- Page 1 OWNER’S GUIDE PRO ATTIC GABLE FAN AFG PRO-2.0 DO NOT THROW AWAY! SERIAL NUMBER FOR FAN IS LOCATED ON THE BACK COVER OF THE OWNER’S GUIDE. LEAVE WITH HOMEOWNER...
-
Page 2: Table Of Contents
3. WIRING ..........6 3.1 Thermostat Wiring - AFG PRO-2.0 ..... . . 6 3.2 Remote Thermostat Wiring - AFG PRO-2.0 . -
Page 3: System Overview
QuietCool Attic Fan! QuietCool Attic Fans are the best in the business. New for 2020, the AFG PRO-2.0 is the attic fan that offers the best value at the best price point. With two available speeds with an energy efficient PSC motor,... -
Page 4: System Venting Requirements
Venting plays a very significant role in the performace of QuietCool fans. QuietCool recommends a mini- mum of 1 SQ. FT. of venting for every 750 CFM in the QuietCool system. If an attic has at least 1:750 attic venting, the QuietCool system will operate efficiently and effectively. If an attic has less than 1:750 attic venting, the system may not operate as efficiently, or effectively, as it could with 1:750 attic venting. -
Page 5: Installation
Vent should be installed in the upper center section of the gable. 1. Installing the QuietCool AFG is very easy. To install the AFG, simply mount the gable fan to your gable vents as shown in the following steps: Figure 2.1A... -
Page 6: Installing Afg Vent Covers
Figure 2.1A Included with your QuietCool Attic Gable Fan are four vent covers that are designed to be installed around the attic fan housing to block any air backdrafting into the attic through a gable vent that is larger than the attic fan cylinder, causing air to cycle in and out around the vent. -
Page 7: Remote Thermostat Wiring - Afg Pro-2.0
5. Tie the black wire from the power source to the remaining black wire from the thermostat. 6. Using the ground screw in the thermostat, ground your power source and the green wire from the fan. 7. Mount the thermostat to one of the joists near the attic fan. Figure 3.1A ®... - Page 8 120° 60° Junction ® ADJUSTABLE TEMPERATURE THERMOSTAT CAUTION Automatically started device - to reduce the risk of injury disconnect from power supply before servicing. For residential use only. See 14-2 Wire 14-2 Wire instructions for wiring diagram. Power Source 1-888-QUIETCOOL...
-
Page 9: System Operating Instructions
4. SYSTEM OPERATING INSTRUCTIONS SETTING THE THERMOSTAT The thermostat for your Pro Attic Gable Fan is a simple way to control your attic fan. The thermostat can be adjusted to any temperature between 60º and 120º. Whatever temperature you set the thermostat to will cause your attic fan to turn on when your attic temperature is at or above the set temperature. -
Page 10: How To Use Attic Fans
USING YOUR QUIETCOOL ATTIC FAN Attic fans are designed to cool and ventilate your attic all year long. Depending on the month of the year, you will want to change the temperature setting of your thermostat. SUMMER MONTHS In the summer, the attic in your home can reach temperatures in excess of 150ºF. -
Page 11: Warranty
QC Manufacturing Inc. extends this warranty to the original purchaser of the following QuietCool Specialty Series Fans - AFG SMT ES-3.0, AFG SMT PRO-3.0, AFG SMT PRO-2.0, and AFR SMT ES-2.0 - installed and used in a residence under normal conditions within the United States: A. - Page 12 Rev. 4/16/20 FAN SERIAL NUMBER INFORMATION RETAIN FOR YOUR RECORDS. SERIAL NUMBER IS REQUIRED FOR WARRANTY PURPOSES. 1-888-QUIETCOOL | WWW.QUIETCOOLSYSTEMS.COM...
