DEKA DURATION DD5300
Installation and User Manual
DD5300 Energy Storage System
LOW VOLTAGE & HIGH VOLTAGE
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DURATION DD5300 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Deka DURATION DD5300

Summary of Contents for Deka DURATION DD5300

  • Page 1 DEKA DURATION DD5300 Installation and User Manual DD5300 Energy Storage System LOW VOLTAGE & HIGH VOLTAGE...
  • Page 2 DEKA DURATION DD5300 ATTENTION: The battery could explode and/or be severely damaged if dropped or crushed. ATTENTION: Appropriate mechanical lifting equipment must be used since the Battery Module weighs 126.3 lb (57.3 kg). ATTENTION: The battery may explode if exposed to open flames or other extreme sources of heat.

  • Page 3: Table Of Contents

    DEKA DURATION DD5300 Contents Statement: ............................6 Preface: ............................6 Declaration: ............................. 6 System Design ..........................7 Battery Operation ..........................7 Storage ................................7 Temperature ..............................7 Depth of Discharge (DoD) ..........................7 Charging ................................7 Warranty ................................7 Product Overview ..........................8 Symbols Used ...........................
  • Page 4 DEKA DURATION DD5300 1.3.3 Stack Mount ..................................23 1.4 Battery Terminal Function Definition ......................25 1.5 Out of the Box Pre-Operational Check ......................26 SECTION 2 - LOW VOLTAGE CONFIGURATION ..................27 2.1 Product Introduction ..........................27 2.1.1 Identifying the Individual Module............................ 27 2.1.2...
  • Page 5 DEKA DURATION DD5300 2.9.8 Conceptual Diagram between Master Modules of multiple clusters..................57 2.10 Cluster Configuration Accessories ......................58 2.10.1 Single Cluster Configuration Kit ............................58 2.10.2 Multi Cluster Hub Device ..............................58 2.11 Low Voltage Inverter Compatibility List ....................59 SECTION 3 - HIGH VOLTAGE CONFIGURATION ...................

  • Page 6: Statement

    DEKA DURATION DD5300 Statement: The information and guidance contained in this manual is related to the DEKA DD5300 Stackable model of battery. This manual contains two sections: Section 2 is for LOW VOLTAGE APPLICATION Section 3 is for HIGH VOLTAGE APPLICATION In case of product upgrades or other reasons, this document will be adjusted accordingly.

  • Page 7: System Design

    DEKA DURATION DD5300 System Design System Design is the process of defining the architecture, components, modules, interfaces and load data for a system to satisfy specified requirements. For a solar energy system, these components are the PV modules, inverter/charge controller & batteries, as well as the different interfaces of those components.

  • Page 8: Product Overview

    DEKA DURATION DD5300 Product Overview The Deka Duration DD5300 is a Stackable Battery Module with a DUAL VOLTAGE module that can be used in a Low Voltage configuration or in a High Voltage configuration. For LOW VOLTAGE (48.5-58.4 Vdc)* Configuration Refer to Section 2 For HIGH VOLTAGE (200-934.4 Vdc)* Configuration Refer to Section 3...

  • Page 9: Battery Module Overview

    DEKA DURATION DD5300 Battery Module Overview INFORMATION provides tips that are valuable for optimum installation and operation of the product. POWER OPERATOR PORT RUN BUTTON SWITCH CONNECTION HUB PROTECTION PLATE UPPER REMOVABLE BRACKET WALL BRACKET LOWER REMOVABLE BRACKET REMOVABLE HANDLES...
  • Page 10 DEKA DURATION DD5300 ATTENTION: THE BATTERY IS DUAL VOLTAGE – IT CAN BE INSTALLED IN EITHER A HIGH VOLTAGE CONFIGURATION OR A LOW VOLTAGE CONFIGURATION, BUT NEVER BOTH AT THE SAME TIME. BE AWARE OF THE DIFFERENT CONNECTION METHODS AND THE SPECIFIC USE OF THE TERMINAL CONNECTORS.

