LED strip manual
liniLED® PCB Mono White G1 & G4
5
R
2
24
MAC
F
20 mm
V DC
ADAM
IP00
RoHS
System
BEND RADIUS
S D C M

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PCB Mono White G1 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for liniLED PCB Mono White G1 Series

  • Page 1 LED strip manual liniLED® PCB Mono White G1 & G4 20 mm V DC ADAM IP00 RoHS System BEND RADIUS S D C M...
  • Page 3: Table Of Contents

    LED strip PCB Mono White Technical notes Technical specifications | Deco G1 Technical specifications | Power G1 Technical specifications | High Power G4 Maximum cable length | Deco G1 Maximum cable length | Power G1 Maximum cable length | High Power G4 Area advice Product care and handling Cutting instructions...
  • Page 4: Technical Notes

    - Products are transported in proper packaging. Products should remain packed until installation. - Take ESD (Electrostatic Discharge) protection measures when handling liniLED® products. - The products and their components may not be exposed to mechanical, static loads and other tension/compression other than from the product itself.
  • Page 5: Technical Specifications | Deco G1

    Typical values are given, which due to tolerances in components and production process can vary up to 10%. Max. connection length between -30°C and -20°C is 14 metres. Product drawing 14.29 Manual | liniLED® PCB Mono White G1 & G4...
  • Page 6: Technical Specifications | Power G1

    Typical values are given, which due to tolerances in components and production process can vary up to 10%. Max. connection length between -30°C and -20°C is 7 metres. Product drawing 14.29 Manual | liniLED® PCB Mono White G1 & G4...
  • Page 7: Technical Specifications | High Power G4

    Typical values are given, which due to tolerances in components and production process can vary up to 10%. Max. connection length between -30°C and -20°C is 7 metres. Product drawing Product drawing 8.33 Manual | liniLED® PCB Mono White G1 & G4...
  • Page 8: Maximum Cable Length | Deco G1

    2.50 mm2 - 0.007 Ω/m 963.4 m 1855.7 m 187.5 m 366.0 m 90.5 m 179.7 m 42.0 m 86.6 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). Manual | liniLED® PCB Mono White G1 & G4...
  • Page 9: Maximum Cable Length | Power G1

    2.50 mm2 - 0.007 Ω/m 391.4 m 757.5 m 192.5 m 375.5 m 73.1 m 146.3 m 33.3 m 69.9 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). Manual | liniLED® PCB Mono White G1 & G4...
  • Page 10: Maximum Cable Length | High Power G4

    2.50 mm2 - 0.007 Ω/m 215.2 m 419.2 m 104.4 m 206.3 m 37.9 m 78.6 m 15.7 m 36.1 m Note: Calculations are based on a standard connector with 1 metre cable (0.5 mm2). Manual | liniLED® PCB Mono White G1 & G4...
  • Page 11: Area Advice

    Area advice Depending on the area where the liniLED® LED strip is installed we off er a range of solutions to cope with external factors. The product portfolio for the liniLED® PCB LED strip includes an IP00 connector. Indoor environment | (IP00) | liniLED®...
  • Page 12: Product Care And Handling

    Do not twist the LED strip. The LED strip has to be unreeled on a horizontal surface at the time of installation. Do not unreel the spool of LED strip before installation. Manual | liniLED® PCB Mono White G1 & G4...
  • Page 13: Cutting Instructions

    Work in an ESD protected environment. Make use of an anti-static Turn off the power before cutting the LED strip. strap. Top view | Only cut on the dotted lines to prevent damaging the LED strip. Manual | liniLED® PCB Mono White G1 & G4...
  • Page 14: Solder

    We advise to use a cable with an area not larger than 0.5 mm Pre-solder the connector pads. 300°C Max. 4 sec. Pre-solder the wires. Solder the wires to the connector pads. Manual | liniLED® PCB Mono White G1 & G4...
  • Page 15: Connect Ip00

    Connect IP00 Open the PCB connector. Push the liniLED® PCB LED strip into the connector. Make sure the polarity is correct and the connection pads are facing up. Close the PCB connector. Manual | liniLED® PCB Mono White G1 & G4...
  • Page 16: Power And Connection Diagram

    Turn off the power. Make sure the wires are not under electric current. liniLED® Control 230 V Power 24 V Supply (Optional) Measure output (23 - 25V DC) before installing liniLED® system Manual | liniLED® PCB Mono White G1 & G4...
  • Page 17: Symbols

    Disclaimer The published information is checked to be as accurate as possible, however Triolight B.V. or any reseller of liniLED® cannot be held liable for any damages resulting from misprints, errors, modifi cations or outdated information. No legal rights can be derived from this document. Triolight B.V. reserves the right to modify the information without informing the customers.
  • Page 20 V301220...
