SERVICE MANUAL
UFOELK - 2/21/2018 5:48 PM
Ver. 1.1 2014.01
Note:
Be sure to keep your PC used for service and
checking of this unit always updated with the
latest version of your anti-virus software.
In case a virus affected unit was found during
service, contact your Service Headquarters.
Design and specifications
Capacity (User available capacity: when the
built-in memory is formatted with the
linear PCM recorder)
32 GB (approx. 25.60 GB =
27,487,790,694 Byte)
A part of the memory capacity is used
as a management area.
Maximum number of folders (f or a drive)
400 folders
Maximum number of files (for a folder)
199 files
Maximum number of files (for a drive)
4,074 files (When 21 folders are
contained in a drive.)
Frequency range
(Input from the LINE IN (OPT) jack,
output from the LINE OUT (OPT) jack
when recording/playing back) (0 dB to
DSD 2.8MHz/1bit (STEREO):
20 Hz - 50,000 Hz
(Input from the LINE IN (OPT) jack,
output from the LINE OUT (OPT) jack
when recor ding/playing back) (0 dB to
LPCM 192kHz/24bit:
LPCM 176.4kHz/24bit:
LPCM 96kHz/24,16bit:
LPCM 88.2kHz/24,16bit:
LPCM 48kHz/24,16bit:
LPCM 44.1kHz/24,16bit:
MP3 320 kbps: 20 Hz - 20,000 Hz
MP3 128 kbps: 20 Hz - 16,000 Hz
Compatible file formats*
1
*1 Not all encoders are supported.
DSD
Bit rate: 1 bit
Sampling frequencies: 2.8224 MHz
File extension: .dff, .dsf
FLAC
Bit rate: 24/16 bit
Sampling frequencies:
44.1/48/88.2/96/176.4/192 kHz
File extension: .flac
CAUTION
Danger of explosion if battery is incorrectly replaced.
Replace only with the same or equivalent type.
9-893-898-02
Sony Corporation
2014A33-1
©
2014.01
Published by Sony Techno Create Corporation
SPECIFICATIONS
Total harmonic distortion (Input from the LINE
FLAC
Bit rate: 16 bit
Sampling frequencies: 22.05 kHz
File extension: .flac
Linear PCM
Bit rate: 24/16 bit
Sampling frequencies:
44.1/48/88.2/96/176.4/192kHz
File extension: .wav
Linear PCM
Speaker
Bit rate: 16 bit
Sampling frequencies: 22.05 kHz
Input/output
File extension: .wav
MIC (microphone) jack (stereo mini jack)
MP3*
2
Bit rate: 32 kbps - 320 kbps (Supports
variable bit rate (VBR))
Sampling frequencies:
(headphone) jack (stereo mini jack)
16/22.05/24/32/44.1/48 kHz
File extension: .mp3
*
The playback of MP3 files recorded using the
2
linear PCM recorder is also supported.
LINE IN (OPT) jack
WMA
*3
Bit rate: 32 kbps - 192 kbps(Supports
variable bit rate (VBR))
Sampling frequencies: 44.1 kHz
File extension: .wma
*
3
WMA Ver. 9 is compatible, however, MBR (Multi
LINE OUT (OPT) jack
Bit Rate), Lossless, Professional, and Voice are
not supported. Copyright-protected file cannot
be played back.
AAC-LC*
4
Bit rate: 16 kbps - 320 kbps (Supports
variable bit rate (VBR))
Sampling frequencies: 11.025/12/16/
22.05/24/32/44.1/48 kHz
DC IN 6V jack (EIAJ connector)
File extension: .m4a
USB connector (micro-B, Hi-speed USB, Mass
*
4
Copyright-protected file cannot be played back.
Signal-to-noise ratio (S/N) (Input from the LINE
