Mini F 1-2 Pump Cold Water
Booster Sets Fixed Speed
Operating and Maintenance Instructions
Declaration of conformity
Lowara pumps UK declare that the Mini F Booster set conforms to the requirements of the Machinery Safety
Directive
Conforming to the UK Health & Safety Requirements
Water supply (Water fittings) regulations
Simple pressure vessel directive
Signed:
t
Clive Willmot
Introduction
This leaflet contains information to enable the safe installation and operation of the products mentioned.
The following instructions must be read and understood by all persons responsible for the installation,
operation and maintenance of this product.
Warning Symbols
Safety instructions where noncompliance would affect safety.
Safety instruction where electrical hazard is involved.
Safety instruction where noncompliance could cause damage to the equipment.
Instruction for safe us
This product has been designed for boosting cold water in potable water installations to the
operating conditions shown.
This product should not be installed until this leaflet has been studied carefully and understood.
Handling, transportation and installation of this equipment should only take place with the proper
use of lifting equipment. This product must be stored in a frost-free dry environment.
Noise Emission
This equipment operates at a noise level lower than 70dBA.
Operating limits
Fluid temperature
Ambient temperature
Operating pressure
Protection class. Motor & Electrical panel
98/37/EEC.
1999
87/404/EEC
Position: Engineering manager
0°C to 40°C
0°C to 40°C
Max 5Bar.
IP55
1
S.I. 1992 No 3073 S.I. 1994 No 2063
Date: 27-02-2012 Revision
