Tentandtable.com 716 832-TENT Assembly Instructions Manual
High peak frame tents
Hide thumbs
Also See for 716 832-TENT:
- Assembly instructions manual (9 pages) ,
- Assembly instructions (4 pages)
Related Manuals for Tentandtable.com 716 832-TENT
Summary of Contents for Tentandtable.com 716 832-TENT
- Page 1 16´-9˝ 8´ 20´ 30´ 16´-9˝ 16´-9˝ 8´ 8´ 20´ 40´ 20´ 20´ HIGH PEAK FRAME TENTS 20´x20´/20´x30´/20´x40´ (tw in tube t ent s) A S S E M B L Y I N S T R U C T I O N S...
- Page 2 716 832-TENT ( 8368 ) Twin Tube High Peak Frame Tent (OVERVIEW) Sidewalls (optional) Canopy Center Mast Pole Pin Center Mast Ratchet Rope Cross Cable Spreader Bar 1 in. Ratchet Strap Corner Fitting Connector Insert Base Plate Recommended Tools: • hard hat Anchoring Stakes •...
- Page 3 716 832-TENT ( 8368 ) STEP 1. CHECK ITEM LIST Item Illustration Tent Size Quantity (all parts available for replacement) 9´ -3˝ 20 x 20 for 20 wide tents (eight 6´ -8˝ 20x30 only) Eave Spreader Bars 20 x 30...
-
Page 4: Step 2. Safety Check List
716 832-TENT ( 8368 ) STEP 2. SAFETY CHECK LIST • When building or assembling anything above shoulder height, wear a hard hat • Steel toe boots are recommended • Inspect the site, look for overhead and underground obstructions— such as utilities •... - Page 5 716 832-TENT ( 8368 ) STEP 4. CANOPY TOP • Unfold canopy top, place over cross cables and tarp • DO NOT walk on canopy Canopy top • Center the top and stretch to edges (flap as you go, to create ‘lift’)
- Page 6 716 832-TENT ( 8368 ) STEP 6. ATTACHING 1˝ STRAPS • At this time, finish sliding the stakes through all of the D-rings, that are connected to the 1˝ straps • Hammer all stakes in position (half-way) Connect before hammering •...
- Page 7 716 832-TENT ( 8368 ) STEP 8. BASE PLATE STRAPS • For every leg pole, there is a base plate and a 1.5˝ ratchet strap assembly —connect the straps as each leg is Attach a Installed 1.5˝strap with ring end Canopy •...
- Page 8 716 832-TENT ( 8368 ) WIND / RAIN / SNOW – IMPORTANT INFORMATION!: WIND! Wind can cause the ratchet assemblies and stakes to loosen, or cause the poles to sink or shift through constant movement and vibration — the tension of the tent will be negatively altered.
- Page 9 716 832-TENT ( 8368 ) FINISHED TENT (example) 16´-9˝ canopy overhang 1.5˝Ratchet strap assembly 8´ and base plate (one per leg location) 40´ 20´ 1˝Ratchet strap assembly (one per leg location) (basically, reverse order from assembly) STRIKE PROCEDURE 1.) Remove base stakes 7.) Lay tarp under canopy...
- Page 10 Appendix A. • Tent Plan— showing details Eave spreader bars 9´ -3˝ Cable set-up 20X20 Mast: TENT 111.0˝ 9´ -3˝ Leg pole positions (at corners) 9´ -3˝ 9´ -3˝ Eave spreader bars 20X30 9´ -3˝ TENT Cable set-up 9´ -3˝ Mast: 111.0˝...
