Digital Loggers Ethernet Power Controller 5 User Manual page 5

IP Setup
If your network settings won't access the default IP, use a direct
cable connection (temporarily bypass any switch or router)
and follow these steps to add a compatible static IP, such as
192.168.0.50 Before adding an IP, close all programs and
browsers. After the link is established, you can enable WiFi or
revert to DHCP.
Windows Step 1
In Windows, the fi rst step is locating the network adapter TCP/IP
properties. The procedure differs for each Windows version:
Open Start / Control Panel / Network
Windows XP, 2000, 2003:
Connections. In "classic view", select Start / Settings / Control
Panel /Network Connections. Right-click on Local Area
Network Connection and select Properties. Proceed to step 2.
Windows Vista: Open Start, right click on Network, then on
Properties. Double click Network and Sharing Center, click
Manage Newtork Connections. A Network Connections window
appears. Right click on the network connection to the switch, ie.
Local Area Network. Proceed to step 2.
Windows 7: Open the Start orb, click on Control Panel. Click
View Network Status and Tasks, then Change Adapter
Settings. Proceed to step 2
Windows 8: Mouse or swipe to the bottom right corner and select
Settings. Select Control Panel. Select Network and Sharing
Center. Change Adapter Settings. Right click on your connected
network and select Properties. Proceed to step 2
Ethernet Power Controller 5 5