  • Page 11: Safety Warnings And Notifications

    CAUTION: The weight of an individual Deka Duration DD5300 Battery Module is 126.3 lb (57.3 kg). Please use original packaging and follow all safety precautions if the Battery Module is to be relocated to another location, to avoid damage to the product and personal injury.

  • Page 12: Warning Statements

    DEKA DURATION DD5300 Warning Statements Lithium Iron Phosphate (LiFEP04) Battery or Cell DANGER Hazard Statement The materials contained in this product may only represent a hazard if the integrity of the cell or battery is compromised; physically, thermally, or electrically abused. The below are the hazards anticipated under those conditions: Causes skin irritation. Causes serious eye irritation.

  • Page 13: General Preparation

    Before starting any operation on the battery, make sure to position the modules in their final position and structurally fix all the modules that make up the system. The installer who intends to install the Deka Duration DD5300 Battery Module in the HV configuration should read this entire manual including the HV configuration information defined in...
  • Page 14 DEKA DURATION DD5300 ATTENTION: STACKABLE INSTALLATION INFORMATION The stack configuration shall be concluded by interlocking the modules by using the module feet as shown below: Use the two screws to fix the feet across the modules The screw holes are on...
  • Page 15 DEKA DURATION DD5300 When operating in stack mode, remove the upper (trapezoidal) front part from the Battery Module to allow the cables to pass through. The front plate must be reinstalled to protect the cables after the installation is complete.

  • Page 16: Section 1 - Storage & Pre-Operational Procedures

    ✓ This battery can only be transported and stored with the original approved carton box, Certified as per UN CLASS 9 Y80. ✓ This Battery must be stored in its original carton box in a dry and cool place. DEKA DURATION carton box is marked as below: ✓...
  • Page 17 DEKA DURATION DD5300 The installer approaching this battery model for the first time must understand the use and operation of its accessories. The DD5300 Battery Module can be equipped with an auxiliary combiner such as: DD21001 HUB for Low Voltage configurations up to 105 batteries (7-Clusters x 15-Modules) DD21002 HV BOX device for High Voltage configurations up to 144 batteries (9-Clusters x 16-Modules).

  • Page 18: Module Unpacking And Handling

    DEKA DURATION DD5300 Module Unpacking and Handling The battery is always delivered in WALL mode, and it is therefore necessary for the installer to make simple changes to install the STACK kit. Below are the installation phases. ATTENTION: The battery must be lifted by four persons, using the four handles.

  • Page 19: Package Information And System Configuration List

    If battery is damaged and/or components missing, contact your local Deka Duration representative. 1.3 Wall Mount or Stack Mount Configuration NOTE: The Deka Duration DD5300 Battery Module ships as standard in the wall mount configuration. 1.3.1 Battery Dimensions* (Wall Bracket)
  • Page 20 DEKA DURATION DD5300 ATTENTION: The Battery Module weighs 126.3 lb (57.3 kg) and must be installed with the help of a mechanical lift, and/or with at least two people equipped with suitable suction cups for mechanical lifting or lifting straps.
  • Page 21 DEKA DURATION DD5300 Step 2A: In case of multiple module installation, make sure to respect the distance between the modules and the ceiling. Min 30 cm 25 cm 25 cm 25 cm 25 cm 25 cm Example of a Floor or Wall Mounted battery cluster connected with power cables and data cables.
  • Page 22 DEKA DURATION DD5300 Examples of a Floor or Wall Mounted battery cluster. Cable routing behind the battery Remove the rubber Secure the battery to feet starting from the wall using the the 2 module standard bracket upward Leave the rubber feet of...

  • Page 23: Stack Mount

    DEKA DURATION DD5300 1.3.3 Stack Mount ATTENTION: The Battery Module weighs 126.3 lb (57.3 kg) and must be installed with the help of a mechanical lift, and/or with at least two people equipped with suitable suction cups for mechanical lifting or lifting straps.
  • Page 24 DEKA DURATION DD5300 ATTENTION: Before stacking the batteries, the installer must check the maximum permissible floor load. It is recommended that the installer obtains approval from a civil engineer. For vertical ground mounting, the support surface of the Battery Module is distributed on 4 insulated supports (rubber pads), 10 x 4 cm each.

