VERSION # 20-11-07
1 / 9
MODEL #
CM7176T
Questions?
GIVE US A CALL: 1-888-980-5122
MON – FRI 8:30AM – 5:30PM (PST)
TOOLS REQUIRED
3 - People
Recommended
ASSEMBLY RATING
EASY
The Assembly Rating is a
5-point system showing the
level of effort needed to
assemble a specific product.
DIFFICULT
Advertisement
Related Manuals for Furniture of America CM7176T
Summary of Contents for Furniture of America CM7176T
- Page 1 MODEL # CM7176T Questions? GIVE US A CALL: 1-888-980-5122 MON – FRI 8:30AM – 5:30PM (PST) TOOLS REQUIRED 3 - People Recommended ASSEMBLY RATING EASY DIFFICULT The Assembly Rating is a 5-point system showing the level of effort needed to assemble a specific product.
- Page 2 Furniture America FOA Intro Thank you for your purchase! We hope you enjoy this new addition to your home for many years to come. Our commitment to providing quality products does not simply end when you purchase our product. We fully stand behind our products from start to finish. Our customer service department is available Monday –...
- Page 3 PRE ASSEMBLY INTRODUCTION We understand building ready-to-assemble furniture can be a challenging experience for some. To help avoid confusion, we have provided some helpful tips that may speed up the process. Teamwork ALWAYS have at least two people to help with transporting and assembling the product to avoid potential injury and/or damage.
- Page 4 4 / 9...
- Page 5 TWIN BED CM7176T #3 1pc #4 2pcs #5 2pcs #6 2pcs #2 3pcs Top Front Side Rail Headboard Right Footboard Footboard Side Rail Bed Slat - Leg Left Leg Right 1008x45x18mm Pan Head Screw Wood Dowel Wood Dowel M4 x 25mm...
- Page 6 ASSEMBLY INSTRUCTIONS Align Headboard Leg(#4) to the Top front Headboard(#1), then secure by using pan head screw(#F) Part #1 x1pc Sticker L Part #4 x2pcs Left Hardware #F x6pcs Sticker R Back View Right NAIL LEG Hardware #H x12pcs Turn-over the fixed part (#1) &...
- Page 7 ASSEMBLY INSTRUCTIONS Back View Part #2 x3pcs Align the Front Headboard Panel (#2) on the fixed dowel(#H) as shown. Hardware #F x12pcs Lift Headbord with Secure Headboard Leg Upside down (L&R)(#4)and Front Headboard position as shown Panel (#2) with Pan Head Screw(#F) by thighten with Screw Driver (NOT PROVIDED) as shown..
- Page 8 ASSEMBLY INSTRUCTIONS Insert Dowel (#G) to the Footboard Panel (#3) and attach Footboard Leg(L&R) (#7) & (#8) accordingly secure with JCBC (#B), Spring washer (#C) and Bend-Washer (K) . Tighten with Allen Key (#I) as shown. Part #3 x1pc Part #7 x1pc Part #8 x1pc...
- Page 9 ASSEMBLY INSTRUCTIONS Align the Side Rail (#5) and (#6) to Headboard & Footboard then secure by tightening bolts. Part #10 x12pcs Part #E x24pcs leveler Align the Bed Slat . (#10) to side rail (#5)&(#6) tighten with Csk Screw (#E) as per diagram shown.
