For more information contact our team: service.ec@foagroup.com
ASSEMBLY RATING
The Assembly Rating is a 5-point system that
shows the degree of effort needed in
assembling a specific product (with 1 being
easy and 5 being difficult). For some
products, two persons are recommended.
EASY
Assembly Instructions
CM-BK450FF
DIFFICULT
Tools Required For Assembly:
Allen Wrench
Phillips Screwdriver
2 PERSONS RECOMMENDED
Page 1 of 10
(Included)
(Not Included)
Rev: 16-12-09
Advertisement
Related Manuals for Furniture of America CM-BK450FF
Summary of Contents for Furniture of America CM-BK450FF
- Page 1 Assembly Instructions For more information contact our team: service.ec@foagroup.com CM-BK450FF ASSEMBLY RATING Tools Required For Assembly: The Assembly Rating is a 5-point system that shows the degree of effort needed in Allen Wrench (Included) assembling a specific product (with 1 being easy and 5 being difficult).
- Page 2 LOOSEN OVER TIME AND MAY CAUSE THE FURNITURE TO BE WOBBLY AND UNABLE TO SUPPORT ITS INTENDED WEIGHT CAPACITY. THIS MAY LEAD TO COLLAPSE AND MAY CAUSE SERIOUS INJURY. FAILURE TO FOLLOW THE GUIDELINES ABOVE MAY RESULT IN INJURY AND/OR PROPERTY DAMAGE. FURNITURE OF AMERICA.ALL RIGHTS RESERVED. Page 2 of 10...
- Page 3 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #1 x 1pc #9 x 1pc Ladder Rail (Left) Headboard (Left) #2 x 1pc #10 x 1pc Ladder Rail (Right) Headboard (Right) #3 x 1pc...
- Page 4 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. #A x 16pcs #F x 8pcs Screw Ø1/4" x 2" Bolt Ø1/4" x 4-7/8" #B x 16pcs #G x 22pcs Barrel Nut Ø1/4"...
- Page 5 Before you begin, please read Page 2 of "Assembly and Care Advice". And remember, do not tighten until each step is completed or instructed. Page 5 of 10...
- Page 6 #A x 16pcs #B x 16pcs Insert barrel nuts (#B) into the holes of the side rails (#3,4,5,6). Align side rails (#3,4,5,6) to the holes of the headboard (#1,2) as shown in the picture. Secure with bolts (#H) by attaching bolts (#H) to the barrel nuts (#B).
- Page 7 Align center support (#12) to the "U" shaped block of the upper headboards (#1,2). Secure wtih screws (#G). #G x 2pcs Align ladder rungs (#11) to the holes of the ladder rails (#9,10). Secure with screws (#F). #F x 8pcs Page 7 of 10...
- Page 8 Align ladder to the holes of the side rails (#3,5). Secure the ladder with bolts (#D). #D x 4pcs #H x 2pcs Align support legs (#13) to the holes of the bottom slat kit (#15), then secure wtih screws (#H). Page 8 of 10...
- Page 9 1) Align top slat kit (#14) to the top side rails, then secure with screws (#G). #G x 20pcs 2) Align bottom slats (#15) to the bottom side rails, then secure with screws (#G). ASSEMBLY IS COMPLETED Page 9 of 10...
- Page 10 Page 10 of 10...