  • Page 25: Battery Terminal Function Definition

    DEKA DURATION DD5300 1.4 Battery Terminal Function Definition The terminal layout is shown in the following figure: Battery Terminal Wiring Definition Table Interface Name Function LV POLE + LOW VOLTAGE POSITIVE (+) Screw Terminal LV POLE - LOW VOLTAGE NEGATIVE (-) Screw Terminal...

  • Page 26: Out Of The Box Pre-Operational Check

    If the LED bar is all illuminated in RED, there is a major fault and you should not attempt any further operation of the battery. Contact Deka Duration support at durationsupport@dekabatteries.com. There is an RS232 Operator Port which will allow you to check all parameters of the Battery Module. Full instructions on how to interface to the RS232 port can be found in this manual.

  • Page 27: Section 2 - Low Voltage Configuration

    2.1 Product Introduction The Deka Duration DD5300 Battery Modules can be used as an on-grid or off-grid energy storage system. It is not recommended to use this product for any purpose other than the intended purpose as described in this document.
  • Page 28 The nameplate label describes the product parameters and is attached to the product. For details, please refer to the nameplate label of the product. For safety reasons, the installer must have a thorough understanding of the contents of this manual before installing the product. DEKA DURATION BATTERY MODULE – PRODUCT LABEL...

  • Page 29: Accessory List (Standard Kit 120A Single Module Lv)

    DEKA DURATION DD5300 2.1.2 Accessory List (Standard Kit 120A Single Module LV) The Battery Module is packed in a carton together with standard accessories. When unpacking the Battery Module, be sure to check that the Battery Module and accessories are free from damage and that the correct quantities of each component are included within the carton.

  • Page 30: Necessary Installation Tools

    DEKA DURATION DD5300 2.1.3 Necessary Installation Tools Insulated Screwdriver Set Insulated Allen Key Set from 2 mm Drill + Hammer Multimeter + Current clamp to 8 mm RS232/USB + Screw Terminal (insulated) Electrician Scissors Insulated Torque Wrench Set Lifting Strap + Mechanical Lifter...

  • Page 31: Low Voltage Module Wiring And Set Up

    : The LV fuse is contained in the left portion of the Battery Module as shown above. The access to the fuse is restricted to authorized Deka Duration service personnel and the protection lid cannot be opened by anyone else. The same applies to the HV fuse.

  • Page 32: Low Voltage Dip Switch Settings

    All drawings are for reference only. Always refer to the physical product as the standard. If the manual does not match the physical product, stop all actions, remove any connections, and store the batteries in a safe place. Call your Deka...

  • Page 33: Low Voltage Parallel Configuration

    DEKA DURATION DD5300 2.3.1 LOW VOLTAGE PARALLEL CONFIGURATION The DIP switch must be set as follows to allow a single Battery Module to communicate with an inverter using CAN communications: WHEN THE INVERTER HAS A CANBUS COMMUNICATION PORT, SWITCH #7 OF THE MASTER BATTERY MUST ALWAYS BE SET TO “ON.”...
  • Page 34 DEKA DURATION DD5300 Name Meaning Function or Indication Status POWER SWITCH On/Off Button Switches the Battery Module on and off. Module Correct Operation RUN BUTTON When the Battery Module is running normally, indicator light will be STEADY GREEN. LOW BATTERY Low SOC When the battery SoC is low (SoC<0-5%) the RUN Button will...

  • Page 35: Low Voltage Parallel Set Up Overview

    All drawings are for reference only. Always refer to the physical product as the standard. If the manual does not match the physical product, stop all actions, remove any connections, and store the batteries in a safe place. Call your Deka Duration technical service representative for assistance.

