RUPTELA FM-Eco4 light T Quick Start Manual

Make sure that you have:
• A computer with Windows 7/8/10
• An internet connection (or a predownloaded
• A USB A to USB mini (Type B) cable
•
Tools for installation and wire connection: a flat screwdriver, a panel removing tool, a wrench, a crimp
terminal, zip-ties (or double-sided tape)
Device overview
12 Pin port
Indication LED patterns
LED Pattern
Once every second
GNSS
Once every 0.4 seconds
Once every 4 seconds
Once every 0.2 seconds
GSM
Always on
Always off
Once every 5 seconds
1-Wire
Twice every 5 seconds
Three times every 5
seconds
All Once every 5 seconds
www.ruptela.com
FM-Eco4 light+ T
Quick Start Guide
Q
Device Center)
USB mini (Type B) port
Device pinout
Description Pin
Accurate signal
VIN
No signal
Accurate signal GND
No signal
DIN1
Link with the
DIN2
server is open
DIN3
No devices
connected
DIN4
One device
AIN1
connected
AIN2
Two devices
connected
DOUT1
Three devices
DOUT2
connected
1-Wire POWER
Sleep/deep
1-Wire DATA
sleep mode
support@ruptela.com | +370 5 2045030
FM-Eco4 light T
FM-Eco4 light+ T
FM-Eco4 light+ 3G T
Indication LEDs
Wire color Description
Power supply
Red
6/12/24V
Ground
Black
connection
Pink Digital input 1
Blue Digital input 2
White Digital input 3
Yellow Digital input 4
Grey Analog input 1
Green Analog input 2
Purple Digital output 1
Orange Digital output 2
White/Red 1-Wire power
Green/Yellow 1-Wire data
1
