Summary of Contents for QuietCool RF
- Page 1 OWNER’S GUIDE ENERGY SAVER WHOLE HOUSE FAN RF Models DO NOT THROW AWAY! SERIAL NUMBER FOR FAN IS LOCATED ON THE BACK COVER OF THE OWNER’S GUIDE. LEAVE WITH HOMEOWNER...
-
Page 2: Table Of Contents
1. HOW TO USE YOUR QUIETCOOL........3... -
Page 3: How To Use Your Quietcool
The result is an easy installation and quiet operation. Once the air outside is cooler than the indoor air, crack open a few windows, turn your QuietCool on, and enjoy the hot air being sucked out of your home and pushed out of your attic with a nice, cool breeze. -
Page 4: When To Run
The breeze will flow through your home and make its way to each QuietCool you have in operation. As it gets later in the evening, and even cooler outside, you can begin to open windows in other rooms of your home, to prepare for bedtime. -
Page 5: Indoor Air Quality
1.7 USING QUIETCOOL DURING THE WINTER During the winter, you can use the QuietCool to warm up your home during the warmer parts of the day. Usually this occurs mid-day. By running the QuietCool during the warmer parts of the day in the winter, you can heat up the thermal mass in your home so your heater doesn’t have to work as hard. -
Page 6: System Overview
J. DUCT COLLAR - The adjustable collar that helps seal and secure the Heavy Duty Steel Housing and the Airtight Damper Box with no air leakage. K. ULTRA-ENERGY EFFICIENT ECM MOTOR - The Electronically Commutated Motor is the most energy efficient motor available in a QuietCool Whole House Fan. 1-888-QUIETCOOL... -
Page 7: System Venting Requirements
Venting plays a very significant role in the performance of QuietCool fans. QuietCool recommends a minimum of 1 SQ. FT. of venting for every 750 CFM in the QuietCool system. If an attic has at least 1:750 attic venting, the QuietCool system will operate efficiently and effectively. If an attic has less than 1:750 attic venting, the system may not operate as efficiently, or effectively, as it could with 1:750 attic venting. -
Page 8: General Safety Information
4. FOLLOW INSTRUCTIONS - All installation and operating instructions should be followed. 5. WATER - The QuietCool system should not be used near water. If you live in a very humid climate, be sure to cover your damper box with insulation to reduce condensation. -
Page 9: Special Instructions
SPECIAL INSTRUCTIONS TO DO-IT-YOURSELFERS 1. DO NOT attempt to install any QuietCool cooling and ventilation system yourself if you lack sufficient skill and experience to do so. 2. WATCH the installation videos on the manufacturer website by visiting www.QuietCoolSystems.com/support or by scanning any QR code found in this guide that appears next to any instructional step. -
Page 10: Installation
Installing the QuietCool system is very easy. Simply follow the steps given below: Determine from down below in which areas you would like to install your QuietCool fan. Go up into the attic to mark the exact location for the fan. Make sure you have a minimum of 30” of clearance. Take the cardboard cutout template and a small screwdriver with you. - Page 11 NOTE: Once your QuietCool fan is hung, it’s time to go below and install the damper box and ceiling grille. NOTE: If you are installing the damper box with a vertical adapter, please follow the instructions on page 12. 7. Look through the hole and make sure there are no kinks or twists in the ducting. Pull the damper box down through the hole in the ceiling.
-
Page 12: Installing Vertical Adapter
4. Using the included black sharp screws, attach the vertical adapter to the damper box by screwing them together through the two remaining flanges. 5. The vertical adapter is now installed. Go back to step 8 on page 10 and continue your installation. 1-888-QUIETCOOL... -
Page 13: Wiring
4. WIRING AND CONTROLS IMPORTANT: Wiring Diagrams are for examples ONLY. Wiring should be done by a licensed electrician following local building and electrical codes and/or NEC guidelines. NOTE FOR NEW CONSTRUCTION: Where use of arc-fault breakers are 100% implemented in the home, or if the whole house fan is installed in a wet area such as a bathroom, wiring a dedicated circuit may be required. -
Page 14: Two Speed Wiring - For 2250 Model
10. If the fan doesn’t operate as described in step 9, please check the dip switch position. Figure 4.2A Attach green ground wires to ground screw Set dip switches: 1 - OFF 2 - ON 3 - OFF POWER TIMER TEST PAIR Whole House Fan Power Cord All White Common Wires Together 1-888-QUIETCOOL... -
Page 15: Two Speed Wiring - For 3100 And Up Models
4.3 TWO SPEED WIRING (for 3100 and up models) 1. Using a wire nut, connect the black wire from the power cord and the black wire from the fan to the black wire from the Hub. 2. Connect the white wire from the power cord and the white wire on the fan to the white wire from the Hub. -
Page 16: Rf Control Hub - Led Indicators
2. Press and hold the Pair button on the Hub. The Pair LED indicator will be on for three seconds then turn off. This clears all previous pairings out of the Hub, 3. Press the Pair button on the Hub twice. The Pair LED indicator will blink once every second indicating the Hub is in pairing mode 1-888-QUIETCOOL... -
Page 17: Finding A Location For The Wall Switch
4. Press either one of the buttons on the Wall Switch to wake it up. Now hold one of the buttons on the switch. The Pair LED indicator on the Hub will go out and the Wall Switch speed indicators will be blinking indicating successful pairing. Press the Wall Switch button again, the speed indicators will go out, and it will display the current fan status. -
Page 18: System Operating Instructions
In order for the fan to run, a Timer selection MUST be made. When the Timer status is off (no LED indicators lit), you can still change the Speed setting. The Speed setting will take effect once the Timer selection is made. 1-888-QUIETCOOL... -
Page 19: Frequently Asked Questions
The RF Switch and RF Hub have a range restriction of 100ft. WHAT HAPPENS IF I LOSE THE RF SWITCH? If you lose or damage an RF Switch you will need to purchase another and re-pair the new one to the RF Hub. -
Page 20: Warranty
No subsequent purchaser of the unit or of a home in which it is installed is entitled to any of the benefits of this warranty. The QuietCool Product that you have purchased has a limited warranty from the date of purchase against defects in workmanship and materials. - Page 21 The electrical motor is to be used solely as a direct replacement for a motor of the same model in QC Manufacturing, Inc., QuietCool products. Using the motor in any other product could result in electrical shock and/ or fire, which may cause property damage, serious injury or even death. Any motor replacement should be installed by a qualified licensed electrician in accordance with local, state and national electrical codes and standards.
- Page 22 Rev. 10/16/24 FAN SERIAL NUMBER INFORMATION RETAIN FOR YOUR RECORDS. SERIAL NUMBER IS REQUIRED FOR WARRANTY PURPOSES. 1-888-QUIETCOOL | WWW.QUIETCOOLSYSTEMS.COM...
