406-T
ENROULEUR DE FOC - NOTICE D'UTILISATION
ROLLREFFANLAGE - AUFBLASBARE RETTUNGSWESTEN
ROLREEFSYSTEEM - GEBRUIKERSHANDLEIDING
RULLFOCKSYSTEM - INSTRUKTIONER OCH HANDHAVANDE
Plastimo - 15, rue Ingénieur Verrière - 56100 Lorient - FRANCE
609-T
JIB REEFING - OWNER'S MANUAL
ENROLLADOR - GUIA DE UTILIZACION
AVVOLGITORE - MANUALE D'USO
811-T
GB
F
D
NL
E
S
I
Advertisement
Related Manuals for Plastimo 406-T
Summary of Contents for Plastimo 406-T
- Page 1 JIB REEFING - OWNER'S MANUAL ENROULEUR DE FOC - NOTICE D'UTILISATION ROLLREFFANLAGE - AUFBLASBARE RETTUNGSWESTEN ROLREEFSYSTEEM - GEBRUIKERSHANDLEIDING ENROLLADOR - GUIA DE UTILIZACION RULLFOCKSYSTEM - INSTRUKTIONER OCH HANDHAVANDE AVVOLGITORE - MANUALE D'USO Plastimo - 15, rue Ingénieur Verrière - 56100 Lorient - FRANCE...
- Page 3 ØB ØA Ø31 Ø200 Ø190 Ø145 ØH ØH ØH 406-T 609-T 811-T Terminal- stevenplaa- spanschroe- Stagspanner- tensor placas chainplate turnbuckle latte ridoir Landre Arridatoi tuitvoering fuitvoering montage montage 406-T 25200 25286 25200 25286 25200 25286 25200 25286 25200 25286 25286...
- Page 4 406-T 1 Trumma med 1 conjunto tambor 1 drum unit 1 ensemble tambour 1 Trommel 1 roltrommel 1 insieme tamburo revlinematare 1 giratorio 1 halyard swivel 1 émerillon 1 Fallwirbel 1 valwartel 1 Fallsvirvel 1 mulinello 1 top end stop 1 embout profil 1 Profilansatzstück...
- Page 5 609-T 1 Trumma med 1 conjunto tambor 1 drum unit 1 ensemble tambour 1 Trommel 1 roltrommel 1 insieme tamburo revlinematare 1 giratorio 1 halyard swivel 1 émerillon 1 Fallwirbel 1 valwartel 1 Fallsvirvel 1 mulinello 1 top end stop 1 embout profil 1 Profilansatzstück 1 top eind stuk...
- Page 6 811-T 1 Trumma med 1 conjunto tambor 1 drum unit 1 ensemble tambour 1 Trommel 1 roltrommel 1 insieme tamburo revlinematare 1 halyard swivel 1 giratorio 1 émerillon 1 Fallwirbel 1 valwartel 1 Fallsvirvel 1 mulinello 1 top end stop 1 embout profil 1 top eind stuk 1 terminal tope...
- Page 7 ASSEMBLY INSTRUCTIONS FOR T-SERIES 406-T 609-T 811-T I N D E X 1/ TECHNICAL SPECIFICATIONS 406-T, 609-T, 811-T 2/ DESCRIPTION OF SPECIFIC PARTS FOR EACH MODEL 2.1 - 406-T 2.2 - 609-T 2.3 - 811-T 3/ TOOLS NEEDED 4/ FLAT ASSEMBLY (forestay dismantled)) 4.1 - Dismantling the forestay...
- Page 8 4.1 - Dismanting the forestay 4.1.1 - Lower part - Slacken the backstay - Secure the mast forward with 1 or 2 halyards - Tigthen the halyards to relieve the strain on the forestay slackened - Dismantle the lower part of the forestay (this usually consists of removing a removing a backstay forestay rigging screw pin, or a screw and a nut).
- Page 9 - Slide the base spar into the drum unit until the two holes are in line, insert the M5x12 screw (after putting some silicone filler in the hole in order to reduce the stainless steel / aluminium electrolytic couple) and tighten. - Put another coupling unit (sleeve and stop) into position - Insert a screw (Ø3.9x12.7);...
- Page 10 - Put the top end stop back into position - Put some silicone filler into the hole - Insert and tighten screw (Ø4.8x12.7) - Your jib reefing system is now assembled and can be put into position (hoist it up to the masthead with a halyard) 5/ IN SITU ASSEMBLY this method of assembly may be carried out by one person it is not necessary to dismantle anything at the masthead...
- Page 11 5.3 - ASSEMBLING THE TOP END STOP - The top end stop should be assembled on the aluminium spar that has just been cut. - Slide the top end stop fully over the end of the spar (IMPORTANT: refer to diagram below for positioning of the hole in the top end stop) - Drill a hole using a Ø4.2 mm drill 5.4 - ASSEMBLING THE SPARS - Dismount the forestay from the stemhead fitting...
-
Page 12: Assembling The Drum Unit
5.7 - ADJUSTING THE REEFING LINE FEEDERS 5.7.1 - 406-T model - The reefing line feeder on the 406-T model is assembled either on the right or left hand side of the drum unit, depending on which direction you prefer to reef. -
Page 13: Maintenance
6/ Recommandations Reefing line feeders The angle of all the reefing line feeders may be adjusted. IMPORTANT: they should be positioned in a way that best suits the direction of pull on the line Reefing line The reefing line is wound around the drum. Only use pre-stretched rope in order to eliminate any elasticity Refer to diagram below for the position of the reefing line as it comes out of the drum 90°... - Page 14 PROBLEM ENCOUNTERED CAUSES SOLUTIONS Halyard turns with the halyard swivel - Forestay not taut enough - tighten the backstay - Genoa halyard too slack - tauten the genoa halyard - Genoa too short, halyard swivel too low - Use a strop - Genoa halyard too close to the forestay - Fasten a halyard feeder to the mast or a diverter to the forestay...
