. Remove the power plug of the garbage disposer from the outlet. If the power plug cannot be removed due to the unreachable position of the outlet, push down the branch circuit breaker latch for the garbage disposer on the distribution switchboard to turn it OFF.
- Page 25 u s e , a n d deformed due to jamming to be replaced. Contact out even after turning on off from the control panel for contact the Teral call center caused by rigid foreign the Call Center. the switch. the disposer. The strainer of for service instructions.
- Page 26 ● Repair costs Inquiry or repair request by telephone is available for 24 hours a day, 365 days a year. Repair date and time will be determined at the time such request is made. Please note ※ Contact Teral Call Center for repair, parts replacement, or inspection. that we may not always be able to respond immediately. For repair, parts replacement, and inspection, it will cost 0120-201-844 Teral Call Center...
- Page 27 Year Month date Motor type Capacitor-start single-phase induction motor ● Free-of-charge warranty provision Number of poles/rated output 4 poles/ 1OOW If a product delivered by Teral lnc. fails or is damaged during the warranty period for reasons attributable to the defective design or workmanship of the product, despite normal use according to the User's Manual, we will repair or replace the affected area free of charge Rated power consumption 330W/320W (50Hz/60Hz) during the specified period. The warranty in the preceding clause will cover the mechanical problem of the affected area and will not cover various expanses or other Rated current 4.2A/3.7A (50Hz/60Hz) damage arising from the problem.
