Important Factory Defaults
IP: 192.168.0.100
User name: admin
(lower case)
Password: 1234
To reset to factory defaults,
gently press the reset-to-
defaults button below the LCD
to enter the reset menu, then select a reset option.

Quick Setup

Use these shortcuts if you are an experienced installer. We
recommend reading the entire manual for fi rst-time installation.
• Unpack. Save the carton. Attach line cords to 15A circuits.
• Attach an Ethernet cable from the controller to your LAN. Switch
power on. If you are attached through a switch, you may need to
cycle switch power to establish a connection.
• Ping the default address 192.168.0.100 to confi rm that a
network connection is established. If you don't receive a response,
proceed to the IP Setup section below.
• Log in to the power controller using the default user name
admin and the password 1234 Note: "admin" must be entered in
lower case.
• Click the Settings link to reach the confi guration page.
the safest power-loss confi guration
all ON, or sequential ON)
• Confi gure the power switch as described below. After each
change, click Submit and wait for the page to refresh before
continuing.
Tip:
• A three-bulb electrical safety-tester is handy for confi guring the
controller before attaching your equipment.
4 Ethernet Power Controller 5
for your installation: (all OFF,
digital-loggers.com
Select