  • Page 36: Auto Id Assignment And Dip Configuration For Low Voltage Single Cluster (Parallel Connection)

    DEKA DURATION DD5300 CAN to Inverter To start up the system just press the Master Run Button CAN PORT 2A MASTER Port RS485B Port RS485A SUB 1 Port RS485B Port RS485A SUB 2 Port RS485B Port RS485A / or Last Module 2.5.1 Auto ID Assignment and DIP Configuration for LOW Voltage Single Cluster (Parallel Connection)
  • Page 37 DEKA DURATION DD5300 STEP 2 AUTO WAKE-UP PROCESS (Pressing the RUN BUTTON ) Once all the connections have been checked, it is possible to start the Battery Module by enabling the automatic wake-up process. Press the RUN button of the MASTER battery, the RUN BUTTON will Blink and will wake-up all the SUB batteries connected.

  • Page 38: Single Cluster Dip And Data Connection

    DEKA DURATION DD5300 2.5.2 Single Cluster DIP and DATA Connection The DIP SWITCH setting for the SINGLE CLUSTER LV mode has an automatic function that assigns the single module ID in cascade. It is mandatory to connect each module in Daisy Chain connection starting from the RS485B PORT of the master unit.

  • Page 39: Parallel Battery Wiring Connections

    All drawings are for reference only. Always refer to the physical product as the standard. If the manual does not match the physical product, stop all actions, remove any connections, store the batteries in a safe place and call your Deka Duration technical representative for assistance. Attention: For the power cable connection for high current, please refer to the specific section to see the diagram.

  • Page 40: Low Voltage Single Stack Power And Data Connections (15-Modules Maximum)

    DEKA DURATION DD5300 2.5.4 Low Voltage Single Stack Power and Data Connections (15-Modules Maximum) Proceed with the physical installation of the desired quantity and configuration of the Battery Modules, following the installation sequences and guidelines as described in Section 1 and Section 2 of this manual.
  • Page 41 Illustrations shown are for reference only. Please always refer to the physical Battery Module in front of you, and if the module has a different configuration to this manual, stop all activity immediately and contact your Deka Duration technical service representative.

  • Page 42: Led Bar Indications

    DEKA DURATION DD5300 2.5.5 LED Bar Indications The LED bar is located on the front of the battery and is to be used as a visual indication. OVER/UNDER TEMPERATURE START UP If the temperature rises above the BMS limits, the contactor opens LED BAR Check.

  • Page 43: Stand Alone Battery Front Panel Control

    DEKA DURATION DD5300 2.6 Stand Alone Battery Front Panel Control 2.6.1 Start Battery Press the Run Button for 2-seconds. The GREEN RUN light should come on. The Battery Module has been activated normally. 2.6.2 Shut Down Battery Press and hold the RUN Button for 5-seconds. The GREEN RUN light should go off. The Battery Module has been shut down normally.

  • Page 44: Shutdown Of Parallel Batteries

    DEKA DURATION DD5300 2.7.2 Shutdown of Parallel Batteries Press and hold the Master Run Button for 5-seconds. The GREEN RUN light should go off immediately. The GREEN RUN lights on the sub batteries will not be extinguished immediately. The RED FAULT lights on the sub batteries’ FRONT LED bars will start flashing after ten seconds and the GREEN RUN lights will remain on.

  • Page 45: Direct Parallel Connection Without Certified Inverter Bms Communication (Open-Loop)

    2.7.3 LV Direct Parallel Connection WITHOUT Certified Inverter BMS Communication (Open-Loop) It is recommended to always use an inverter equipped with CAN communication as listed in this manual, however any inverter can be used with Deka Duration batteries by setting the voltage and current values according to the table below.

  • Page 46: Direct Parallel Connection With Certified Inverter Bms Communication (Closed-Loop)

    DEKA DURATION DD5300 2.7.4 LV Direct Parallel Connection WITH Certified Inverter BMS Communication (Closed-Loop) Note that for installations WITH certified Inverter BMS Communications the maximum number of battery modules per installation is limited to seven clusters of fifteen Battery Modules per cluster. The DD21001 Low Voltage Hub must be used when the installation has more than one cluster.