Card slot
IN (OPT) jack, output from LINE OUT
(OPT) jack when recording/playing
Playback speed control (DPC)
back) (1 kHz IHF-A)
DSD 2.8MHz/1bit: 98 dB or above
LPCM 192kHz/176.4kHz/96kHz/88.2
General
kHz/48kHz/44.1 kHz 24bit: 96 dB or
Maximum power output
above (for S/N 100dB OFF)/100 dB
or above (for S/N 100dB ON)
Power requirements
PCM-D100
Power consumption
IN (OPT) jack, output from LINE OUT
(OPT) jack when recording/playing
Operating temperature
back)
DSD 2.8MHz 1bit: 0.008% or below
Dimensions (JEITA)*
(1 kHz, 22 kHz LPF)
LPCM 192kHz/176.4kHz 24bit,
96kHz/88.2kHz/48kHz/44.1kHz
16bit/24bit: 0.006% or below (1 kHz,
Mass Approx. 395 g (including batteries)
22 kHz LPF)
*
5
Values measures according to JEITA (Japan
Approx. 16 mm dia.
Electronics and Information Technology Industries
Association) standards.
Supplied accessories
Input impedance: 22 k
Rated input level: 2.5 mV
Minimum input level: 0.7 mV
Rated output level: 400 mV
Maximum output level:
25 mW + 25 mW or more
Recommended load impedance: 16
Input impedance: 22 k
Rated input level: 2.0 V
Minimum input level: 450 mV
Input level: –27 dBm to –14 dBm
(for optical digital input)
Absorption wavelength:
660 nm (Typ) (for optical digital input)
Output impedance: 220
Rated output level: 1.7 V
Recommended load impedance: 22 k
Output level: –21 dBm to –15 dBm
(for optical digital output)
Storage Class)
Memory Stick
/SD memory card slot
2.00 times - 0.25 times (LPCM/MP3/
WMA/ AAC-LC/FLAC)
Design and specifications are subject to
change without notice.
200 mW
Four LR6 (size AA) alkaline batteries
(supplied)/AC adaptor (Chinese model: supplied,
Except Chinese model: not supplied):
Four nickel metal hydride rechargeable
batteries NH-AA (not supplied):
4.8 V DC
LINEAR PCM RECORDER
US Model
Canadian Model
AEP Model
E Model
Chinese Model
5 °C - 35 °C
5
Approx. 72.0 × 156.8 × 32.7 mm (w/h/d)
(not including projecting parts and
controls)
(JEITA)*
5
USB cable (1)
(Supplied in the carrying case)
AC adaptor AC-ES608K3 (6V) (1)
(Chinese model only)
Carrying case (1)
The external pocket can hold the remote
control (transmitter unit), and the inner
pocket can hold batteries and the battery
case.
Wind screen (1)
Wireless remote control (receiver unit (1) and
transmitter unit (1))
(Supplied in the carrying case)
Four LR6 (size AA) alkaline batteries
(Supplied in the carrying case)
DVD-ROM ("Sound Forge Audio Studio LE")
(1) (US, Canadian, AEP and E models only)
Operating Instructions
Using Sound Forge Audio Studio LE
The "Sound Forge Audio Studio LE" software
allows you to edit data, create a CD, and
perform other operations on your computer.
The Sound Forge Audio Studio LE software
does not support DSD files recorded with the
linear PCM recorder.
For an overview of the software and details
on installation procedures, refer to the
supplied manual "Using Sound Forge Audio
Studio LE."
– Continued on next page –

