Ubiquiti PowerBeam AC Gen2 Quick Start Manual

5 ghz high-performance airmax ac bridge
Hide thumbs
Table of Contents

Advertisement

Quick Links

PBE-5AC-Gen2 Quick Start Guide
Package Contents
Dish Reflector
5 GHz High-Performance airMAX® AC Bridge
Model: PBE-5AC-Gen2

Table of Contents

Package Contents
Installation
Mounting Bracket
Compliance
Carriage Bolts (Qty. 2)
https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]
×
Power Cord
PBE-5AC-Gen2 Quick Start Guide
Antenna Feed
Hex Bolts with Washers (Qty. 4)
Flange Nuts (Qty. 2)
Rear Housing
Pole Clamp
Gigabit PoE (24V, 0.5A) with Mounting Bracket

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PowerBeam AC Gen2 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ubiquiti PowerBeam AC Gen2

Summary of Contents for Ubiquiti PowerBeam AC Gen2

  • Page 1: Table Of Contents

    PBE-5AC-Gen2 Quick Start Guide × PBE-5AC-Gen2 Quick Start Guide Package Contents Dish Reflector Antenna Feed Rear Housing 5 GHz High-Performance airMAX® AC Bridge Model: PBE-5AC-Gen2 Table of Contents Package Contents Installation Requirements Hardware Overview Application Examples Installation Mounting Bracket Hex Bolts with Washers (Qty. 4) Pole Clamp Accessing airOS via Wi-Fi Installer Compliance Responsibility...

  • Page 2: Installation Requirements

    AC ground of the PoE. We recommend that you protect your networks from harmful outdoor environments and destructive ESD events with industrial- grade, shielded Ethernet cable from Ubiquiti. For more details, visit ui.com/toughcable Surge protection should be used for all outdoor installations. We recommend that you use two Ethernet Surge Protectors, model ETH- SP, one near the PowerBeam and the other at the entry point to the building.
  • Page 3 PBE-5AC-Gen2 Quick Start Guide Ethernet This Gigabit Ethernet port is used to connect the power and should be connected to the LAN and DHCP server. Reset Button To reset to factory defaults, press and hold the Reset button for more than 10 seconds while the device is powered on. Alternatively, the device may be reset remotely via a Reset button located on the bottom of the Gigabit PoE Adapter.

  • Page 4: Application Examples

    PBE-5AC-Gen2 Quick Start Guide Signal In airOS®, you can modify the threshold value for the wireless signal strength LEDs on the Wireless tab under Signal LED Thresholds. Each LED will light when the wireless signal strength is equal to or greater than the LED’s threshold value. The default threshold values for these LEDs are shown below: Ethernet The Ethernet LED will light steady blue when an active Ethernet connection is made and flash when there is activity.
  • Page 5 PBE-5AC-Gen2 Quick Start Guide The PowerBeam mounted outdoors without the Dish Reflector installed provides outdoor-to-indoor coverage using the 3 dBi Antenna Feed only. Installation https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 6 PBE-5AC-Gen2 Quick Start Guide https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 7 PBE-5AC-Gen2 Quick Start Guide Note: In high-wind environments, you can add support with additional hardware (not included): https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 8 PBE-5AC-Gen2 Quick Start Guide a. Using the four holes in the Adjustment Bracket as a template, drill four holes into the Dish Reflector with a 4.4 mm or 11/64" drill bit. b. Secure the Dish Reflector to the Adjustment Bracket using M4 screws, washers, and nuts (not included). https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 9 PBE-5AC-Gen2 Quick Start Guide https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 10 PBE-5AC-Gen2 Quick Start Guide https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 11 PBE-5AC-Gen2 Quick Start Guide https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 12 PBE-5AC-Gen2 Quick Start Guide https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
  • Page 13 PBE-5AC-Gen2 Quick Start Guide 11. Connect the power using: included Gigabit PoE Adapter PoE switch WARNING: The switch port must comply with the power specifications listed in this Quick Start Guide. Connecting to the PoE Adapter https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...

  • Page 14: Accessing Airos Via Wi-Fi

    PBE-5AC-Gen2 Quick Start Guide 1. Connect the Ethernet cable from the device to the POE port of the PoE adapter. 2. Connect an Ethernet cable from your LAN to the LAN port of the PoE adapter. 3. Connect the Power Cord to the adapter, and then plug the Power Cord into a power outlet. Mounting the PoE Adapter (Optional) 1.
  • Page 15 PBE-5AC-Gen2 Quick Start Guide Note: Ensure that DHCP is enabled on your Wi-Fi adapter. 3. Launch the app and follow the on-screen instructions. Web Portal 1. Connect your device’s Wi-Fi to the SSID named: <model>:<MAC Address> Note: Ensure that your Wi-Fi connection has DHCP enabled. 2.

  • Page 16: Installer Compliance Responsibility

    PBE-5AC-Gen2 Quick Start Guide The airOS Configuration Interface will appear, allowing you to customize your settings as needed. For additional details, refer to the User Guide available at ui.com/download/airmax-ac Installer Compliance Responsibility Devices must be professionally installed and it is the professional installer’s responsibility to make sure the device is operated within local country regulatory requirements.

  • Page 17: Specifications

    PBE-5AC-Gen2 Quick Start Guide Antenna Select your antenna from the list. If Calculate EIRP Limit is enabled, transmit output power is automatically adjusted to comply with the regulations of the applicable country. For a Custom antenna, Antenna Gain is entered manually. Note the requirements and antenna types listed below.
  • Page 18 PBE-5AC-Gen2 Quick Start Guide (16.54 x 16.54 x 9.06") Weight 2.22 kg (4.89 lb) Gain 25 dBi Networking Interface (1) 10/100/1000 Ethernet Port Processor MIPS 74Kc Enclosure Characteristics Antenna Feed Outdoor UV Stabilized Plastic Dish Reflector Powder-Coated SPCC Max. Power Consumption 8.5W Max.

  • Page 19: Safety Notices

    PBE-5AC-Gen2 Quick Start Guide Safety Notices 1. Read, follow, and keep these instructions. 2. Heed all warnings. 3. Only use attachments/accessories specified by the manufacturer. WARNING: Do not use this product in location that can be submerged by water. WARNING: Avoid using this product during an electrical storm.
  • Page 20 PBE-5AC-Gen2 Quick Start Guide required to correct the interference at his own expense. This radio transmitter has been approved by FCC. ISED Canada CAN ICES-3(A)/NMB-3(A) This device complies with ISED Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: 1.

  • Page 21: Declaration Of Conformity

    PBE-5AC-Gen2 Quick Start Guide Brazil Nota: Este equipamento não tem direito à proteção contra interferência prejudicial e não pode causar interferência em sistemas devidamente autorizados. CE Marking CE marking on this product represents the product is in compliance with all directives that are applicable to it. Country List BFWA (Broadband Fixed Wireless Access) members noted in blue Note:...

  • Page 22: Online Resources

    PBE-5AC-Gen2 Quick Start Guide Online Resources © 2020 Ubiquiti Inc. All rights reserved. https://dl.ubnt.com/qsg/PBE-5AC-Gen2/PBE-5AC-Gen2_EN.html[4/17/2020 8:58:22 AM]...