  • Page 47: Power Connection Of A Single Cluster

    DEKA DURATION DD5300 2.8 Power Connection of a Single Cluster -Double BUS BAR- ATTENTION: Both ends of the cluster must be connected with two output cables 50 mm2. Cables length shall not exceed 250cm. The suggested output cable is composed of two sets of 50 mm2 each.
  • Page 48 DEKA DURATION DD5300 Cable size verification for a cluster composed by 5 or more Battery Modules connected to the inverter with 2 sets of cables (50mm² each) for a total of 100 mm² each terminal (positive and negative). Numbers of Modules...

  • Page 49: Can Hub For Multi Cluster Configuration

    SET THE INVERTER POWER AS PER THE CABLES’ CAPABILITIES Each battery pack and each cluster must have the same Voltage and Firmware. All stack configurations must use the Deka Duration Bus Bar. Each cluster must have the same number of Battery Modules.
  • Page 50 DEKA DURATION DD5300 The DD21001 HUB can manage a maximum of 7 clusters composed of a maximum of 15 modules each. A MULTI CLUSTER SYSTEM SHALL BE CONNECTED WITH BUS BAR BETWEEN MODULES. Interface Description and Connector I/O CONTACT 2X...

  • Page 51: Low Voltage Can Hub Dimensions

    DEKA DURATION DD5300 2.9.1 Low Voltage CAN HUB Dimensions Kg: 8 Weight: 2.9.2 Control Logic and Protection Limit The inverter, if applicable, must be set with the below restrictions in addition to the BMS control logic. MAX CURRENT WITH BUS BAR...

  • Page 52: Can Hub General System Description

    DEKA DURATION DD5300 2.9.3 CAN Hub General System Description CAN Hub is Mandatory for Multiple Cluster Installation ATTENTION: BEFORE PROCEEDING WITH THE DD22100 INSTALLATION IT IS MANDATORY TO READ THE INSTRUCTIONS BELOW Special BUS Bar for Parallel Configuration (MODULES INTERCONECTION BUS BAR MODEL – ACCESSORY) ATTENTION: BUS BARS ARE MANDATORY FOR STACK SYSTEM.

  • Page 53: Multi Cluster Configurations

    DEKA DURATION DD5300 2.9.4 Multi Cluster Configurations Before using the MASTER HUB device, make sure to update the modules with the latest update Firmware available on www.DD5300-BMS.com. To use and set up the MASTER HUB, the installer must follow the instructions contained in this manual.

  • Page 54: Master Id Set Up And Connection Diagram

    DEKA DURATION DD5300 2.9.5 Master ID Set Up and Connection Diagram Communication Diagram It is important to follow the diagrams below to make the connections in the correct sequence. Each cluster must have its own unique address which will be assigned by the first battery of each cluster.

  • Page 55: Power Connection Example

    DEKA DURATION DD5300 2.9.6 Power Connection Example Communication Diagram + Power Connection CAN INPUT FROM LAST CLUSTER Master Inverter PARALLEL BUS TWO POLES TWO POLES BREAKER BREAKER ( US/UL Market) NEGATIVE POWER CABLES 2X50/75mm² GROUND CABLES 10mm² RS485 PARALLEL RJ45 Cable...

  • Page 56: Conceptual Diagram Of A Cluster Composed By 5 Clusters And 8 Batteries Each

    DEKA DURATION DD5300 2.9.7 Conceptual Diagram of a Cluster composed of 5 clusters of 8 batteries each. Note: It is possible to install up to 7 clusters composed of 15 batteries each for a total of 105 batteries. CAN BMS...

  • Page 57: Conceptual Diagram Between Master Modules Of Multiple Clusters

    DEKA DURATION DD5300 2.9.8 Conceptual Diagram between Master Modules of multiple clusters. Note: It is possible to Install up to 7 clusters composed of 15 batteries each for a total of 105 batteries.

  • Page 58: Cluster Configuration Accessories

    DEKA DURATION DD5300 2.10 Cluster Configuration Accessories 2.10.1 Single Cluster Configuration Kit DD21005 STANDARD LV BUS BAR KIT 1 x Custom BUS BAR Insulated RED module connection Each kit includes 1 x Custom BUS BAR Insulated BLACK module connection 1 red + 1 black...

