Team C TS2TE Manual page 17

Shock Absorber
29 F
x2
R
TU0266-3/TU0266-4
Shock Top Cover
Front For Short
Rear For Long
TU0250-8 14x1.5 O-ring
Front Suspension
30
T02084 M3 Nylon Nut
..................2
T02082 M3x15 Screw
......2
L
R
Assemble as many times as specified
x2
All manuals and user guides at all-guides.com
TU0266-5/TU0266-6
Top Spring
TU0266-5/TU0266-6
Spring Switching
TU0266-5/TU0266-6
Front Lower Spring-Short
Rear Lower Spring-Long
TU0250-5
Below Spring mount end
T02084 M3
Assemble front and rear sides the same way
F
R
Assemble Both Left And Right
L
R
14
Front For Short
Rear For Long
TU0250-8
14x1.5 O-ring
TU0266-3/TU0266-4
Spring Adjuster
T02082 M3x15
