ADTRAN TSU ESP Quick Start Manual

Network
T1
N C
ETWORK ONNECTION
Pin Name
1 R1 RXDATA
2 T1 RXDATA
3, 6, 7, 8 UNUSED
4 R TXDATA
5 T TXDATA
R P D
EAR ANEL ESCRIPTIONS
Network Connector Connection to T1 circuit
Test Interface Bantam jacks provided for monitoring and testing
Control In/Out Connection to a VT100 terminal or emulator
V.35 Connector High-speed DTE interface
Power Switch Turns power to the TSU on or off
Power cord connection for a reliably grounded
115 VAC Connection
115 VAC, 60 Hz power source
DBU Interface ESP DBU card slot
LAN Interface ESP Ethernet card slot
Quick Start Guide, 61200169L1-13A, February 2002
TSU ESP
DBU Card Slot
VT 100 Terminal or device running
SLIP or async PPP protocol.
P
INOUT
Description
Receive data from the Network - Ring
Receive data from the Network - Tip
n/a
Transmit data towards the Network - Ring
Transmit data towards the Network - Tip
Technical Support 1-888-4ADTRAN (1-888-423-8726)
For more detailed documentation, visit us online at
LAN Card Slot
I I
NSTALLATION NFORMATION
• An eight-position modular jack (labeled N
the network T1 circuit. The pinout is provided on this Quick Start Guide. See
Chapter 2, Installation, of the TSU ESP User Manual for more information.
• The rear panel contains a single V.35 interface for connecting to DTE
equipment. The pinout for this interface is located in Appendix A of the TSU
ESP User Manual.
• When shipped from the factory, the TSU ESP is uninitialized and set to factory
default conditions. Upon the first application of power, the unit will
automatically execute self-tests followed by an initialization sequence.
• The TSU ESP can be configured and controlled using the local front panel of
the unit, a VT 100 terminal or emulator connected to the chain-in port,
ADTRAN's PC Control Program, T-WATCH, or using SNMP or Telnet through
the ethernet port. A limited menu tree is provided on the back of this sheet. For
more detailed menu information, refer to the TSU ESP User Manual.
• Additional information can be found on the product CD which contains the TSU
ESP User Manual, FAQs, Data Sheets, Applications, and White Papers.
www.adtran.com
P/N 1200169L1
) is provided to connect to
ETWORK
Copyright  2001 ADTRAN, All Rights Reserved