Advertisement

Table of Contents
loading

Summary of Contents for Sony PCM-D100

  • Page 1 4.8 V DC – Continued on next page – Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. LINEAR PCM RECORDER 9-893-898-02 Sony Corporation 2014A33-1 © 2014.01 Published by Sony Techno Create Corporation...
  • Page 2 Windows 7 Starter Ser vice Pack 1 or higher REC Mode Memor y card When using nick el metal hydride rechargeable batteries (Continuous using of Sony nickel Windows Vista Ultimate Ser vice Pack 2 or metal hydride rechargeable battery NH-AA) (not supplied)
  • Page 3: Table Of Contents

    LES DIAGRAMMES SCHÉMATIQUES ET LA LISTE DES PIÈCES SONT CRITIQUES POUR LA SÉCURITÉ DE FONC- TIONNEMENT. NE REMPLACER CES COMPOSANTS QUE PAR DES PIÈCES SONY DONT LES NUMÉROS SONT DON- NÉS DANS CE MANUEL OU DANS LES SUPPLÉMENTS PUBLIÉS PAR SONY.
  • Page 4: Servicing Notes

    2. On PC, unzip the model setting fi le (change_destination_ switch in the direction opposite to that specifi ed in step 3. PCM-D100.zip) to get folder on PC. 5. While pressing the [F1] and [T-MARK] keys, slide the [HOLD] 3. On PC, open the unzipped folder, and select the folder corre- switch in the direction opposite to that specifi...
  • Page 5 PCM-D100 8. Confi rm that the destination has been changed. (Displayed characters/values in the following fi gure are ex- ample) LCD Display <Version> PCM-D100 CN Destination ARM 1.00.01 OMF 4.11.63 SYS 20130906RB [ Stop ] :Ret 9. Press the [ STOP] key, return to test mode menu.
  • Page 6: Disassembly

    PCM-D100 SECTION 2 DISASSEMBLY • This set can be disassembled in the order shown below. 2-1. DISASSEMBLY FLOW 2-2. GUARD (MIC) 2-10. HP VOLUME ASSY (Page 7) (Page 12) 2-3. PANEL (FRONT) BLOCK 2-11. DA C BOARD (Page 8) (Page 13) 2-4.
  • Page 7: Guard (Mic)

    PCM-D100 2-2. GUARD (MIC) Note: When installing the guard (MIC), insert firmly it and Note: When installing the guard (MIC), insert firmly it and check that align the screw hole and panel (front) hole. check that align the screw hole and case hole.
  • Page 8: Panel (Front) Block

    PCM-D100 2-3. PANEL (FRONT) BLOCK 1 Slide the knob to “RELEASE” side. 2 Open the battery case lid. – Rear bottom view – 3 two stoppers (1.7) 4 panel (front) block – Front bottom view –...
  • Page 9: Lcd Assy (Lcd1)

    PCM-D100 2-4. LCD ASSY (LCD1) 4 LCD assy (LCD1) 2 two stoppers 3 two screws (M1.7 3.0) Note: When installing the LCD flexible board, check that it have inserted straight. No slanting after insertion. Insert is straight to the interior.
  • Page 10: Led Assy

    PCM-D100 2-6. LED ASSY [black] [yellow] AUDIO DA board 1 Remove the solder. 2 Peel off two [yellow] adhesive sheets. 1 Remove the solder. three bosses [black] 3 LED assy three bosses LED assy – – 2-7. POWER BOARD-1 Note: Continued on 2-8 (Page 11).
  • Page 11: Power Board-2

    PCM-D100 2-8. POWER BOARD-2 Note 2: When installing the POWER board, align two switches and two knobs. switch knob (POWER) 3 Move the POWER board in the direction of an arrow. switch Note 1: When installing the flexible flat cable, knob check that it have inserted straight.
  • Page 12: Sp Box Assy (Sp1)

    PCM-D100 2-9. SP BOX ASSY (SP1) 3 SP box assy (SP1) 2 Peel off the adhesive sheet (SP box). 1 boss 1 boss – Front top view – 2-10. HP VOLUME ASSY Note 1: When installing the HP VOLUME assy, push 2 screw the DA C board wire under the chassis (upper).
  • Page 13: C Board

    PCM-D100 2-11. DA C BOARD 6 DA C board DA C board AUDIO DA board 1 Remove the solder. [red] 1 Remove the solder. [gray] 3 Remove the DA C board in the direction of an arrow. [red] [gray] –...
  • Page 14: Audio Da Board

