- Page 1 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! Desk Call us on 1300 527 665 Size: 1000mm Tools Required: Power screwdriver; Allen key set (provided) 2 persons required for installation Page 1 of 7...
- Page 2 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! Desk Call us on 1300 527 665 Size: 1000mm COMPONENTS Table top x1 Legs Quadro A x2 Beam x1 Plastic bracket x4 SCREWS M8x20MM CSK x1 M8x20MM Socket head x1 M6x20MM Socket head x2 M6x30MM Socket head x2 Allen key x2 Page 2 of 7...
- Page 3 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! Desk Call us on 1300 527 665 Size: 1000mm STEP 01 STEP 02 Plastic bracket holes facing to the other side. You will notice two colored Both legs must have the colour Insert the bottom of the legs as shown in the stickers located on each leg.
- Page 4 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! Desk Call us on 1300 527 665 Size: 1000mm STEP 03 STEP 04 Using Allen Key provided, attach 2 plastic brackets per leg (D) Using Allen Key provided, attach M8x20MM Socket head (F)- (as per picture above) using M6x20MM (G) Socket head screw screw socket half way into leg for both legs (B) Page 4 of 7...
- Page 5 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! Desk Call us on 1300 527 665 Size: 1000mm STEP 05 Adjust extendable beam (C) to desired length using markers and secure beam at that length using screws provided 2000 1900 1800 1700 1600 1500...
- Page 6 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! Desk Call us on 1300 527 665 Size: 1000mm STEP 06 TOP VIEW STEP 07 Attach beam (C) to legs (B) using nut insert in legs Frame looks like this. Using Allen Key, attach beam (C) with Socket (E) See point attached Page 6 of 7...
- Page 7 www.jasonl.com.au ASSEMBLY INSTRUCTIONS Quadro Wood A Need help! Desk Call us on 1300 527 665 Size: 1000mm STEP 08 TABLE TOP BOTTOM VIEW nut insert nut insert Place desktop ontop of frame. Nut inserts in top will align with plastic joiner brackets using M6x30MM (H) sockets attached top to frame.
