- Page 1 23´-9˝ 9´ - 3˝ 20´ 40´ 20´ 40´ HIGH PEAK FRAME TENT 40 Hex A S S E M B L Y I N S T R U C T I O N S...
- Page 2 • sledge hammer • tape measure Anchoring Stakes • work boots • 6 ft ladder (example, not size specific) High Peak Frame Tent (SPECIFICATIONS: 40 Hex) Width 40 ft. / 9.1m Fabric Material PVC Coated Polyester Length 40 ft. / 7.6m Fabric Material Weight 16 oz.
- Page 3 716 832-TENT ( 8368 ) STEP 1. CHECK ITEM LIST (40 Hex High Peak Frame Tent) Item Illustration Item Size (all parts available for replacement) Quantity 9´-3˝ Eave Spreader Bars SKU: BT-FHAST111 (9´-3˝) Center Mast Pole 174˝ SKU: BT-FHCM174 Center Mast Pin...
-
Page 4: Step 2. Safety Check List
• Replace or repair any items in poor condition STEP 3. CONNECT EAVE BARS (40 Hex) • Spread tarp (sold separately) in the Position tarp in the exact tent location desired tent location, to protect canopy—... - Page 5 716 832-TENT ( 8368 ) STEP 4. CANOPY TOP • Unfold canopy top, place over cross cables and tarp • DO NOT walk on canopy Canopy top • Center the top and stretch to edges (flap as you go, to create ‘lift’) Note: Locate the O-ring pull strap attached to one of the corner loops, that should be the last loop to be...
- Page 6 716 832-TENT ( 8368 ) STEP 6. ATTACHING 1˝ STRAPS • At this time, finish sliding the stakes through all of the D-rings, that are connected to the 1˝ straps • Hammer all stakes in position (half-way) Connect before hammering •...
- Page 7 716 832-TENT ( 8368 ) STEP 8. BASE PLATE STRAPS • For every leg pole, there is a base plate and a 1.5˝ ratchet strap assembly —connect the straps as each leg is Attach a Installed 1.5˝strap with ring end Canopy •...
- Page 8 716 832-TENT ( 8368 ) FINISHED TENT 23´-9˝ canopy overhang 1.5˝Ratchet strap assembly 9´ - 3˝ and base plate 20´ (one per leg location) 40´ 20´ 1˝Ratchet strap assembly 40´ (one per leg location) (basically, reverse order from assembly) STRIKE PROCEDURE 1.) Remove base stakes 7.) Lay tarp under canopy 2.) Detach short straps under canopy...
- Page 9 Appendix A. • Tent Plan— showing details (other available sizes below) Eave spreader bars 40 Ft. HEXAGON Cable set-up TENT Mast: 174˝ 9´ -3˝ Leg pole positions 9´ -3˝ (at corners) Spreader inserts/connectors Other available sizes (High Peak Frame Tent) 10X10 10X20 15X15...
