Assa Abloy Norton J1600 UniTrol Installation

J1600 UniTrol
®
Non Handed Door Closer
Top Jamb Mount
Non Hold Open
Hold Open (H)
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
Included Components (See page 2 for mounting hardware)
TO DETERMINE
HAND OF
To Determine Your Hand of Door:
YOUR DOOR:
Right Hand
Reverse
LEFT
HAND
DOOR
Copyright © 2016, 2020, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9316-2534-020 Rev 2 04/20
(UL Listed)
(Not UL Listed)
Hold Open Control
(Hold Open Models)
Left Hand Door - LH
Right Hand Reverse - RHR
Arm Foot
Main Arm
Screw
Main Arm
Hold Open Control
To Identify Your Model:
Left Hand
Reverse
RIGHT
HAND
DOOR
Sized Adjustable
(Sizes 3,4) (Sizes 1-6)
UNI-J1603BC (H) UNI-J1601 (H)
UNI-J1604BC (H)
Ce produit peut vous exposer au plomb qui, dans l'état de la Californie,
est reconnu pour causer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez:
www.P65warnings.ca.gov.
UNI-J1600 (H)
Right Hand Door - RH
Left Hand Reverse - LHR
Sleeve-nut
Rod Unit
(Arm Number Stamp)
Rod Screws
Forearm
1-6 = 1601
3 = 1603BC
4 = 1604BC
Hold Open Control
(Hold Open Models)
Optional Components
1687Drop Plate
For low ceiling
clearance
Tools Needed
Hold Open
