  • Page 1 XJ-1023 uAxcess XJ-1023 uAxcess XJ-1023 Users Manual - 041419 Users Manual - 041419 Users Manual - 041419...
  • Page 2 COPYRIGHT ACKNOWLEDGEMENTS The contents of this document are the property of Applied Wireless Identifications Group, Inc. (AWID) and are copyrighted. All rights reserved. Any reproduction, in whole or in part, is strictly prohibited. For additional copies of this document please contact:...
  • Page 3 Note: The country code selection is for non-US model only and is not available to all US model. Per FCC regulation, all WiFi products marketed in US must be fixed to US operation channels only.
  • Page 4: Table Of Contents

    Table of Contents REVISION HISTORY....................5 INTRODUCTION....................... 6 General Description ................... 6 Special Features ....................6 Suggested Applications..................6 SPECIFICATIONS ....................7 Measure Read Distance..................7 PREPARATION FOR INSTALLATION ..............7 Site Survey......................7 Preferred reader installation practices..............7 Metal mounting ....................8 General wiring requirements ................
  • Page 5: Revision History

    REVISION HISTORY Version Revised By Date Sections Remarks Affected AWID Engineering 9/2019 Initial version AWID Engineering 10/2019 FCC ID assigned: OGS1356RM...
  • Page 6: Introduction

    INTRODUCTION AWID's uAxcess XJ-1023 Reader is a smart card reader for switch plate mounting. This Reader will provide simultaneous Wiegand and RS-232 output formats. Its primary applications are Access Control and Time & Attendance applications. 1.1 GENERAL DESCRIPTION Thin-line switch plate mounting ...
  • Page 7: Specifications

    SPECIFICATIONS Input voltage .....+5V to +12 V Input current .....250 mA minimum Read range Smart Card (ISO-14443 A/B) ………………Up to 1.5 inches (3.8 cm) Transmit frequency ......13.56 MHz Receiver frequency ......13.56 MHz Operating temperature range .....-30° C to +65° C (-22° F to 149° F) Output format available …….………..Wiegand &...
  • Page 8: Metal Mounting

    3.4 GENERAL WIRING REQUIREMENTS 3.4 GENERAL WIRING REQUIREMENTS All the Reader wiring must be continuously shielded. AWID recommends using #22 All the Reader wiring must be continuously shielded. AWID recommends using #22 All the Reader wiring must be continuously shielded. AWID recommends using #22 AWG up to #18 AWG, six or seven-conductor shielded cables.
  • Page 9: Warranty

    Warranty Warranty AWID’s products are warranted to the original purchaser to be free of defects in material and AWID’s products are warranted to the original purchaser to be free of defects in material and AWID’s products are warranted to the original purchaser to be free of defects in material and workmanship for the life of the product.