    PCM-D100 2-13. AUDIO DA BOARD 1 screw (M1.4) 5 AUDIO DA board 4 Draw out two jacks. 3 Remove the AUDIO DA board in the direction of an arrow. 2 connector (CN3301) – Front top view – 2-14. REC VOLUME ASSY...
  • Page 15: Chassis (Power)

    PCM-D100 2-15. CHASSIS (POWER) 4 chassis (power) UFOELK - 2/21/2018 5:48 PM < Sectional view > button (light) assy chassis (power) 3 rib 2 boss Note: When installing the chassis (power), insert the rib of chassis (power) under the button (light) assy.
  • Page 16: Chassis (Lower)

    PCM-D100 2-17. CHASSIS (LOWER) AUDIO AD board boss 1 two stoppers (M1.7 3.0) 2 chassis (lower) Note: When installing the chassis (lower), wire must not touch underside of MIC (L) assy. – Front bottom view – 2-18. AUDIO AD BOARD 2 screw (M1.4)
  • Page 17: Mic Sw Assy

    PCM-D100 2-19. MIC SW ASSY 1 two washerhead screws (P M1.4 3.5) 3 MIC SW assy Note 1: When installing the MIC SW switch lever Note 2: When installing the MIC SW assy, check that the MIC assy, insert two switch levers wire is arranged as shown in the following figure.
  • Page 18: Mic Assy (Mic1)

    PCM-D100 2-20. MIC ASSY (MIC1) Note 1: When replacing the MIC assy (MIC1), Met o o insta in t e MIC assy (MIC ) replace left and right at the same time. Note 2: Check the “R” mark not Do not replace only one side.
  • Page 19: Knob Assy

    PCM-D100 2-21. KNOB ASSY 3 knob assy 1 two stoppers (M1.7 3.0) 2 Remove the knob assy in the direction of an arrow. UFOELK - 2/21/2018 5:48 PM – Front bottom view – 2-22. PANEL (REAR) BLOCK 1 four foots (rear)
  • Page 20: Battery Case Lid Block

    PCM-D100 2-23. BATTERY CASE LID BLOCK et o o i ta i 4 shaft (lid lock) 3 spring (lid lock) 5 slider (BATT lid) 4 shaft (lid lock) 6 two screws 2 hook (M1.4) Note: When installing the spring (lid lock), install two hooks to numerical order.
  • Page 21: System Board

    PCM-D100 2-25. SYSTEM BOARD 3 two stoppers 1 Remove the two solders of battery terminals. (M1.7 3.0) 2 screw 6 SYSTEM board (M1.4) 4 Remove the SYSTEM board in the direction of an arrow. UFOELK - 2/21/2018 5:48 PM battery terminals 5 Draw out the flexible flat cabel and wires.
  • Page 22: Test Mode

    PCM-D100 SECTION 3 TEST MODE 1. SETTING THE TEST MODE 3. CONFIGURATION OF THE TEST MODE Note: Test mode is impossible when battery voltage is not enough. Do START work using the battery with suffi cient battery level. After turn on the power, stop or sleep condition.
  • Page 23 (Displayed characters/values in the following fi gure are ex- ample) [ STOP ] :Ret LCD of Display (page 1/3) <Version> Releasing method: PCM-D100 CN Press the [ STOP] key, return to test mode menu. Model name/Destination ARM 1.00.01 ARM version 4-3.
  • Page 24 PCM-D100 4-5. Power Down 4-7. LCD/Led/Light It can change into the power off state. The lighting check of LCD can be performed. Procedure: Procedure: 1. Enter the test mode. 1. Enter the test mode. (Refer to “SETTING THE TEST MODE” on page 22) (Refer to “SETTING THE TEST MODE”...
  • Page 25 PCM-D100 4-8. Log Output 4-10. Factory Ship The failure analysis log can be outputted. This unit can return to the factory shipment settings (LCD contrast is not initialized). Procedure: Procedure: 1. Enter the test mode. (Refer to “SETTING THE TEST MODE” on page 22) 1.
  • Page 26 PCM-D100 4-11. Sircs Check 4-12. Keychk+Factory Ship Operation of remote commander keys can be checked. Operation of keys and switches can be checked, and this unit can Note 1: This check requires remote commander and receiver unit. return to the factory shipment settings (LCD contrast is not initial- ized).
  • Page 27: Exploded Views