  • Page 59: Low Voltage Inverter Compatibility List

    DEKA DURATION DD5300 2.11 Low Voltage Inverter Compatibility List...
  • Page 60 DEKA DURATION DD5300 2.12 Low Voltage Inverter Battery to Inverter CAN Terminal Pin Out Inverter Invertr Side Battery Side CAN TERMINAL Terminal Type (PIN Number) (PIN Number) CAN L CAN H SMA SUNNY ISLAND RJ45 CAN L ZCS HYD/SP CAN H...

  • Page 61: Section 3 - High Voltage Configuration

    DEKA DURATION DD5300 SECTION 3 - HIGH VOLTAGE CONFIGURATION SERIAL CONNECTION AND SYSTEM CONFIGURATION HIGH VOLTAGE STACKABLE CONFIGURATION ATTENTION: THIS SECTION IS FOR HIGH VOLTAGE CONFIGURATION ONLY IT IS COMPULSORY TO USE THE DD21002 HV BOX FOR THIS CONFIGURATION...

  • Page 62: Product Introduction

    3.1 Product Introduction The Deka Duration DD5300 Battery Modules can be used as an on-grid or off-grid energy storage system. It is not recommended to use this product for any purpose other than the intended purpose as described in this document.

  • Page 63: Product Identification And Labels

    DEKA DURATION DD5300 3.1.2 Product Identification and labels The nameplate label describes the product parameters and is attached to the product. For details, please refer to the nameplate label of the product. For safety reasons, the installer must have a thorough understanding of the contents of this manual before installing the product.

  • Page 64: Hv Box Dimensions

    DEKA DURATION DD5300 3.1.3 HV BOX Dimensions 400mm 210mm 470mm Dimensions 400 x 470 x 170 36.6 lb Weight lb (kg) (16.6 kg) Case Material Type Steel Operative Voltage 100-1000 400mm...

  • Page 65: Battery Module Accessory List (Standard Kit)

    DEKA DURATION DD5300 3.1.4 Battery Module Accessory List (Standard Kit) The Battery Module is packed in a carton together with standard accessories. When unpacking, be sure to check that the Battery Module and accessories are free from damage and that the correct quantities of each component are included within the carton.

  • Page 66: Hv Box Kit (Included In The Carton Box)

    DEKA DURATION DD5300 3.1.5 HV BOX KIT (Included in the carton box)

  • Page 67: Necessary Installation Tools

    DEKA DURATION DD5300 3.1.6 Necessary Installation Tools Drill + Hammer Insulated Screwdriver Set Insulated Allen Key Set Multimeter + Current clamp RS 232/USB + Screw Terminal (insulated) Electrician Scissors Insulated Torque Wrench Set Lifting Strap + Mechanical Lifter 3.1.7 Personal Protective Equipment + 1000 Vdc Insulated Tool Kit...

  • Page 68: High Voltage Battery Module Wiring And Set Up

    : The LV fuse is contained in the left portion of the module as shown above. The access to the fuse is restricted to authorized Deka Duration service personnel, and the protection lid cannot be opened by anyone else. The same applies to the HV fuse.
  • Page 69 DEKA DURATION DD5300 Battery Terminal Definition table The terminal layout is shown in the following figure: H/H1 I/I 1 Module Definition Table Interface Name Function LV POLE + LOW VOLTAGE POSITIVE (+) Screw Terminal (NO USE IN HV CONFIGURATION) LV POLE -...

  • Page 70: Hv Box Overview

    DEKA DURATION DD5300 HV BOX Overview MAIN BREAKER POWER LED RUN LED FRONT PLATE 1000Vdc 125A GREEN Wi-Fi ANTENNA HV CONNECTION HUB Optional Accessory...
  • Page 71 DEKA DURATION DD5300 HV BOX Terminals Definition Table HV BOX Definition Table Interface Name Function WIFI ANTENNA WiFi ANTENNA * (Optional) INPUT CHANNEL + POSITIVE INPUT FROM THE INVERTER CHANNEL 01 POSITIVE PLUG (+) MAX 50A INPUT CHANNEL - NEGATIVE INPUT FROM THE INVERTER...

