Assa Abloy NORTOX RIXSON JS7500 Quick Start Manual

JS7500
Non Handed Door Closer
Top Jamb Mount
With or without DA suffix (delayed action)
With or without M suffix (metal cover)
WARNING
This product can expose you to lead which is known to the state of
California to cause cancer and birth defects or other reproductive harm.
For more information go to www.P65warnings.ca.gov.
Top Jamb Mount shown on 2" frame face with optional 7786 backplate (sold separately)
Included Components (See page 2 for mounting hardware)
Cover
Standard Plastic
or Optional Metal
TO DETERMINE
HAND OF
To Determine Your Hand of Door:
YOUR DOOR:
Right Hand
Reverse
LEFT
HAND
DOOR
Copyright © 2001, 2014, 2021, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole
or in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9377-1218-020 Rev 3 12/21
Left Hand Door - LH
Right Hand Reverse - RHR
DA Option
(5 Valves)
Closer
Regular Arm/
Top Jamb Shoe
1/8" Hex Wrench
Screw Pack
To Identify Your Model:
Older models may
be stamped "1-6",
"1-4" or "2-6". They
Left Hand
can be replaced
Reverse
with a newer "1-6"
model which has
RIGHT
no stamp.
HAND
DOOR
Standard S7500 = 4 valves
Delayed Action S7500DA = 5 valves
Non Hold Open Arm Models
Adjustable
(Sizes 1-6)
Ce produit peut vous exposer au plomb qui, dans l'état de la Californie,
est reconnu pour causer le cancer, des anomalies congénitales ou d'autres
problèmes de reproduction. Pour plus d'informations, visitez:
www.P65warnings.ca.gov.
Right Hand Door - RH
Left Hand Reverse - LHR
Main Arm
Pinion Screw
Arm Assembly
Shoe
Connecting Rod
Forearm
Screw
Optional Components
Main Arm
Arm Slide
Tools Needed
NORTON
RIXSON
7786
Backplate
Drop Plate
