ASSEMBLY INSTRUCTIONS
Quadro Wood A
Need help!
Mobile Counter Table
Call us on
1300 527 665
Sizes:
1200x700, 1400x700, 1600x700, 1800x700
Tools Required:
Power screwdriver; Allen key set (provided)
2 persons required for installation
Page 1 of 10
