- Page 1 REMOTE CONTROLLER OWNER’S MANUAL IMPORTANT NOTE: Thank you for purchasing our air conditioner. Please read this manual carefully before operating your new air conditioning unit. Make sure to save this manual for future reference.
-
Page 2: Table Of Contents
Table of Contents Remote Controller Specifications ............02 Handling the Remote Controller ............03 Buttons and Functions ..............04 Remote Screen Indicators ..............06 How to Use Basic Functions ............07 How to Use Advanced Functions ..........09... -
Page 3: Remote Controller Specifications
Remote Controller Specifications Model RG51A(2)/E,RG51B(2)/E Rated Voltage 3.0V( Dry batteries R03/LR03×2) Signal Receiving Range Environment -5°C~60°C(23°F~140°F) Quick Start Guide AUTO COOL HEAT FIT BATTERIES SELECT MODE SELECT TEMPERATURE AUTO HIGH SELECT FAN SPEED POINT REMOTE TOWARD UNIT PRESS POWER BUTTON... -
Page 4: Handling The Remote Controller
Handling the Remote Controller Inserting and Replacing Batteries NOTES FOR USING REMOTE CONTROL Your air conditioning unit may come with two The device could comply with the local national batteries(some units). Put the batteries in the regulations. remote control before use. In Canada, it should comply with •... -
Page 5: Buttons And Functions
Press together DIRECT & TIMER OFF alternate the temperature buttons simultaneously for 5 seconds display of indoor unit to lock the keyboard. Press together between setting the two buttons for 2 seconds to temperature and room unlock the keyboard. temperature(some units). Model: RG51A(2)/E... - Page 6 TEMP TEMP Decreases temperate in Increases temperate in 1°C (1°F) increments. 1°C (1°F) increments. Min. temperature is Max. temperature is 16°C (60°F). 30°C (86°F). NOTE: Press together & buttons at the same time ON/OFF for 3 seconds will alternate Turns the unit on or off.
-
Page 7: Remote Screen Indicators
Remote Screen Indicators Information are displayed when the remote controller is power up. Mode display COOL AUTO AUTO HEAT Displayed when data transmitted. COOL HIGH Displayed when remote controller is ON. HEAT Displayed when TIMER ON time is set Displayed when TIMER OFF time is set Shows set temperature or room temperature, or time under TIMER setting Displayed when ECO feature is activated... -
Page 8: How To Use Basic Functions
How to Use Basic Functions Basic operation ATTENTION! Before operation, please ensure the unit is plugged in and power is available. SETTING TEMPERATURE The operating temperature range for units is 16-30°C (60-86°F). You can increase or decrease the set temperature in 1°C (1°F) increments. - Page 9 DRY Mode (dehumidifying) 1. Press the MODE button to select DRY. 2. Set your desired temperature using the TEMP or TEMP button. 3. Press the ON/OFF button to start the unit. NOTE: FAN SPEED cannot be changed in DRY mode.
- Page 10 Setting the TIMER TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off. TIMER ON setting Press TIMER ON button to Press Temp. up or down button for Point remote to unit and wait 1sec, initiate the ON time sequence.
-
Page 11: How To Use Advanced Functions
How to Use Advanced Functions Swing function Press Swing button SWING SWING The horizontal louver will swing up and down Keep pressing this button more than 2 seconds, automatically when pressing Swing button. the vertical louver swing function is activated. Press again to make it stop. - Page 12 ECO function Press this button under COOL Mode to enter the energy efficient mode. (For model of RG51A(2)/E) Note:This function is only available under COOL mode. Under cooling mode, press this button, the remote controller will adjust the temperature automatically to 24 C/75 F, fan speed of Auto to save energy (only when the set temperature is less than 24 C/75 F).
- Page 13 Silence function Keep pressing Fan button for more than 2 seconds FAN SPEED to activate/disable Silence function(some units). Due to low frequency operation of compressor, it may result in insufficient cooling and heating capacity. Press ON/OFF, Mode, Sleep, Turbo or Clean button while operating will cancel silence function.
- Page 14 The design and specifications are subject to change without prior notice for product improvement. Consult with the sales agency or manufacturer for details. CR249-RG51A-B(2) 16117000002122 2020.08.01...
- Page 15 技术要求： 尺寸A5,大度 80克双胶纸 装订，黑白...
