VERSION
# 20-06-1 2
1 / 9
MODEL #
CM7171D-M
Questions?
GIVE US CALL: 1-888-980-5122
MON-FRI 8:30AM - 5:30PM (PST)
Allen Wrench
(Included)
Phillips
Screwdriver
(Not Included)
3 - People
Recommended
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7171D-M
Summary of Contents for Furniture of America CM7171D-M
- Page 1 MODEL # CM7171D-M Questions? GIVE US CALL: 1-888-980-5122 MON-FRI 8:30AM - 5:30PM (PST) Allen Wrench (Included) Phillips Screwdriver (Not Included) 3 - People Recommended EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 America Furniture FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / X X X X X X X 9...
- Page 5 DRESSER & MIRROR CM7171D-M #1 1pc #2 4pcs #3 1pc #4 1pc Ø 1/4" Support Leg Dresser Bun Foot Mirror 130x29x29mm #5 2pcs Back Rail #A 8pcs #B 8pcs #C 8pcs #D 1pc Bolt Ø1/4" x 1-1/2" Lock Washer Ø1/4"...
- Page 6 CM717 0 D&M is packed in 2 cases Carton Disignation Part Hardware Dresser Bun Foot CM7170D Support Leg Mirror #A 8pcs #B 8pcs CM717 0 M #C 8pcs #D 1pc Back Rail 20mm 32.5mm 123mm 25x10mm 6 / 9...
- Page 7 ASSEMBLY INSTRUCTIONS Part #1 x1pc Remove bun foot (#2) from the bottom drawer of the dresser (#1). Part #2 x4pcs Bun Foot Part #3 x1pc Attach bun foot (#2) to the bottom holes of the dresser (#1). Attach support leg (#3) to the bottom center hole of the dresser (#1).
- Page 8 ASSEMBLY INSTRUCTIONS Prepare 8 bolts assembly by inserting lock washer (#B), then flat washer (#C) onto bolts (#A). Align mirror support (#5) to Part #4 x1pc the holes of the mirror (#4) and dresser (#1). Secure by using Part #5 x2pcs bolts (#A).
- Page 9 9 / 9...
