Service Manual
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . .
Specifications subject to change without notice.
INTRODUCTION
PAGE
This service manual provides the necessary information to use the
service functions on the RG58D/BGEFU1 wireless remote controller.
1
Use the Table of Contents to locate a desired topic.
2
3
4
5
5
5
5
5
6
7
7
7
7
7
8
8
8
8
8
8
8
8
9
9
10
Fig. 1 - Remote Controller
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Midea RG58D/BGEFU1
Summary of Contents for Midea RG58D/BGEFU1
-
Page 1: Table Of Contents
PAGE This service manual provides the necessary information to use the service functions on the RG58D/BGEFU1 wireless remote controller. INTRODUCTION ........ -
Page 2: Handling The Remote Controller
Fig. 3 - Remove the back cover Remote Controller Specification Table 1—Remote Controller Specification Model RG58D/BGEFU1 Rated Voltage 3.0V (Dry batteries AAA) Signal Receiving Range 26 ft. (8m) Environment 23_F (-5_C) ~ 140_F (60_C) -
Page 3: Function Buttons
FUNCTION BUTTONS Before you use your new system, familiarize yourself with the remote controller. The following is a brief introduction of the remote controller. 1. ON/OFF Use to turn the air conditioner ON and OFF. 2. UP Use to increase the set temperature or Timer setting hours. DOWN Use to decrease the set temperature or Timer setting hours. -
Page 4: Accessing The Service Functions
ACCESSING THE SERVICE FUNCTIONS Caution: Read and understand the function changes you wish to make in IMPORTANT: The remote controller is enabled within 10 minutes advance. The remote will not read the parameters in the unit. after the indoor unit is powered on, and the indoor unit must be turned off. -
Page 5: Remote Controller Functions
REMOTE CONTROLLER FUNCTIONS NOTE: The indoor unit beeps for 2 seconds indicating the function Anti−Cold Air Function (F3) has been successfully set. A) Intelligent Anti−Cold Air Function Auto−Start Function (F1) NOTE: The intelligent anti−cold air parameter changes with the room In the event of a sudden power failure, the module memorizes the temperature. -
Page 6: Indoor Fan Motor Speed Control After Set Temperature Is Reached (F4)
B) General Anti−Cold Air Function Setting (Cold Blow Prevention 2. Press MODIFY. Next, press to select Function) “1”,“2”,“3”,“4”. The general anti−cold air parameter is set regardless of the room temperature. NOTE: No setting adjustment recommended. 1. Press to select “F3”. Fig. -
Page 7: Heating Only Or Cooling And Heating Setting (F6)
Heating Only or Cooling and Heating Setting (F6) Refrigerant Leakage Detection (F8) 1. Press to select “F6”. 1. Press to select “F8”. Fig. 31 - Select F6 Fig. 36 - Select F8 2. Press MODIFY. Next, press to select “ON” or 2. -
Page 8: Lowest Temperature Setting (E2)
Lowest Temperature Setting (E2) Priority Setting of Heating or Cooling (only on Multi−Zone Systems (E5)) 1. Press to select “E2”. CAUTION All heads must be set to the same priority. Fig. 42 - Select E2 2. Press MODIFY. Next, press to set the temperature range (63 C) to 75... -
Page 9: Default Values Of Indoor Units
DEFAULT VALUES OF INDOOR UNITS Table 2—Default Values of Indoor Units Description Remote Code Cassette Ducted Console Auto-Start Function Heating Temperature Compensation Anti-Cold Air Function NORMAL NORMAL NORMAL Indoor Fan Motor Speed Control after Set Temperature is Reached SET SPEED SET SPEED SET SPEED Louver Angle Memory Function... -
Page 10: Code Value
CODE VALUE When the air conditioner enters the enquiry information status, it displays the code value in the next 25 seconds after the display name appears (see Table 4). Table 4—Code Value Enquiry Information Display Value Meaning Remark 1. The displaying temperature is -1F,-1E, -1d,-1c, -1b,-1A -25,-24,-23,-22,-21,-20 the actual value.