  • Page 72: High Voltage Module Configuration

    DEKA DURATION DD5300 3.4 High Voltage Module Configuration ATTENTION: The High Voltage mode mandates that the Battery Modules must be connected in series ATTENTION: The following table provides the possible module configurations. NO OTHER configurations are suitable ATTENTION: Before connecting an HV inverter with the HV BOX terminal, always check the Inverter Input range.

  • Page 73: High Voltage Dip Switch Settings

    ATTENTION: All drawings are for reference only. Always refer to the physical product as the standard. If the manual does not match the physical product, stop all actions, remove any connections and store the batteries in a safe place. Call your Deka Duration technical representative for assistance.

  • Page 74: Serial Tower Connection #1 Set-Up Of The Hv Box Can Communication Loop

    DEKA DURATION DD5300 3.5.1 Serial Tower Connection #1 Set-Up of the HV Box CAN Communication Loop Four batteries connected in series is the minimum allowed configuration for High Voltage operation: CAUTION After setting the DIP switches, the batteries must be restarted for the DIP switch changes to take effect.

  • Page 75: Serial Battery Wiring Connections

    Attention: For power cable connection for high current connection diagram, please refer to the specific section. Charging current limitation is mandatory as per this instruction manual. Attention: Do not use anything other than Deka Duration supplied power and data cables.

  • Page 76: High Voltage Power Connections

    DEKA DURATION DD5300 3.6.1 High Voltage Power Connections DD21002 HV Box can support maximum of 16 modules (934Vdc string Voltage). Proceed with the physical installation of the desired quantity and configuration of the Battery Modules, following the installation sequences and guidelines as described in Section 1 of this manual.

  • Page 77: Data Connections (Example Of 12-Modules)

    DEKA DURATION DD5300 3.6.2 DATA Connections (Example of 12-Modules) Step 1: Set up the DIP Switches as per the picture below. Step 2: Connect the CAN and Link PORTS, starting from the HV Box PORT CAN A and LINK, then chain connection as shown below.
  • Page 78 DEKA DURATION DD5300 Make sure that the ground connection is not shared with other potential distributing devices, and that the ground rod is not used for Neutral Line dispersion or Harmonics mitigation circuit.

  • Page 79: Hv Box And Battery Module Power Connection

    DEKA DURATION DD5300 3.6.3 HV Box and Battery Module Power Connection Step 1: Keep the power box main breaker OFF (located on the side). Step 2: Connect the positive terminal of the HV Box to the Positive terminal of the 1 Battery Module.

  • Page 80: Single Hv Box Connection To An Inverter

    DEKA DURATION DD5300 3.6.4 Single HV Box Connection to an Inverter Step 1: Turn the HV Box off by switching off the MAIN BREAKER located on the right side. Step 2: Turn the Solar Inverter OFF. Step 3: Connect the RJ45 cable into the CAN PORT 2A and perform the connection as per the Inverter Manual by following the PIN layout provided below.

  • Page 81: Multi Hv Box Connection

    DEKA DURATION DD5300 CAN TO INVERTER 3.6.5 Multi HV Box Connection Multi Clusters Communication Cable Connection TO HV HUB or Last CAN 2A TO HV HUB CAN 1A HV BOX ADDRESS 00 HV BOX ADDRESS 01 HV BOX ADDRESS 02...

  • Page 82: Multi Hv Box Connection

    DEKA DURATION DD5300 3.6.6 Multi HV Box Connection General Instructions In a Multi Cluster Connection with only one inverter CAN Connection Line, it is necessary to use the HV HUB and connect in Daisy Chain all the HV BOXES of each Cluster.

