Use the keypad for local control: Select an outlet using the
arrow keys, then press on, off, or cycle. Press ON or OFF for
5 seconds to lock or unlock an outlet. Locking prevents web
access. To change the display move, press the up and down
arrows simultaneously. The keypad may be disabled on the

Setup page.

You may want to Cycle a device which is connected to the
controller. This feature is useful for rebooting Ethernet devices
which may interrupt the web link to the controller. Clicking Cycle
switches power off, waits for the ON Delay time, and then
switches power back on. This reboots the attached device.
You can also cycle all outlets
using the Master Control on the
bottom of the page. An adjustable
ON sequence delay takes effect
when cycling, when using All
Outlets ON and on power-up.
Depending on your web browser settings, you may need to click
the Refresh button or F5 key to update the on-screen status
display after changing settings. Screen refresh rate is adjusted
in two places: on the Setup page and in your browser settings.
Setup Page
The Setup page allows the admin to confi gure:
Controller and Outlet Names
Use the controller name fi eld to assign a Controller Name to
the power controller itself. An example is Server Rack 4 PDU..
The Controller Name will appear on top of all pages. Assign a
separate name to each outlet, such as DSL Router 1 or Email
Server to aid identifi cation. Check the Confi rm button to the
right of the outlet name if you would like a pop-up window to
appear before switching critical outlets.
