Panasonic CS-V18VKF Operating Instructions Manual
  1. Manuals
  2. Brands
  3. Panasonic Manuals
  4. Air Conditioner
  5. CS-V18VKF
  6. Operating instructions manual

Panasonic CS-V18VKF Operating Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
Operating Instructions
Air Conditioner
Model No.
Indoor Unit
CS-V18VKF
CS-V24VKF
Name and Address of Manufacturer:
Panasonic Appliances Air-Conditioning Malaysia Sdn. Bhd.
Shah Alam, Selangor, MALAYSIA
Name and Address of Importer:
Panasonic Marketing Middle East & Africa FZE
Jebel Ali, Dubai, UNITED ARAB EMIRATES
ACXF55-24430_FA0319-0.indb 1
ACXF55-24430_FA0319-0.indb 1
Outdoor Unit
CU-V18VKF
CU-V24VKF
١٣-٢
‫ﻗﺒﻞ ﺗﺸﻐﻴﻞ ﺍﻟﻮﺣﺪﺓ، ﻳ ﹸ ﺮﺟﻰ ﻗﺮﺍﺀﺓ ﺗﻌﻠﻴﻤﺎﺕ ﺍﻟﺘﺸﻐﻴﻞ ﺑﻌﻨﺎﻳﺔ ﻭﺍﻻﺣﺘﻔﺎﻅ‬
‫ﻳﺠﺐ ﺍﻟﺤﻔﺎﻅ ﻋﻠﻰ ﺗﻌﻠﻴﻤﺎﺕ ﺍﻟﺘﺮﻛﻴﺐ ﺍﻟﻤﻀﻤﻨﺔ، ﻛﻤﺎ ﻳﺠﺐ ﺃﻥ ﻳﻘﺮﺃﻫﺎ‬
‫ﻭﺣﺪﺓ ﺍﻟﺘﺤﻜﻢ ﻋﻦ ﺑ ﹸ ﻌﺪ ﻣﻀﻤﻨﺔ ﺩﺍﺧﻞ ﺍﻟﻮﺣﺪﺓ ﺍﻟﺪﺍﺧﻠﻴﺔ ﻭﻳﻘﻮﻡ ﺍﻟﻘﺎﺋﻢ‬
Operating Instructions
Air Conditioner
Before operating the unit, please read these operating
instructions thoroughly and keep them for future reference.
The included Installation Instructions should be kept and
read by the installer before installation.
Remote control is packaged in the indoor unit and
removed by the installer before installation.
‫ﺗﻌﻠﻴﻤﺎﺕ ﺍﻟﺘﺸﻐﻴﻞ‬
‫ﺟﻬﺎﺯ ﺍﻟﺘﺒﺮﻳﺪ‬
.‫ﺑﻬﺎ ﻟﻠﺮﺟﻮﻉ ﺇﻟﻴﻬﺎ ﻓﻲ ﺍﻟﻤﺴﺘﻘﺒﻞ‬
.‫ﺍﻟﻘﺎﺋﻢ ﺑﺎﻟﺘﺮﻛﻴﺐ ﻗﺒﻞ ﺍﻟﺘﺮﻛﻴﺐ‬
.‫ﺑﺎﻟﺘﺮﻛﻴﺐ ﺑﺈﺯﺍﻟﺘﻬﺎ ﻗﺒﻞ ﺍﻟﺘﺮﻛﻴﺐ‬
14-25
ACXF55-24430
2/27/2019 3:15:29 PM
2/27/2019 3:15:29 PM