  • Page 83: Hv Box Address

    DEKA DURATION DD5300 3.7 HV Box ADDRESS...
  • Page 84 DEKA DURATION DD5300 MULTI CLUSTER CONNECTION WITH HIGH VOLTAGE HUB Installation of a High Voltage Multi-Cluster System. Install clusters with the same number of modules. Each module of each cluster must have the same voltage. Each cluster must have the same total voltage.

  • Page 85: Led Visual Indication Lights

    DEKA DURATION DD5300 LED Visual Indication Lights 3.7.1 • RUN Button • Each Battery Module has its own RUN button, however, when used with the HV Box during normal operation, the RUN button has no function and is bypassed by the control communications from the HV Box.
  • Page 86 FRONT LED BAR low battery LED will go out. Details of the indications on the FRONT LED BAR can be found in Section 2.5.5 of this manual. ATTENTION: Each Battery Module must be recharged at the same SoC. The inspection must be done by using the Deka Duration RS232 and LV PC software.

  • Page 87: High Voltage Inverter Compatibility

    DEKA DURATION DD5300 3.8 HIGH VOLTAGE INVERTER COMPATIBILITY INVERTER BRAND MODEL HV BOX Protocol Selection ZCS Azzurro HYD ThreePhase ALL WeCo CAN Sermatec SMT ThreePhase ALL WeCo CAN Tsun TSOL HV single Phase WeCo CAN Megarevo Threephase ALL WeCo CAN...

  • Page 88: Weco Bms - Low Voltage Pc Software For Dd5300

    DEKA DURATION DD5300 3.9 WECO BMS - LOW VOLTAGE PC SOFTWARE for DD5300 LOW VOLTAGE SECTION Equipment List: PC Windows 10+Service pack 3.5 or above RS232 Serial Converter with 232-RJ45 Plug WeCo Monitor PC-SOFTWARE PIN OUT RS232 CONVERTER STEP 1 Download the latest version of the WeCo BMS PC software at www.DD5300-BMS.com.
  • Page 89 DEKA DURATION DD5300 STEP 3 Connect the RJ45 plug from the RS232-USB Converter to the Operator Port of the Battery Module. Operator Port is located on the battery side, near the RUN button. nd PRESS RUN Turn On The PLUG OPERATOR...
  • Page 90 DEKA DURATION DD5300 STEP 5 When the communication is established between the PC and the Battery Module, the PC software will display a page like the one below: If more than one battery is connected in parallel, all the information will be displayed on this page.
  • Page 91 DEKA DURATION DD5300 STEP 6 LOW VOLTAGE PROTOCOL MODIFICATION In order to connect the battery with an inverter other than the default one, it is necessary to access the SETTING page and select the CAN protocol needed to communicate with the inverter.

  • Page 92: Weco Bms - High Voltage Pc Software For Dd5300

    DEKA DURATION DD5300 3.10 WECO BMS - HIGH VOLTAGE PC SOFTWARE for DD5300 Use an Opto-Isolated RS232-USB Converter for the connection between PC and HV BOX. STEP 1 Connect the RJ45 Port with the Operator Port located in the front of the HV BOX.
  • Page 93 DEKA DURATION DD5300 STEP 3 SYSTEM INFORMATION From this page it is possible to view the modules that make up the system. It is also possible to monitor the voltage and current status of each individual module and any warnings or alarms.
  • Page 94 DEKA DURATION DD5300 MOBILE Bluetooth APP Install the WECO LOCAL App by downloading it from the App Store / Google Play - available in 2022 Install the APK file from your File Folder MOBILE APP GENERAL OVERVIEW + FIRMWARE UPGRADE...
  • Page 95 All data subject to change without notice. No part of this document may be copied or reproduced, electronically or mechanically, without written permission from the company. Before installing your Deka Duration Battery Modules, please contact your Deka Duration representative for the latest manual and any additional support.
  • Page 96 DEKA DURATION DD5300 1-800-372-9253 ● 714-937-1033 ● mkbattery.com Email: durationsupport@dekabatteries.com MK Battery – An East Penn Manufacturing Co. Subsidiary All data subject to change without notice. Actual product color may vary. No part of this document can be copied r reproduced, electronically or mechanically, without written permission from the company.