    PCM-D100 SECTION 4 EXPLODED VIEWS Note: • -XX and -X mean standardized parts, so • The mechanical parts with no reference they may have some difference from the number in the exploded views are not sup- original one. plied. • Items marked “*” are not stocked since •...
  • Page 28: Panel (Front) Section

    PCM-D100 4-2. PANEL (FRONT) SECTION • Rear view LCD section not supplied Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-476-280-01 CAP (GUARD REC) 3-252-825-01 SCREW (1.7) 4-470-836-01 SHAFT (GUARD REC) A-1971-524-A PANEL (FRONT) ASSY 4-473-716-01...
  • Page 29: Lcd Section

    PCM-D100 4-3. LCD SECTION POWER board section LCD1 UFOELK - 2/21/2018 5:48 PM Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-485-515-01 STOPPER (M1.7X3.0) 4-487-087-01 SPACER (REC VOL R) 3-254-082-01 SCREW 4-471-217-01 BELT (KNOB REC) A-1971-522-A...
  • Page 30: Power Board Section

    PCM-D100 4-4. POWER BOARD SECTION AUDIO AD, AUDIO DA board section Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 9-885-191-12 POWER BOARD, COMPLETE (for SERVICE) 4-470-812-01 KNOB (PLAY VOL) 3-254-082-01 SCREW 3-880-474-01 CUSHION, 15X5X0.3 4-485-515-01 STOPPER (M1.7X3.0)
  • Page 31: Audio Ad, Audio Da Board Section

    PCM-D100 Ver. 1.1 4-5. AUDIO AD, AUDIO DA BOARD SECTION microphone section AUDIO AD board AUDIO DA board not supplied UFOELK - 2/21/2018 5:48 PM Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark A-1969-105-A AUDIO DA BOARD, COMPLETE (US, Canadian, E)
  • Page 32: Microphone Section

    PCM-D100 Ver. 1.1 4-6. MICROPHONE SECTION MIC1 L-ch R-ch battery case lid section Note: When replacing the MIC assy (Ref. No. MIC1), replace left and right at the same time. Do not replace only one side. Ref. No. Part No.
  • Page 33: Battery Case Lid Section

    PCM-D100 4-7. BATTERY CASE LID SECTION • Rear view case section supplied UFOELK - 2/21/2018 5:48 PM Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-470-834-01 SPRING (LID LOCK) 3-254-082-01 SCREW 4-470-835-01 SHAFT (LID LOCK) 4-476-516-02...
  • Page 34: Case Section

    PCM-D100 Ver. 1.1 4-8. CASE SECTION • Rear view FFC1 SYSTEM board BT1351 Note: When replacing the SYSTEM board, refer to “ABOUT THE DESTINATION SETTING WHEN REPLACING THE SYS- TEM BOARD” on page 4. Ref. No. Part No. Description Remark Ref.
  • Page 35: Accessories

    PCM-D100 Ver. 1.1 SECTION 5 ACCESSORIES Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark 4-475-415-11 MANUAL, INSTRUCTION (Operating Instructions) 1-846-320-11 CABLE WITH CONNECTOR (USB cable) (ENGLISH) (E) 0 502 1-479-333-13 ADAPTOR, AC (AC-ES608K3) (AC adaptor (6 V))
  • Page 36 PCM-D100 REVISION HISTORY Checking the version allows you to jump to the revised page. Also, clicking the version at the top of the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2013.10 2014.01...
